Bad Symbol Message

Bad Symbol Message

Note: Bad Symbol Message does not apply to multisymbol operations.
Usage:
Used in verifying the presence of a symbol that has not been decoded.
Definition:
When enabled, a message is sent to the host when a symbol is detected
but not decoded. See
The Bad Symbol output is tied to the transition counter. If during a read
cycle no symbol is decoded and the required setting for the Transition
Sample Threshold is met, a user defined message will be sent to the
host. See
"Output Message Flow" on page 9-8.
Bad Symbol Status
Serial Cmd:
<KMstatus,message>
Serial Cmd:
<K'status,message>
Default:
Disabled
Options:
0 = Disabled
Bad Symbol Message
Serial Cmd:
<KMstatus,message>
Serial Cmd:
<K'status,message>
Default:
BADCODE
Options:
Up to seven ASCII characters (except NUL)
The Bad Symbol output is tied to the transition counter. If during a read
cycle no symbol is decoded and the required setting for the Transition
Sample Threshold is met, a user defined message will be sent to the
host.
MS-710 Scanner User's Manual
6-8
"Transition Counter Threshold" on page 6-8.
1 = Enabled
