IB-105 Connectors
Scanner Connector. A 15-pin connector provides connectivity to the scanner.
25-pin (host) "RS-232" Connector. The 25-pin host connector, symboled "RS-232" on
the box, can also be used in certain configurations to route RS-422/485.
RS-485/422 (LAN) Connector. See
Power Connector. Designed to accept the standard +5V Microscan power supply. Chas-
sis ground must be properly connected for the IB-105 and scanner to pass all regulatory
requirements (FCC, CE, CISPER-22).
Trigger Connector. Connects to an object detector.
IB-105 Switches
New Master Switch. Used in match symbol operations to indicate that the next symbol
will be read as the new master symbol. Momentarily press the switch to activate it.
Default Switch. Provides a convenient way to restore factory configuration settings to
the scanner. This switch is recessed to prevent accidentally defaults. See
Saving/Initializing" on page
Power Switch. Accesses +5V power supply (pin 3 of power connector).
Mode Switch. IN or OUT according to configuration.
IB-105 Configuration Options
Note: See tables starting on page A-10
Because the IB-105 is a very flexible device used with more than one scanner model,
you need to verify cable type, IB-105 model, and mode switch setting for your option.
Configuration Description
1 RS-232 with RTS/CTS or RS-485
2 RS-232 with RTS/CTS or RS-422
3 RS-422 with Aux RS-232 or RS-232
4 RS-422 (MS-710) to RS-232
5 RS-422 LAN to RS-232 converter
MS-710 Scanner User's Manual
Table A-6 on page A-10
A-20.
for IB-105 pinouts and mode switch settings.
Internal Dip Switches
8 7 6 5 4 3 2 1
= ON
Appendices
for pinouts.
"Defaulting/
= OFF
A-7
