Microscan MS-710 User Manual page 8

Table 9-1 Summary of Utility Serial Commands ........................................ 9-3
Table 9-2 Hex Value to Binary Conversion .............................................. 9-17
Table 9-3 Scanner Status ........................................................................ 9-17
Table A-1 MS-710 Status Lights ................................................................ A-3
Table A-1 MS-710 Host Connector, 15-pin ................................................ A-5
Table A-2 6-pin Trigger Connector .......................................................... A-10
Table A-3 15-pin Scanner Connector ...................................................... A-10
Table A-4 5-pin Power Connector ........................................................... A-10
Table A-5 25-pin D-sub Host Connector .................................................. A-10
Table A-6 6-pin LAN (RJ11) Connector ................................................... A-10
Table A-7 Complete List of Serial Configuration Commands .................. A-11
Table A-8 ASCII Table with Control Characters ...................................... A-17
Table A-9 Communication Protocol Commands ...................................... A-18
Table A-10 Multidrop Addresses ............................................................. A-33
About the MS-710 Scanner
The MS-710 is a programmable, fixed-mount, high-speed scanner that reads and
decodes a wide variety of bar code symbols using a 10-sided spinning mirror to
project laser beams over a wide scan angle.
A user interface program, the ESP (Easy Setup Program), can be downloaded from our
web site (www.microscan.com) and runs on Windows 2000 or Windows XP operating systems.
Alternately, configuration commands can be sent from an embedded, menu-driven terminal
program, or directly by host serial command strings.
