Scanning Parameters
Scanning mirror type: Rotating, 10-faceted
Options: Single line/raster300 to 550Scan Rate: scans per second
Scan width angle: Typically 60°; Pitch: ±50°Optional raster mirror image: 10 raster scan
lines over a 2-degree arc (or 0.24 inch raster at 6-inch distance)
Scan Range Raster Height
2 inches (50.8 mm) 0.10 inch (2.54 mm)
4 inches (101.6 mm) 0.17 inch (4.32 mm)
6 inches (152.4 mm) 0.24 inch (6.1 mm)
8 inches (203.2 mm) 0.31 inch (7.87 mm)
10 inches (254 mm) 0.38 inch (9.65 mm)
Communication
RS-232, RS-422/485, Daisy chain
Symbologies
Standard offering: Code 128, Code 39, Code 93, Codabar, Interleaved 2 of 5, UPC/EAN
FIS Options
Each MS-710 model is identified by an FIS (final instruction sheet) number that refer to a set
of options. The following are the standard options available at this time:
Hardware
• Single line / Raster scanning
• Straight out / Right angle
• Bottom mount / Top mount
• Low density / High density
• RS-232 / RS-422 and RS-485
• Second relay for noread option
• MS-Sensor
LED Indicators

Table A-1 MS-710 Status Lights

LED State
PWR On Scanner has power
RDY Green On Scanner is ready to read
GD/RD Green On Symbol is qualified as good
a. In menu status both green lights will flash on and off.
MS-710 Scanner User's Manual
Software
• Wand emulation
• Full ASCII code 39 software
• Code 49 software
• PDF-417
• Extended hold relay
• Photo finishing software
• MSI software
• Long line software
• Long symbol software
• Plessy code
• Pharmacode
a
Status
Appendices
A-3
