Edit Saved Spot-Locks

When you save a Spot-Lock, it is saved with an alphanumeric name that starts with SPL. The name can be edited from the Waypoint
Info menu in the Chart View or the Nav Data tool. The Spot-Lock icon cannot be changed unless you turn Spot-Lock off, which will
convert the position to a waypoint.
Edit a Saved Spot-Lock in Chart View
Touch Screen
1. Tap a Spot-Lock icon on the chart.
2. Tap the Spot-Lock Name.
3. From the Waypoint Info menu, select one of the menu
options shown in the table below.
Tapping a menu option will open the selected menu
option, display the on-screen keyboard, or change a
setting to on or off.
Spot-Lock Name
Color
Spot-Lock
Depth Marker
(waypoints only)
Latitude/Longitude
Move
Ruler
Delete
Edit Notes
(select Full Info)
Spot-Locks
Spot-Lock Editing Options
Select the Spot-Lock name and use the on-screen keyboard to change it. After renaming the
Spot-Lock, select Save.
Select a color to represent the Spot-Lock.
To convert the Spot-Lock to a waypoint, turn off Spot-Lock.
If Depth Marker is turned on, the Spot-Lock will convert to a waypoint. The waypoint will be
displayed as a depth marker on the Chart View. The depth is based on the depth at the vessel
position. If the Spot-Lock was marked at the cursor position, the depth will not be saved.
Use the on-screen keyboard to edit the latitude/longitude position of the Spot-Lock or waypoint.
Select Move to move the Spot-Lock to a new position on the Chart View. Use the cursor to
move the Spot-Lock to the new position, and press the ENTER key to save it at the new
position. See Edit Saved Spot-Locks: Move a
Select Ruler to measure the distance between two positions on the chart. Press the ENTER
key to select the measurement start point. Move the Joystick to the second selected position,
and press the ENTER key to mark the measurement end point. The distance between the two
points will be displayed in the lower left corner of the screen.
Select Delete to delete the Spot-Lock.
Open Edit Notes to use the on-screen keyboard to add notes about the Spot-Lock.
Keypad
1. Use the Joystick to move the cursor to a Spot-Lock
icon on the chart.
2. Press the ENTER key.
3. From the Waypoint Info menu, select one of the menu
options shown in the table below.
Press the ENTER key to open the selected menu
option, display the on-screen keyboard, or change a
setting to on or off.
Spot-Lock.
