| Start i-Pilot Link Navigation

When i-Pilot Navigation is selected as the navigation source, the i-Pilot Link becomes the steering source for navigating points,
routes, iTracks, and contour lines. See Configure i-Pilot with the Control Head: Enable i-Pilot Link Navigation.
The i-Pilot Navigation modes can be accessed from the X-Press Remote or the Go To Menu. Also, you can open these menus from
any view. i-Pilot icons are available in Chart View and Radar View.
NOTE: If the boat doesn't move when you start navigation, confirm the i-Pilot Link propeller is turned on (see Propeller Controls).
1. Tap Chart in the status bar, or press the Go To key. Select Go To.
OR
Open the X-Press Remote.
2. Select a navigation mode. This section is an overview. Each navigation mode is detailed throughout this manual.
Spot-Lock
Follow the Contour
(Chart View only)
Circle
AutoPilot
BackTrack
Nav Data
i-Pilot Link Navigation Options
Select Spot-Lock to create and start navigation to a temporary Spot-Lock position, either at
the boat's position or the cursor position. If you select Spot-Lock while navigating a route,
BackTrack, iTrack, or contour, navigation will be paused on the Spot-Lock. See the Spot-Lock
section for more information.
Select Follow the Contour to start navigating the selected contour line. See the Follow the
Contour section for compatible Map Card information and details. This feature is available in
the Chart View only.
Select Circle Mode to set a point to navigate around. You can select clockwise or
counterclockwise. See the Circle Mode section for details.
If the cursor is inactive, navigation begins in the direction of the boat's Course Over Ground
(COG) setting. If COG is not available, the current Heading (Hdg) is used.
If the cursor is active, navigation begins in the direction of the cursor's position using bearing
data from the active cursor.
See the AutoPilot section for details.
Select BackTrack to start navigating back through the Current Track, starting with the last
recorded track point. The Current Track will be converted to a saved iTrack. While navigating
BackTrack, the direction of navigation can be changed using the Reverse menu option. See
the BackTrack section for details.
Select Nav Data to start navigation to a saved waypoint, route, Spot-Lock, iTrack, etc. See
Manage Your i-Pilot Link Navigation Data for details.
43 Navigation Overview
