Engage High Speed Bypass (HSB)

Use High Speed Bypass to automatically set the propeller speed to 10.
W RNING! Watch for a turning propeller and be prepared for boat movement when working with High Speed Bypass. High Speed
Bypass will automatically increase the propeller speed to 10 even if the engagement is accidental. A turning propeller can cause injury.
Engage High Speed Bypass
Touch Screen
1. Open the X-Press Remote: Tap the top, right corner of
the status bar. Tap the remote.
2. Tap the HSB button.
OR
Press and hold the + button.
Disengage High Speed Bypass
To exit High Speed Bypass, decrease the propeller speed or turn off the HSB button.
Touch Screen
1. Open the X-Press Remote: Tap the top, right corner of
the status bar. Tap the remote.
2. Tap the HSB button. (gray = off)
OR
Press and hold the + button.
OR
Tap the - button repeatedly to decrease speed.
Propeller Controls
Keypad
1. Open the X-Press Remote: Press the POWER key.
Select the remote.
2. Select the HSB button. Press the ENTER key.
OR
Press and hold the + (ZOOM IN) key.
Keypad
1. Open the X-Press Remote: Press the POWER key.
Select the remote.
2. Select the HSB button. Press the ENTER key. (gray = off)
OR
Press and hold the + (ZOOM IN) key.
OR
Press the − (ZOOM OUT) key repeatedly to decrease
speed.
50
