RS-232 Auxiliary Port
Stop Bits, Aux Port
Usage: Only changed if necessary to match host setting.
Definition: Allows the user to select the last one or two bits in each character to indi-
cate the end of the character.
Serial Cmd: <Kyaux port mode,baud
status,daisy chain ID>
Default: One
Options: 0 = One
Data Bits, Aux Port
Usage: Only changed if necessary to match host setting.
Definition: Number of bits in each character.
Serial Cmd: <Kyaux port mode,baud rate,parity,stop
status,daisy chain ID>
Default: Seven
Options: 0 = Seven

Aux Port Mode

Note: The aux port interacts only with the host port via the 25-pin port except when in
Daisy Chain mode. When in Daisy Chain mode, the aux port will also interact with the
configuration port (9-pin port) or the wiring box network ports.
Definition: Determines the flow of data between the auxiliary port device(s), the
scanner, and the host.
Serial Cmd: <Kyaux port mode,baud rate,parity,stop bits,data bits,daisy chain ID
status,daisy chain ID>
Default: Disabled
Options: 0 = Disabled
1 = Transparent
2 = Half duplex
MS-710 Scanner User's Manual
3-10
rate,parity,stop bits,data bits,daisy chain ID
1 = Two
bits,data
1 = Eight
3 = Full duplex
4 = Daisy chain
bits,daisy chain ID
