Step 1 — Hardware Required
(Refer to figure 1-1.)
Item Part Number
1 FIS-0710-XXXX
2
3 61-300026-01
4
97-100002-01 (120V)
5
97-100002-02 (240V)
99-4400021-03
6
a. With either a terminal communications program or Microscan's ESP™ which runs under Windows™
operating system, Windows-95 or higher, including Windows NT™ and Windows XT.
b. If using another host cable, make certain it does not have RTS/CTS connected to the host.
2
3

Figure 1-1 MS-710 Hardware Configuration

Caution: If using your own power supply, be certain that it is wired correctly and sup-
plies voltage is 5 VDC is within the +10 to 28 VDC limits. Incorrect wiring or voltage can
cause software or equipment failures.
MS-710 Scanner User's Manual
1-2
Description
MS- scanner
a
A host computer
Cable, Communication, DB-25 Plug to DB-9 Socket,
b
6 foot.
IB-105 interface Box
Power supply
Optional object detector
5
4
6
1
