Page 2: Warnings
Your Humminbird is designed for trouble-free use in even the harshest marine environment. In the unlikely event that your Humminbird does require repairs, we oﬀer an exclusive Service Policy. For complete details, see the separate warranty card included with your unit. We encourage you to read this operations manual carefully in order to get the full beneﬁt from all the features and applications of your Humminbird product.
Page 3 360 Imaging®, AUTOCHART®, AutoChart® LIVE, ChartSelect®, Cross Touch®, Down Imaging®, DualBeam PLUS™, Dual Spectrum™, Fish ID+™, FishSmart™, Humminbird®, Humminbird Basemap™, i-Pilot® Link™, LakeMaster®, MEGA Imaging™, MEGA Down Imaging™, MEGA Down Imaging+™, MEGA Side Imaging™, MEGA Side Imaging+™, Real Time Sonar™, RTS Window™, SI™, Side Imaging®, SmartStrike™, SOLIX®, Structure ID™, SwitchFire®, WhiteLine™, X-Press™ Menu, and ZeroLine Map Card™ are trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc.
Page 4: Table Of Contents
Manage Routes ........114 Using Humminbird Manuals on your Mobile Device or Computer . .7 Manage Tracks .
Page 5 Set up a NMEA 2000 Network ......247 Set up your Humminbird Network ......256 Change the Network Name .
Page 6: Introduction
Web site at humminbird.com. Register and Update: As you build your Humminbird network, it is important to register your products and keep your software up to date. Visit our Web site at humminbird.com to register your Humminbird products, update control head and accessory software, and purchase additional equipment.
Page 7: Using Humminbird Manuals On Your Mobile Device Or Computer
EVICE OR OMPUTER The Humminbird manuals for your control head and accessories can be downloaded to your mobile device or computer. If you prefer to use a hard copy for reference, this manual may be printed. Download the Manual to your Mobile Device 1.
Page 8: The Solix Control Head
SOLIX C ONTROL The SOLIX control head includes CrossTouch, which allows you to use both the touch screen and keypad to make selections. Review this section for an overview of touch and keypad functions. keypad SD or microSD card slots touch screen Keypad Functions The functions for each key are described here.
Page 9: Solix Touch Screen And Keypad
Name Key Press Function(s) Key Press Function(s) Powers on the control head. POWER key Powers off the control head. During operation, this key opens the Power X-Press Menu. Starts a command. Selects, or turns on, a setting. Adjusts menu settings. ENTER key Opens menus.
Page 10 Touch Screen Functions The touch screen actions are also determined by the view displayed on the screen. Using the Touch Screen Swipe Functions One Finger Swipe (vertical) Two Finger Swipe Browse Menus: Scroll through a menu With a view displayed on-screen, touch the or list (up or down).
Page 11 Tap Functions One Tap Two Taps Select (Open): Tap to select (or open) a Tap the screen twice to zoom in on the view, tool, widget, menu, or icon. current display. Activate the Cursor: Tap a position on the view once. Press and Hold Functions Pinch Press and Hold...
Page 12 Basic Touch Screen and Keypad Operations Select (Open) a Tool, Widget, or View Touch Screen Keypad Select Open tap to open Adjust a Menu Setting Touch Screen Keypad Press Turn Press and Hold Press and Hold OR Slide Close a Tool or Menu Touch Screen Keypad Select...
Page 13 Open a View from the Views Tool Touch Screen Keypad Select Display tap to open Open a View from the Favorite Views Widget Touch Screen Keypad Open Select Display tap to open The SOLIX Control Head...
Page 14: Sd Card Slots
SD Card Slots Your control head may be compatible with an SD or microSD card (separate purchase required). Use it to update software, add detailed charts to your control head, import/export navigation data, and save sonar recordings and screen snapshots. Use the instructions in this section to install the card.
Page 15: Power On/Off
OWER Power On 1. Press the POWER key. 2. Select Start Normal Mode. 3. When the ﬁrst view is displayed on the screen, the control head is ready for operation. Use Standby Mode to Conserve Power To conserve power while the control head is not in-use, start Standby mode from the Power X-Press Menu. 1.
Page 16: Getting Started
ETTING TARTED The procedures in this section describe how to get started with your control head: • review GPS reception • check connected accessories and sensors • start radar transmission • pair your Bluetooth® wireless technology enabled mobile device (phone or tablet) •...
Page 17 | Review GPS Reception Use the GPS tool to check the GPS reception. The GPS tool provides two ways to view the satellites communicating with the GPS Receiver. Yellow indicates that the satellite is being used to determine your current position. Teal indicates that the satellite is being monitored but not used.
Page 18 You can also manually change which GPS receiver is the selected source for GPS (1) or GPS (2). To change the GPS sources, see Set up your Humminbird Network. GPS (1) provides position data, Speed over Ground (SOG), Course over Ground (COG), waypoints, routes, tracks, and navigation calculations to the control head.
Page 19 Link is connected, enabled, and actively navigating. The Talon is connected and stowed. Download the Bluetooth Talon Bluetooth Talon Accessory Manual from our Web site at humminbird.com for additional Talon status icons. Radar The selected radar source is detected and transmitting.
Page 20 2. Press the POWER key. 3. Humminbird CHIRP Radar: Select Radar > Standby. Press the POWER key again, and select Radar > Transmit. Humminbird Radar: Select Radar Transmit. Tap the on/oﬀ button, or press the ENTER key, to turn it on.
Page 21 Pairing a Mobile Phone to the SOLIX Turn paired phone connection on/off. Bluetooth settings device list The status bar indicates the SOLIX is actively searching for Bluetooth devices. Change the Phone Bluetooth Notification Settings Use the following instructions to select an alert format on the control head or turn oﬀ alerts. 1.
Page 22 1. Press the HOME key. Select Alarms. 2. Under Settings, select Alarms. If the control head is connected to the Humminbird network, select Local Alarms (control head only) or Networked Alarms (alarms shared across control heads). See Set up your Humminbird Network for more information.
Page 23 See Radar Overview: Radar Alarms for details. Temp (High) or Temp (Low). To change the Temperature sources, see Installation Information: Temperature Set up your Humminbird Network. Low Fuel, Engine Temp, Oil Level, Coolant Level, Check Engine, etc. To change Engine and Fuel Engine sources, see Installation Information: Set up a NMEA 2000 Network.
Page 24: The Home Screen
CREEN The Home screen is the main control center for your control head. Use the Home screen to access the control head settings, navigation data, views, alarms, and other tools. • The tools, views, and side bar widgets available on the Home screen are determined by the equipment attached to the control head network.
Page 25 Navigate the Home Screen See the instructions and screenshot below to better understand the Home screen layout. Touch Screen Keypad Open a Tool: Tap the tool icon. Select (Open): Use the Joystick to select a menu, tool, or widget. Press the ENTER key to open it. Open a Widget: Tap the widget icon (in the side bar).
Page 26 You can also designate a primary and secondary GPS source from this tool. See Getting Started, Installation Information, and Set up your Humminbird Network. Required Equipment: GPS receiver (internal or external) Select Targets to manage AIS and MARPA targets.
Page 27 Select Audio to listen to AM/FM radio or audio ﬁles saved to a USB stick, iPod, etc. Audio* *Required Equipment: compatible audio system Select Bluetooth to pair your mobile phone and/or Bluetooth wireless remote (separate purchase required) to the control head. You can also assign key functions for the Bluetooth remote from this tool. Bluetooth See your installation guide for details.
Page 28 Side Bar Widgets The side bar includes widgets that allow you to quickly access your favorite views, data bars, and digital remotes for networked accessories, like i-Pilot Link and Talon. The side bar is set to always display on the Home screen, but it can be hidden in other views. See Edit the On-Screen View: Turn the Side Bar On/Oﬀ.
Page 29 Available Side Bar Widgets When you connect an accessory to the control head, a related widget may also be displayed in the side bar. If you have connected an accessory to the control head, and the icon is not displaying in the system status bar, check the installation of the accessory and the cable connection to the control head.
Page 30 Status Bar The status bar is located at the top of the screen. It changes to match the on-screen view and operation mode. In the following illustration, the information in the status bar corresponds with the Chart View displayed on-screen. You can tap the icon in the status bar to open a menu, return to the Home screen, close a menu, or make a selection.
Page 31 Wallpaper The background display, or wallpaper, for your Home screen can be customized. Choose from the existing selection of Humminbird wallpaper images or from your own saved images (on the control head or uploaded from an SD or microSD card).
Page 32: The Menu System
YSTEM The SOLIX provides menu options that change with the application, on-screen view, and the operations mode. Open Settings The Settings tool provides main menu settings for the control head. 1. Press the HOME key. 2. Tap Settings. Use the Joystick to select Settings. Press the ENTER key. Selecting Settings Navigation Main Menu Tap Settings...
Page 33 Open an X-Press Menu The X-Press Menu displays menu options for the on-screen view and operation mode (such as navigation). In a multi-pane view, the X-Press Menu options are determined by which pane is selected. See Views for more information. Open an X-Press Menu 1.
Page 34 Change a Menu or Start an Action Use the following instructions to change a menu setting or start an action through the menu system. 1. Tap a menu category, or use the Joystick to select it. 2. Tap a menu option, or use the Joystick to select it. 3.
Page 35 Tips for Changing a Menu This section describes the diﬀerent types of menus in the menu system and how to change them using the touch screen or keypad. Action ( > ) Touch Screen Keypad Press On/Off Button Touch Screen Keypad Press Slider...
Page 36 Tips for Using the On-Screen Keyboard Use the on-screen keyboard to rename the control head in the network, edit your navigation data, and more. arrows move name field the cursor right or left deletes a single character starts a new line uppercase uppercase deletes all text...
Page 37 Close a Menu When you close a menu, your settings are saved until you change them again or until the control head defaults are restored. back close 1. Back: Tap the Back icon to close the current menu and go back one level in the menu system.
Page 38: Views
IEWS There are many options to display data on-screen, and the data can be displayed in a variety of ways. You can open a view from the Views tool or from the Favorite Views widget (in the side bar). You can also create a new view, edit views, and customize your favorite views list.
Page 39 Views Tool selected group star = favorite return to Home screen close status bar groups available views Options: select to create a new view Tap to Select Select Open Views...
Page 40 Display a View from the Favorite Views Widget Touch Screen Keypad 1. Tap the views widget icon in the side bar. 1. Press the Rotary dial. 2. Tap a view to display. 2. Use the Joystick to select a view to display. Press the ENTER key.
Page 41: Edit The On-Screen View
DIT THE CREEN You can edit a view from the Views tool or from the view that is displayed on the screen. When you edit a view from on-screen, the View Options menu provides additional editing options. Global: To appy changes to all views in the same category, turn on Global. To apply changes to the on-screen view exclusively, turn oﬀ...
Page 42 Display Data Overlays Digital readout data can be displayed as an overlay, and it can be displayed in the data bar. To turn on the data bar, see the next section Display a Data Bar. Display an Overlay on the View 1.
Page 43 Change the Overlay Data Use the following instructions to customize the data displayed in the data overlay. You can also change the overlay color, size, and position on the view. 1. Open the View Options menu. 2. Select Data Overlays. 3.
Page 44 Change the Overlay Appearance You can also change the overlay color, size, and position on the view. 1. Open the View Options menu. 2. Select Data Overlays. 3. Select the Edit: menu. For example, if you have the Sonar overlay displayed, select Edit: Sonar. If you have the Chart overlay displayed, select Edit: Chart.
Page 45 Display a Data Bar Your control head allows you to choose a standard data bar or a navigation data bar with preset data boxes. If you attach additional accessories to the control head or network, additional data bar options may also be displayed. The data boxes in the data bar can also be changed.
Page 46 Data Bars with Multiple Tabs or Data Boxes Data Bar Tabs open the second tab to see more digital readout boxes Some of the data bar options include multiple tabs and data boxes. The standard Data Bar and the Favorite Views widgets both use two tabs.
Page 47 Change the Data Boxes Use the following instructions to change the data boxes displayed in a data bar. NOTE: A data bar must be displayed to access the menu options in this section. See Display a Data Bar. 1. View Options Menu: With a view displayed on-screen, press the PANE key once. In a multi-pane view, press the PANE key repeatedly until the menu displays.
Page 48 The number on the data label (Temp 1, Temp 2, Temp 3, etc.) corresponds with the source number. For more information about sources and networking, see Installation Information, Set up your NMEA 2000 Network, and Set up your Humminbird Network: Select Data Sources.
Page 49 Label Name Description Data Type Fuel (#) Fuel Level The fuel level of the fuel source. Fuel The direction the boat is pointing, measured in degrees. Due to wind Heading and waves, the boat is often traveling in a slightly diﬀerent direction Vessel than its heading.
Page 50: The View Options Menu
PTIONS The View Options menu provides options to edit the selected view. You can open the View Options menu from the on-screen view or from the Views tool on the Home screen. The menu options vary slightly. For example, if you open the View Options menu from an on- screen view, you can also edit the data bar from the menu.
Page 51 Turn the Side Bar On/Off You can turn the side bar on or oﬀ using the View Options menu. Set the side bar to stay displayed to view live data along with the display, or close the side bar to view more of the display. You can customize the data boxes displayed in the data bars.
Page 52 Open the View Options Menu from the Views Tool 1. Press the HOME key. 2. Select the Views tool. 3. Use the Joystick to select a view. Press the MENU key. 4. Close: Press the EXIT key. Opening the View Options Menu from the Views Tool return to Home screen close status bar...
Page 53: Create A New View
REATE A Follow the instructions in this section to create a new view from a blank template. 1. Press the HOME key. 2. Select the Views tool. 3. Select New View. 4. See Edit the View Layout and Application to rename the view, edit the layout, add applications, display digital readouts, and more.
Page 54 Edit the View Layout and Application The Edit menu on the View Options menu allows you to change the type of data that is displayed in the view and how many panes are displayed. 1. Select Edit (or Edit View) from the View Options menu. 2.
Page 55 Adding Applications to the Template applications tab preview window save selected pane applications selected application Tap to Select Select a Pane Select an Application Views...
Page 56 Change the View Name (Views Tool) 1. Select Name from the View Options menu. 2. Use the on-screen keyboard to edit the view name. See The Menu System: Tips for Using the On-Screen Keyboard for more information. Duplicate the Selected View (Views Tool) When you duplicate a view, the control head creates a copy.
Page 57: Set Up An Instrument View
NOTE: The data boxes and gauges must have input from connected and powered equipment. The Engine Instrument View must have input from a NMEA 2000 network to provide source data. For more information about sources and networking, see Installation Information, Set up your NMEA 2000 Network, and Set up your Humminbird Network. Instrument View: Dashboard...
Page 58 Customize an Instrument View In an Instrument View, you can customize the gauges, data boxes, and ranges. You can change each item in the same way you change data boxes in a view. You can also set up warning limits for the selected data range. NOTE: The available changes and sources are determined by the selected gauge or data box.
Page 59: Chart Overview
To enable the navigation features, the control head must have a GPS ﬁx from an internal or external GPS receiver (see Getting Started to check the sensor reception). Some of these features also require a compass/heading sensor to be connected to the control head. 2D Chart View (Humminbird Basemap) X-Press Menu orientation menu...
Page 60: Map Source Overview
Map Source Overview The SOLIX includes built-in charts by Humminbird, Navionics, and AutoChart Live. Humminbird is the default map source, but you can change the map source at any time (see Using the Built-in Charts). SOLIX control heads support the following charts (some require a separate purchase):...
Page 61 Humminbird Charts When Humminbird is selected as the map source, you can use the system defaults, or you can set the menu settings to your preference. You can use the built-in Humminbird Basemap or a Humminbird SD Chart Card (see Using Chart Cards).
Page 62 Humminbird Basemap: Set the following menus to your preference: Text Size Adjust the setting to change the size of font used in the Basemap. Symbol Size Adjust the setting to change the size of the symbols used in the Basemap.
Page 63 2D Chart View (Humminbird Basemap) X-Press Menu orientation menu show cursor sensor status icons north indicator data overlays active cursor map scale cursor dialog box 2D Chart View during Navigation heading line boat icon land current track contour water level offset...
Page 64 Navionics When Navionics is selected as the map source, you can use the system defaults, or you can set the menu settings to your preference. You can use the built-in map, or you can install an SD chart card with additional features. 1.
Page 65 2D Chart View (Navionics) dynamic tides/currents icon symbols chart boundary Map Source: Navionics...
Page 66 AutoChart Live AutoChart LIVE can be used when Humminbird LakeMaster or Navionics is set as the map source. AutoChart LIVE uses data from an installed GPS receiver and 2D transducer (down beam, digital CHIRP or single-frequency DualBeam PLUS or DualSpectrum sonar) to create detailed depth maps of your favorite waters.
Page 67 Using Chart Cards When you install an SD or microSD chart card (separate purchase required), the control head automatically chooses the best map to display. If you install more than one SD or microSD card, you can choose which map source you want to use. Your control head may be compatible with an SD or microSD card (depending on your control head model).
Page 68 Change the Map Source When you install an SD card, the map source is changed automatically to match the SD card map source. You can also change the map source using the Settings tool. When you change the map source, the menu options for the Chart Views also change, allowing you to add navigation data, shading, alarms, and more.
Page 69 Selecting a Map Source selected category return to Home screen close sensor status select chart map source options menu options are determined by the selected map source Tap to Select Select Confirm Map Source...
Page 70: Navigation Alarms Overview
NOTE: To turn on additional alarms that relate to your vessel and navigation, such as Lost Heading, Drift Alarm, Pitch, Roll, and more, select Home > Alarms > System and Home > Alarms > Vessel. Chart View with Alarm Overlays Displayed (Humminbird LakeMaster) off course...
Page 71 Off Course (XTE) Alarm Turn on Oﬀ Course (XTE) to receive an alert if the vessel has traveled outside the selected route. You can also set how far the vessel is allowed to move oﬀ course before the alarm is triggered. If the alarm is turned oﬀ, the Oﬀ Course limit can be displayed on the Chart View, but you won’t receive an alert if the vessel crosses it.
Page 72 Waypoint Avoidance Alarm Turn on Waypoint Avoidance to receive an alert if the vessel has crossed the Waypoint Avoidance Radius. If the alarm is turned oﬀ, the Waypoint Avoidance Radius can be set for a waypoint, and it will be displayed on the Chart View, but you won’t receive an alert if the radius is crossed.
Page 73 Turn on the Alarm 1. Press the HOME key. 2. Select Alarms > Navigation. 3. Select Anti-Collision Alarm. Tap the on/oﬀ button, or press the ENTER key, to turn it on. Display the Anti-Collision Overlay When the overlay is turned oﬀ, the scan area is shown only when a danger is detected. When the overlay is turned on, the scan area is displayed at all times.
Page 74: Man Overboard (Mob) Navigation
(MOB) N VERBOARD AVIGATION As soon as you know that you have a man overboard (MOB), you should activate Man Overboard navigation to maximize the chances for a successful rescue. Man Overboard navigation marks the approximate point where the person went overboard and starts continuous navigation toward the Man Overboard waypoint.
Page 75: Customize The Chart View
The settings in this section are optional. You can use the default settings for the chart appearance and map source, or you can customize the Chart View for your navigation preferences. See Views for more information. Display Chart Layers and Overlays Display overlays on the Chart view to add more details and data. Displaying Humminbird Overlays overlays menu Humminbird LakeMaster...
Page 76 1. Open the Layers Menu: Tap the Layers Menu icon in the task bar. 2. Select Humminbird or Navionics. 3. Humminbird: Select Map Overlay or Base Layer. Select 2D Map, AutoChart, or SI Mosaic. Navionics: Select Satellite Maps, Land, Land + Shoals, or Land + Sea.
Page 77 Displaying Humminbird Overlays overlays menu Humminbird LakeMaster PLUS aerial overlay Tap to Open and Select Chart Options...
Page 78 Humminbird must be selected as the map source to enable the following features. Open the Humminbird Settings Menu When Humminbird is selected as the map source, additional menus to customize the Humminbird chart display are added to the menu system.
Page 79 Adjust the Depth Range and Colors (Humminbird Chart Cards) Humminbird Chart Card must be selected as the map source to enable the following features. See Map Source: Using Chart Cards. 1. From the Humminbird Settings menu, select the settings shown in the table below.
Page 80 Set the Chart Orientation Use the Preferences menu to change the chart orientation. 1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once. 2. Select Chart Options > Preferences > Orientation. 3.
Page 81 Set the Motion Mode Motion Mode controls how the chart moves on the view. This menu is available in Custom Mode (see The Menu System: Change the User Mode). 1. From the Preferences menu, select Motion Mode. 2. Select Relative or True. Relative The position of the vessel is ﬁxed on the view and the chart moves with the vessel.
Page 82 Customize the Navionics Chart Display (optional) Navionics must be selected as the map source to enable the following features. Select Map Data When a Navionics chart is selected as the map source, you can set navaids, marine, and land icons to hidden or visible. The Depth menu option allows you to see shading on the map based on the set depth.
Page 83 Change the Chart Mode Use the instructions in this section to switch the Chart View from 2D to 3D. Change the Chart Mode Touch Screen Keypad 1. With two ﬁngers, tap the screen twice. 1. Press the MENU key. 2. Select Chart Mode. 1.
Page 84: Change The Chart View Data Overlays
1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once. 2. Select Chart Options. 3. Select Overlays. 4. Use the touch screen or Joystick to select a menu and change a setting. (check mark = visible, blank = hidden). Chart View with Overlays Displayed (Humminbird) north indicator waypoint...
Page 85: Chart And Radar
Radar Overview for more information. Start Radar Transmission 1. Humminbird CHIRP Radar: Press the POWER key once. Select Radar > Standby. Press the POWER key again, and select Radar > Transmit. Humminbird Radar: Press the POWER key once. Select Radar Transmit, and turn it on.
Page 86: Introduction To Navigation
There are many ways to start navigation or edit navigation data with your Humminbird control head. The instructions in this section review navigation features on the Chart View.
Page 87: Navigation Menu Overview
The same menus are also opened by pressing the MARK key, GO TO key, or ENTER key. This section is an overview of the menus available for navigation. The availability of menu options is determined by the navigation mode and your Humminbird model. To apply these functions, see Waypoints, Routes, Tracks, and Search. Navigation X-Press Menu The Navigation X-Press Menu allows you to open the following navigation menus: Mark, Go To, and Info.
Page 88: Mark Menu
Mark Menu The Mark menu marks a waypoint at the selected location. You can also create a saved route or mark the vessel position. See Waypoints and Routes for more information about using this menu. Open the Mark Menu 1. Touch Screen: Select Mark from the Navigation X-Press Menu. Keypad: Press the MARK key.
Page 89 Go To Menu Options Select Quick Route to mark quick route points and start navigation. See Routes for more Quick Route information. Nav Data Open the Nav Data tool to select saved navigaton data and start navigation. Open the on-screen keyboard to enter a latitude/longitude position. Select Go To to start Lat/Long navigation to the position.
Page 90: Info Menu
Info Menu Use the Info menu to start a proximity search. You can also set a trolling grid from this menu. If you are using Humminbird as the map source, you can search lake information. Navionics also has additional search options.
Page 91 ENTER key to select the measurement start point. Move the Joystick to the second selected position, and press the ENTER key to mark the measurement end point. Select Lake List to search for lakes within a preset range. Humminbird must be selected Lake List as the map source.
Page 92: Cursor Menu
Cursor Menu The Cursor menu is another way to use the touch sceen and mark a waypoint, create a route, or start a search. The Cursor menu is only available with the 2D Chart View, Sonar Views, or Radar View displayed on-screen. Open the Cursor Menu 1.
Page 93: Waypoints
AYPOINTS Waypoints are saved latitude/longitude positions. They mark a position of interest such as your favorite ﬁshing area, structure, or marker buoy. The control head saves the position and allows you to edit the waypoint name, icon, and more (see Manage your Navigation Data). You can save 10,000 waypoints to the control head. Mark Waypoints Waypoints can be marked at the vessel position or cursor position.
Page 94 Marking a Waypoint at the Cursor Position The Mark menu opens when you press the MARK key or select Mark from the Navigation X-Press Menu. cursor Move the Joystick Press the Press and Hold to Activate the Cursor MARK key Twice Waypoints...
Page 95 Mark + Edit Waypoints (on the go) If you set the Mark Mode to Mark + Edit, you can edit a waypoint immediately when you mark it in the Chart View. See Manage your Navigation Data for more information. 1. Press the HOME key. 2.
Page 96 Edit a Waypoint in the Chart View 1. Tap the waypoint icon to select it. Tap the Waypoint Name. Use the Joystick to move the cursor to a waypoint icon. Press the ENTER key. 2. Use the Waypoint Info menu to edit the waypoint name, icon, color, and more (see Manage your Navigation Data for more information).
Page 97 Set the Waypoint Radius and Avoidance A radius can be set around a selected waypoint. If you select Avoidance, the radius will be highlighted around the waypoint. To receive an alarm when the waypoint avoidance radius has been crossed, turn on the Waypoint Avoidance Alarm (see Navigation Alarms Overview).
Page 98: Routes
OUTES Routes link two or more points together to create a path for navigation. A route represents your intended navigation and shows the shortest path from each data point to the next. The distance between each route point is a route leg. You can save 50 routes to the control head.
Page 99 Marking Route Points with the Touch Screen quick route active start navigation cancel undo last show vessel show cursor route point Tap to Mark Route Points Routes...
Page 100 Starting Quick Route Navigation with the Keypad quick route active start navigation cancel undo last show vessel show cursor route point cursor marking a route point route leg route point Open Go To Menu Move Cursor Position Mark Route Points Start Navigation Routes...
Page 101 Change Route Order During Navigation 1. During navigation, tap Chart in the status bar. Select Go To. Press the GO TO key. 2. Select one of the following menu options: Restart Course: Resets navigation to start from the current vessel position to the next point in the route. Next Point: Skips to the next point in the route.
Page 102 Program a Position and Start Navigation Use the instructions in this section to enter a latitude/longitude position and start navigation to it. Start Navigation to a Latitude/Longitude Position 1. Tap Chart in the status bar. Select Go To. Press the GO TO key. 2.
Page 103 Creating a Saved Route with the Keypad creating a saved route save route cancel undo last show vessel show cursor route point cursor marking a route point waypoint Open Mark Menu Move Cursor Position Mark Route Point Save Routes...
Page 104 Edit a Route in the Chart View 1. Tap the route to select it. Tap the Route Name. Use the Joystick to move the cursor to a route on the chart. Press the ENTER key. 2. Use the Route Info menu to edit the route name, color, and more (see Manage your Navigation Data for more information). 3.
Page 105: Search
4. To start navigation to your selection, press the GO TO key. Search for a Lake If Humminbird is selected as the map source, you can search for lakes in the area. 1. Tap Chart in the status bar. Select Info.
Page 106 Find the Nearest Navigation Data Use the Find Nearest menu to search for the closest waypoints, routes, and tracks. 1. Tap Chart in the status bar. Select Info. Press the ENTER key. 2. Select Find Nearest. 3. Select Waypoints, Routes, or Tracks. 4.
Page 107: Tracks
RACKS A track is a collection of track points that contains the vessel’s detailed position history at set intervals. The Current Track shows the position history since the control head was powered on. Record Track must be turned on to enable this feature (see Record a Track).
Page 108 Save the Current Track Use the following instructions to save the current track and start a new track. 1. Tap a track start point or end point. Tap the Track Name. Use the Joystick to move the cursor to a track start point or end point. Press the ENTER key. 2.
Page 109 Edit a Track in the Chart View 1. Tap a track start point or end point. Tap the Track Name. Use the Joystick to move the cursor to a track start point or end point. Press the ENTER key. 2. Edit the track name, style, color, and more from the Track Info menu. 3.
Page 110: Manage Your Navigation Data
ANAGE YOUR AVIGATION Use the Nav Data tool to manage your saved waypoints, routes, tracks, and groups. You can edit your saved navigation data and start navigation from this tool. Open the Nav Data Tool 1. Press the HOME key. 2.
Page 111: Manage Waypoints
Manage Waypoints Edit a Waypoint 1. Under Lists, select Waypoints. 2. Press and hold a waypoint. Select Info. Use the Joystick to select a waypoint. Press the ENTER key. 3. Edit the waypoint using the options in the Waypoint Info menu. To see the complete list of options to edit the waypoint, select Full Info.
Page 112 Change the Mark Mode for New Waypoints When you mark a waypoint, the control head assigns an alphanumeric name that can be edited from the Nav Data tool. Use these instructions to change how the control head marks a waypoint, allowing you to mark and edit waypoints as you go, or mark waypoints and edit them with your favorite settings.
Page 113 Create Favorite Settings If you’ve selected Mark Favorites as the Mark Mode for waypoints, use the instructions in this section to preset your favorite icon, color, depth marker, default group, and whether the waypoint is visible or hidden. When you mark a waypoint, you will be given the menu options from your favorite settings to edit the waypoint.
Page 114: Manage Routes
Delete a Waypoint 1. Under Lists, select Waypoints. 2. Tap a waypoint or use the Joystick to select it. 3. Press the ENTER key. 4. Select Full Info. 5. Select Delete. Navigate to a Selected Waypoint 1. Under Lists, select Waypoints. 2.
Page 115 Selected Route with Route Points selected route routes selected selected route and preview window summary Delete a Route Point Touch Screen Keypad 1. Under Lists, select Routes. 1. Under Lists, select Routes. 2. Tap a route to open it and display its route points. 2.
Page 116: Manage Tracks
Delete a Route This menu option is not available while the selected route is being navigated. 1. Under Lists, select Routes. 2. Press and hold a route. Select Delete. 1. Use the Joystick to select a route. Press the ENTER key. 2.
Page 117 Record a Track When Record Track is turned on, the control head will save the current track. If you power oﬀ the control head and then power on the control head at a diﬀerent position, there might be gaps in the track. If Record Track is turned oﬀ, the track will not be displayed on the Chart View, and the track will not be recorded or saved.
Page 118 Edit a Saved Track 1. Under Lists, select Tracks. 2. Press and hold a track. Select Info. Use the Joystick to select a track. Press the ENTER key. 3. Edit the saved track using the options in the Track Info menu. To see the complete list of options to edit the track, select Full Info.
Page 119: Manage Groups
Manage Groups Use Groups to organize your navigation data (waypoints, routes, and tracks) in one set. Some anglers prefer to group their navigation data by trip, ﬁsh-type, body of water, or time of day. Default Group: Your navigation data is saved to My Data, the default group for your control head. You can create new groups and save new navigation data to them.
Page 120: Delete All Navigation Data
WARNING! Humminbird is not responsible for the loss of data ﬁles (waypoints, routes, tracks, groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the unit’s hardware or software. It is important to back up your control head’s data ﬁles periodically.
Page 121: Autochart Live Overview
ZeroLine Map Card for unlimited mapping. ZeroLine Map Card: To purchase a ZeroLine Map Card and download the accessory guide, visit our Web site at humminbird.com. More Information: Visit our Web site for informational videos.
Page 122: Prepare The Control Head For Mapping
| Set the Map Source AutoChart LIVE can be used when Humminbird LakeMaster or Navionics is set as the map source. When you install a map card, the map source is changed automatically to match the SD card map source. If your control head has two cards installed, you can choose which map source you want to use.
Page 123 7. Press and hold the EXIT key to close the menu system. 8. If there are additional control heads on your boat with a 2D transducer, conﬁrm that they are not pinging while you are mapping. There should be only one 2D transducer pinging on your boat during the recording process. | Confirm Digital Depth and GPS Fix 1.
Page 124 4. Select Recording Sources. Tap 2D Sonar, or press the ENTER key, to add a check mark to the box. 5. Press the EXIT key. 6. Select Start Recording. NOTE: For more information, see Sonar Recording. Also, visit our Web site at humminbird.com to purchase AutoChart PC and download the manual. AutoChart Live...
Page 125: Record Your Custom Map
2. R ECORD YOUR USTOM While recording your custom map, Chart View will display the depth contour data in real time. Bottom hardness and vegetation will be recording at the same time, however, the data is not displayed in real time on the Chart View. 1.
Page 126: Stop Recording
Collecting Data for your AutoChart LIVE Map depth boat icon contour lines (black lines) depth map in progress current track (red line) depth map scale 3. S ECORDING Use the instructions in this section to stop recording. Your map is automatically saved to the control head (internal) or to the ZeroLine Map Card if it is installed.
Page 127: Correct Data
ORRECT If you see an irregularity in the data (such as lost depth), it can be corrected. Recording must be turned oﬀ while you correct the data. 1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once. 2.
Page 128: Display The Autochart Live Map
ISPLAY THE HART You can make changes to the AutoChart Live map during recording or after you’ve saved your map. You can also view bottom hardness or vegetation data, and you can customize how the data is displayed. Display/Hide your Custom Map The custom map can be displayed or hidden while you are recording or after the map is saved.
Page 129 Display the AC Live Color Bar The AC Live Color bar allows you to display the palette icon for AutoChart Live or Bottom Type. You can use this icon to see the selected palette and, from left to right, the AutoChart Live depth range (low to high), Bottom Hardness range (soft to hard), or Vegetation range (soft to hard).
Page 130: Adjust The Map Display Settings
DJUST THE ISPLAY ETTINGS Use the AutoChart Live Options menu to adjust the depth range, contour interval, and map position. You can also change the color palette and shading. Some of the menu options in this section may be displayed in other parts of the menu system so that you can access them quickly. No matter where you make the change, the control head will update the setting across the system.
Page 131 Change the Highlight Color If you’ve set the Depth Highlight and Depth Highlight Range in the Humminbird Settings menu (Chart X-Press Menu > Humminbird Settings), and it is not easy to see with the AutoChart Live color palette you’ve selected, you can change the Highlight Color. See Customize the Chart View for more information.
Page 132 Change the Shallow Color If you’ve set the Shallow Water Highlight in the Humminbird Settings menu (Chart X-Press Menu > Humminbird Settings), and it is not easy to see with the AutoChart Live color palette you’ve selected, you can change the Shallow Color. See Customize the Chart View for more information.
Page 133 If the water level has not changed (normal), turn oﬀ Water Level Oﬀset. Add Humminbird Chart Settings If Humminbird is set as the map source, you can add Depth Colors, Shallow Water, etc. to your AutoChart LIVE map. See Customize the Chart View: Adjust the Depth Range and Colors for more information.
Page 134: Customize The Bottom Hardness Display Settings
2. Select Bottom Hardness. 3. Adjust the Transparency: Press and hold the slider, or press and hold the ENTER key, to adjust the setting. Displaying the Bottom Hardness Layer (Map Source: Humminbird) Hide Bottom Hardness 1. From the AutoChart Live menu, select Hardness Layer. Tap, or press the ENTER key, to remove the check mark from the box.
Page 135 2. Select Min Hardness. Press and hold the slider, or press and hold the ENTER key, to adjust the setting. 3. Select Max Hardness. Press and hold the slider, or press and hold the ENTER key, to adjust the setting. Adjusting the Bottom Hardness Range (Map Source: Humminbird) AC Live Color Bar NOTE: Use the AC Live Color Bar icon see the selected palette and, from left to right, the AutoChart Live depth range (low to high), Bottom Hardness range (soft to hard), or Vegetation range (soft to hard).
Page 136 Color bar and is aﬀected by the Min Hardness and Max Hardness settings. See Adjust the Hardness Range for more information. 1. From the AutoChart Live menu, select Hardness Options. 2. Select Hardness Color. 3. Select a palette. Changing the Bottom Hardness Colors (Map Source: Humminbird) AutoChart Live...
Page 137: Customize The Vegetation Display Settings
2. Select Vegetation. 3. Adjust the Transparency: Press and hold the slider, or press and hold the ENTER key, to adjust the setting. Displaying the Vegetation Layer (Map Source: Humminbird) Hide Vegetation 1. From the AutoChart Live menu, select Vegetation Layer. Tap, or press the ENTER key, to remove the check mark from the box.
Page 138 2. Select Min Vegetation. Press and hold the slider, or press and hold the ENTER key, to adjust the setting. 3. Select Max Vegetation. Press and hold the slider, or press and hold the ENTER key, to adjust the setting. Adjusting the Vegetation Hardness Range (Map Source: Humminbird) AC Live Color Bar NOTE: Use the AC Live Color Bar icon see the selected palette and, from left to right, the AutoChart Live depth range (low to high), Bottom Hardness range (soft to hard), or Vegetation range (soft to hard).
Page 139 2. Select Vegetation Color. 3. Select a palette. Changing the Vegetation Colors (Map Source: Humminbird) NOTE: Use the AC Live Color Bar icon see the selected palette and, from left to right, the AutoChart Live depth range (low to high), Bottom Hardness range (soft to hard), or Vegetation range (soft to hard).
Page 140: Mosaic Live Overview
• To understand how 360 Imaging works, review the manual that is included with the transducer. When recording the Mosaic, you should have only one Side Imaging sonar source pinging on your boat. To select a Side Imaging sonar source or conﬁrm pinging, see Set up your Humminbird Network: Select Sonar Sources. Mosaic...
Page 141: Open The Mosaic Live Menu
PEN THE OSAIC 1. Press the HOME key. 2. Select a Chart View. 3. Tap Chart in the status bar, or press the MENU key once. 4. Select AutoChart Live. 5. Select Mosaic Live. Record and Save a Mosaic When you record a Mosaic, the control head displays the data as an overlay on the Chart View. If you are planning to use AutoChart PC, start a sonar recording before you start recording your Mosaic (see Sonar Recording).
Page 142 Recording a Mosaic in the Chart View turn on Record add a check mark to display the Mosaic on the Chart View bottom return current track (red line) water column Mosaic...
Page 143: Customize The Mosaic Live Display
USTOMIZE THE OSAIC ISPLAY You can display or hide a Mosaic, and you can adjust the Mosaic Live display settings while it is being recorded or when it is loaded on the Chart View. Display/Hide the Mosaic Live Overlay Use the instructions in this section to display or hide the Mosaic overlay. You can also adjust the transparency. 1.
Page 144 Change the Palette The Palette menu changes the colors used to display the Mosaic. The palette can be changed while a Mosaic is being recorded, or it can be applied to a saved Mosaic on the Chart View. 1. From the Mosaic Live menu, select Mosaic Options. 2.
Page 145 Turn on/off Gain Correct Turn on Gain Correct to automatically tune the transducer signal and ﬁlter any clutter that may show up in the Mosaic Live data. 1. From the Mosaic Live Menu, select Mosaic Options. 2. Select Gain Correct. 3.
Page 146 Turn on/off Contour Mode Contour Mode controls how the water column is displayed in the Mosaic. The location of a target in the Mosaic is inﬂuenced by the Contour Mode setting. For more information, see Customize the Side Imaging View: Turn on/oﬀ Contour Mode. When Contour Mode turned oﬀ, the water column is displayed on the view.
Page 147: Autopilot Overview
UTOPILOT VERVIEW The Humminbird autopilot (SC 110) connects to the control head network. The Humminbird autopilot system requires a separate purchase. For additional autopilot products and equipment, visit our Web site at humminbird.com. SC 110 Humminbird Autopilot Nav Mode with Chartplotter Input...
Page 148 Send Navigation Data to the Autopilot When a route is started from the control head, it will communicate with the autopilot to tell it which way to turn to get on course. The Autopilot Navigation menu must be turned on to enable this feature on the control head. navigation menu Enable Autopilot Navigation...
Page 149: Radar Overview
• Humminbird CHIRP Radar • Humminbird Radar: RH 44, RH 45, AS 12RD2KW, and AS 21RD4KW NOTE: To configure the Humminbird radar after installation or equipment repair, see Installation Information: Configure Humminbird Radar. Humminbird CHIRP radar does not require configuration.
Page 150: Radar Transmission Settings
1. Tap the top, right corner of the status bar. Press the POWER key. 2. Humminbird CHIRP Radar: Under Radar, select Oﬀ. Humminbird Radar: Select Radar Transmit > Oﬀ. 3. Power Oﬀ: Turn oﬀ the power source from the breaker or switch.
Page 151 Select the Radar Mode (Humminbird CHIRP Radar only) For optimum radar operation, select the radar mode for your current environment and weather. See the instructions below. 1. With a Radar View displayed on the screen, tap Radar in the status bar, or press the MENU key.
Page 152 Set up Timed Transmission Settings Set up Timed Transmission Settings: Humminbird CHIRP Radar 1. Press the HOME key. 2. Select Settings. 3. Select Radar. 4. Select Timed Transmit, and turn it on. 5. Select Transmit Cycles. Select the number of cycles that the radar will transmit during Timed Transmission mode.
Page 153: Adjust The Transmission Range
DJUST THE RANSMISSION ANGE The scanner transmission range can be adjusted from the X-Press Menu or by pressing the +/- ZOOM keys. The range setting aﬀects all the Radar Views in the control head. The control head will default to the largest chosen area from all of the Radar Views. Adjust the Range with the Keypad 1.
Page 154: Radar Alarms
ADAR LARMS When an alarm is turned on, it will use the control head’s default setting to provide an alert, and you can also adjust the settings used to trigger an alarm. If you will be tracking targets with MARPA or AIS, see AIS and MARPA. Turn on Radar Alarms 1.
Page 155 Set the Guard Zone If you turned on the Guard Zone alarms in the Alarms tool, use this section to display the Guard Zone and adjust the settings that will trigger the alarm. The settings in this section are optional. You can turn on the Guard Zone alarms and receive alerts using the control head default settings.
Page 156 Setting the Guard Zone Sector (Keypad) save cancel guard zone (shaded area) 1st guard zone cursor position marking 2nd guard zone position Select a Position Confirm Radar Alarms...
Page 157: Customize The Radar View
USTOMIZE THE ADAR The settings in this section are optional. You can use the default settings for the Radar View, or you can customize it with your preferences. See iews for more information. PEN THE ADAR REFERENCES The Preferences menu allows you to set the Radar View orientation, vessel oﬀset, and display colors. For more information about view preferences, see iews.
Page 158 Change Radar Display Colors The Radar Colors menu changes the palette used to display radar returns. The Background Colors menu changes the color of the background on Radar Views. 1. From the Preferences menu, select Radar Colors or Background Colors. 2.
Page 159: Change The Radar View Data Overlays
HANGE THE ADAR VERLAYS Use the Overlays menu to display or hide information on the view. In a Radar View, you can display or hide range rings, range symbols, the compass ring, north indicator, and EBL/VRM readout box. You can also display or hide vessel data, AIS and MARPA targets, navigation data, and the data overlay.
Page 160 Display Digital Readouts as an Overlay Digital readout data can be displayed as an overlay, and it can be displayed in the data bar. For more information about data overlays, see Views. 1. From the View Options menu, select Data Overlays. 2.
Page 161: Adjust Radar Signal Settings
DJUST ADAR IGNAL ETTINGS Use the settings in this section to ﬁlter the returns on the display or increase the amount of returns on the display. Adjust the Gain Setting Use the Gain setting to adjust the sensitivity of the radar. Increase the gain to see more targets on the view, and decrease the gain to reduce the clutter caused by rain or snow.
Page 162 Changing the Gain Setting Using the Rotary Dial Select a Setting Adjust the Color Gain Setting (Humminbird CHIRP Radar only) Use Color Gain to adjust the contrast of the radar returns on the display. 1. With a Radar View displayed on-screen, tap Radar in the status bar.
Page 163 Adjust the Sea Clutter Setting Use the Sea Clutter setting to reduce the clutter that may appear on the view during rough sea conditions. 1. With a Radar View displayed on-screen, tap Radar in the status bar. Press the MENU key. 2.
Page 164: Ebl/Vrm
EBL/VRM Use EBL (Electronic Bearing Range) and VRM (Variable Range Ring) to measure the distance and bearing between any two targets on the Radar View. The EBL and VRM can be set as a pair, and you can set two pairs. The marker is tied to the center of the vessel. As the vessel’s position and heading move, the EBL/VRM also moves.
Page 165 Edit an EBL/VRM 1. With a Radar View displayed on-screen, tap Radar in the status bar. Press the MENU key. 2. Select EBL/VRM. 3. Under EBL/VRM, select Adjust. 4. Use the Joystick to move the cursor until it is positioned over the chosen EBL/VRM intersection. 5.
Page 166: Navigation In Radar View
AVIGATION IN ADAR You can mark waypoints and start navigation from the Radar View. See Introduction to Navigation for more features and information. NOTE: To display navigation data on the Radar View, see Change the Radar View Data Overlays: Display Navigation Data. Mark a Waypoint There are a variety of ways to mark a waypoint in the Radar View.
Page 167 Start Navigation There are a variety of ways to start navigation in the Radar View. The basic instructions are shown here. See Introduction to Navigation for more features and information. Start Quick Route Navigation Touch Screen Keypad 1. Tap Radar in the status bar. 1.
Page 168: Ais And Marpa
MARPA AIS and MARPA allow the control head to display targets on the Chart and Radar Views. While AIS and MARPA share many of the same menus and functions, some of the requirements and operations are diﬀerent for each feature. AIS: Targets within the AIS VHF transmission range are displayed on Chart and Radar Views.
Page 169 Turn on MARPA Alarms For a MARPA target to be detected, the radar must be transmitting and a return must be identiﬁed as a target. The settings in this section are shared with Radar. 1. Press the HOME key. 2. Select Alarms. 3.
Page 170: Ais And Marpa Display Settings
MARPA D ISPLAY ETTINGS Display AIS and MARPA Targets Use the following instructions to display AIS or MARPA Targets on the Chart View or Radar View. NOTE: If Automatic AIS Tracking is turned on, but you do not see AIS targets on the chart and Radar Views, use these instructions to make sure targets are set to display in the Overlays menu.
Page 171 Set Target Display Settings In both AIS and MARPA, when a target is identiﬁed, it is displayed on the screen with an icon that indicates the target’s safety status. You can set defaults for how the targets will display on the screen. 1.
Page 172: Ais Overview
AIS O VERVIEW When an AIS is connected to the control head network, targets within the AIS VHF transmission range are displayed on the Chart and Radar Views. An AIS and compass/heading sensor are required to enable this feature. The AIS tracks up to 100 targets at once. The AIS also exchanges information with the targets, including vessel identiﬁcation, position, course, and speed.
Page 173 AIS Filter Settings You can also control how many AIS targets are shown on the view by adjusting the ﬁlter settings. Turn on/off Range Filter If Range Filter is turned on, targets are displayed from your vessel to the distance you set. Targets outside of the range will not be displayed.
Page 174 AIS Targets Each target is represented by an icon that indicates the vessel type. The color of the target icon is determined by the AIS Target Type shown on the AIS List. The target type shows its status with the following shapes and additional color details. For example, the Cargo Target appearance will change depending on its status, and whether it is moving or anchored, as shown in the following table: Underway Icon...
Page 175 Track AIS Targets You can turn on tracking for all targets. You can also select individual targets and turn tracking on or oﬀ. Turn on/off Automatic AIS Tracking When Automatic AIS Tracking is turned on, all AIS targets are tracked within the equipment’s capabilities. When Automatic AIS tracking is turned oﬀ, all AIS targets are not tracked, but you can still track targets individually (see Track a Selected Target).
Page 176 Start Navigation to a Selected Target Start navigation to a selected target using the following instructions. See Introduction to Navigation for more features and information. Start Navigation to a Selected Target Touch Screen Keypad 1. With a Chart View or Radar View displayed on-screen, 1.
Page 177 Open the AIS Target List The AIS List is based on the last available transmission calculation and includes the targets’ name, MMSI (Maritime Mobile Service Identity, Distance, Bearing, SOG, and Class. The AIS List can be opened in the Targets tool, or it can be opened in the Chart and Radar Views.
Page 178 Display the AIS Data for a Selected Target (Targets Tool) 1. From the Home screen, select the Targets tool. 2. Under Lists, select AIS. 3. Tap a target or use the Joystick to select it. Review the summary information in the dialog box (see the illustration AIS Target Data Received).
Page 179: Marpa Targets
MARPA T ARGETS Use MARPA to track targets on the Radar View. A compass/heading sensor must be attached to the control head network to enable MARPA, and the radar must be transmitting (see Radar Overview). If an AIS is connected, then AIS targets will also be displayed on the Radar View.
Page 180 Radar View with MARPA Targets Displayed orientation menu close cursor sensor status icons MARPA target MARPA target Press and Hold Move the Cursor to Press the Joystick a Radar Return a Radar Return to Acquire Target MARPA...
Page 181 Cancel Tracking for a Selected Target 1. Select a target from the Radar View, Chart View, or Targets tool. 2. Tap the target name, or press the ENTER key. 3. Select Cancel Target. Cancel Tracking for all Targets (X-Press Menu) Use the instructions in this section to cancel tracking from the X-Press Menu.
Page 182 Open the MARPA Target List Open the MARPA List from the Targets Tool 1. Press the HOME key. 2. Select the Targets tool. 3. Under Lists, select MARPA. Open the MARPA List from a View 1. With a Chart View or Radar View displayed on-screen, tap Chart or Radar in the status bar. Select Info. Press the ENTER key.
Page 183 Display the MARPA Data for a Selected Target 1. With a Chart View or Radar View displayed on-screen, tap the target. Tap the target name. Use the Joystick to select a target. Press the ENTER key. The dialog box will display the ID, SOG (Speed over Ground), COG (Course over Ground), CPA (Closest Point of Approach), and TCPA (Time to Closest Point of Approach).
Page 184: Sonar Overview
A functioning transducer must be attached to the control head or selected as the transducer source on the Ethernet network to enable sonar functions. To purchase transducers and black box sonar equipment, visit our Web site at humminbird.com. The SOLIX control head supports the following sonar: •...
Page 185 MEGA Imaging+ MEGA Side Imaging+ and MEGA Down Imaging+ sonar provides three high frequency options, and includes (2D) Dual Spectrum CHIRP sonar. MEGA Imaging+ transducers MEGA SI+ MEGA DI+ XM 14 HW MSI T XM 14 HW MDI T XTM 14 HW MSI T XTM 14 HW MDI T XPTH 14 HW MSI T MEGA SI+...
Page 186 MEGA DI+ MDI+ sonar beams point down and scan the water with razor-thin, high deﬁnition beams that are wide side to side, but very thin from front to back. The beams can be operated at one of three display frequencies: MEGA+, 800 kHz, or 455 kHz. MDI+ also includes (2D) Dual Spectrum CHIRP sonar.
Page 187 MEGA Imaging Transducers with (2D) DualBeam PLUS MEGA SI MEGA DI XM 14 20 MSI T XM 14 MDI T XPTH 14 74 MSI T XTM 14 20 MDI T XTM 14 20 MSI T MEGA SI MSI sonar uses two very precise sonar beams that are aimed at right angles to the path of the boat. The side beam coverage is very thin from front to back, yet very wide from top to bottom.
Page 188 (2D) Dual Spectrum CHIRP Dual Spectrum CHIRP sonar provides conical coverage directly below the boat. The beam can be adjusted to show the full, narrow, or wide frequency range. The sonar returns are displayed on the Sonar (2D) Views. Full Select Full Beam (default) to use the complete frequency range.
Page 189 DualBeam PLUS Sonar DualBeam PLUS sonar provides conical coverage directly below the boat. The beam can be adjusted to show the medium, high, or medium-high frequency range. DualBeam PLUS sonar returns are displayed on the Sonar (2D) Views. Select Medium Frequency for deep water (more than 800 feet). Medium Medium Frequency can be used for deep returns at high speed.
Page 190: Sonar Setup
Transducer Settings: To review transducer settings, including sonar frequencies, depth oﬀset, and maximum depth, see Installation Information: Set up or Change Transducer Settings. Also, visit our Web site at humminbird.com to download the Transducer Setup Guide and review troubleshooting options.
Page 191: Sonar Alarms
ONAR ALARMS Before you start navigating and ﬁshing with your control head, set up sonar alarms. A functioning transducer must be attached to the control head or selected as the transducer source on the network to enable all sonar functions. Turn on Sonar Alarms 1.
Page 192: Sonar Overview
2D S ONAR VERVIEW As the boat moves, the unit charts the changes in depth on the display to create a proﬁle of the bottom contour. The 2D Sonar View displays the sonar return intensity with diﬀerent colors. Strong returns often result from rocky or hard bottoms (compacted sediment, rocks, fallen trees), while weaker returns often result from soft bottoms (sand, mud), vegetation, and small ﬁsh.
Page 193: Customize The 2D Sonar View
2D S USTOMIZE THE ONAR The settings in this section are optional. You can use the default settings for the 2D Sonar View, or you can customize it with your preferences. See Views for more information. 2D S PEN THE ONAR REFERENCES The Preferences menu allows you to set the sonar mode, zoom mode, return palette, background color, bottom view, and...
Page 194 Set the Zoom Mode The Zoom Mode sets the zoom commands to magnify the full pane or the cursor selection. See Use Cursor and Zoom in Sonar Views to apply the zoom features. 1. From the Preferences menu, select Zoom Mode. 2.
Page 195 Sonar View with a Customized Palette and Background preview window menu selection Palette Options Weak Strong Original Green Set the Bottom View Preferences Bottom View selects the method used to represent bottom and structure on the display. There are many ways to display the bottom on the display.
Page 196 Select Bottom Line to display the depth reading from the Depth Source as a line, either from Bottom Line the selected transducer or another digital depth source. See Set up your Humminbird Network for details about selecting sources. 2D Sonar...
Page 197 Display the RTS Window The RTS Window plots the depth and intensity of a sonar return. It updates at the fastest rate possible for depth conditions and shows only the returns from the bottom, structure, and ﬁsh that are within the transducer beam. When you use the cursor to review sonar history, the sonar history will pause, but the RTS Window will continue to display sonar returns in real time.
Page 198 2D Sonar View (Split Dual Mode) with RTS Window and Fish ID+ Turned On fish depth number fish icon (83 kHz beam) RTS Window set to A-Scope 2D Sonar...
Page 199: Change The 2D Sonar View Overlays
2D S HANGE THE ONAR VERLAYS Use the Overlays menu to display or hide information on the view. In the 2D Sonar View, you can display the following: depth lines, depth range, a color bar for the selected palette, temperature graph, beam frequency label, and data overlays. Digital readout data can be displayed as an overlay, and it can be displayed in the data bar.
Page 200: Adjust 2D Sonar Display Settings
2D S DJUST ONAR ISPLAY ETTINGS The X-Press Menu provides menu options to adjust the sensitivity and range as you ﬁsh. You can also mark a particular depth and control how fast the sonar history scrolls across the screen. The menu options allow you to see more or less of the sonar returns from the transducer beams as you adjust each setting.
Page 201 Adjust Display Settings 1. With a 2D Sonar View displayed on-screen, tap Sonar (2D) in the status bar, or press the MENU key once. 2. Select Sensitivity, Contrast, or Chart Speed. 3. Press and hold the slider, or turn the Rotary dial, to adjust the setting. Sensitivity controls how much detail is shown on the display and will adjust the sensitivity of all sonar frequencies.
Page 202 Change the SwitchFire Mode SwitchFire controls how the sonar returns are displayed in the view. 1. With a 2D Sonar View displayed on-screen, tap Sonar (2D) in the status bar, or press the MENU key once. 2. Select SwitchFire. 3. Select Clear Mode or Max Mode. SwitchFire: Clear Mode SwitchFire: Max Mode Tap to open the SwitchFire menu in the status bar.
Page 203 If there are multiple beams available in a transducer, you can display individual frequencies on the 2D Sonar View. See Installation Information: Set up your Humminbird Network, Select Sonar Sources and Set up or Change Transducer Settings for details. 1. With a 2D Sonar View displayed on-screen, tap the frequency menu in the status bar.
Page 204 2D Sonar View Tap to open the SwitchFire menu in the status bar. frequency menu Press and Hold Tap to Select to Change the Setting Adjust Beam Sensitivity Your control head model may allow you to adjust the sensitivity of individual frequencies. The available frequencies are determined by your control head model and the installed transducer.
Page 205: Side Imaging Overview
MAGING VERVIEW MAGING RANSDUCER EQUIRED Side Imaging beams “illuminate” the bottom contour, structure, and ﬁsh. The side beam coverage is very thin from front to back, yet very wide from top to bottom. The bottom composition determines the intensity of the sonar return, and upward slopes that face the transducer reﬂect sonar better than downward slopes that face away from the transducer.
Page 206 Side Imaging View, variations in the width of the water column show variations in the distance to the bottom as the vessel passes over. For Best Side Imaging Performance • Vessel Speed: 2 to 6 mph • Straight line navigation • Minimum turning time and wave turbulence Also, see humminbird.com for tutorials and Side Imaging videos. Side Imaging...
Page 207: Customize The Side Imaging View
USTOMIZE THE MAGING The settings in this section are optional. You can use the default settings for the view, or you can customize it with your preferences. See Views for more information. PEN THE MAGING REFERENCES The Preferences menu allows you to select a beam to display, set the zoom mode, return palette, and turn on Contour Mode and SI Navigation.
Page 208 Turn on/off Contour Mode Contour Mode controls how the water column is displayed in the Side Imaging Views. When Contour Mode turned oﬀ, the water column is displayed on the view. The location of a target on the display is based on the slant range to the target. When Contour Mode is turned on, the bottom is graphed at a constant point on the display, regardless of changes in depth.
Page 209: Change The Side Imaging View Overlays
HANGE THE MAGING VERLAYS Use the Overlays menu to display or hide information on the view. In the Side Imaging View, you can display the following: boat icon, range lines, range intervals, side label, frequency label, and data overlays. To turn on the data overlay or data bar, see Views: Edit the On-Screen View.
Page 210: Adjust Side Imaging Display Settings
DJUST MAGING ISPLAY ETTINGS The X-Press Menu provides menu options to adjust the sensitivity, contrast, sharpness, and range as you ﬁsh. You can also mark a particular range, and you can control how fast the sonar history scrolls across the screen. The menu options allow you to see more or less of the sonar returns from the transducer beams as you adjust each setting.
Page 211 Change the SwitchFire Mode SwitchFire controls how the sonar returns are displayed in the view. 1. With a Side Imaging View displayed on-screen, tap Sonar (SI) in the status bar, or press the MENU key once. 2. Select SwitchFire. 3. Select Clear Mode or Max Mode. Choose Clear Mode to see less clutter and more ﬁsh size accuracy on the display.
Page 212 If there are multiple beams available in a transducer, you can display individual frequencies on the view. See Installation Information: Set up your Humminbird Network, Select Sonar Sources and Set up or Change Transducer Settings for details. 1. With a Side Imaging View displayed on-screen, tap the frequency menu in the status bar.
Page 213: Down Imaging Overview
MAGING VERVIEW MAGING RANSDUCER OR MAGING RANSDUCER EQUIRED The images you see on the Down Imaging display are produced using sonar technology. Each time the unit pings, a strip of data representing all the echoes received by the transducer are put together on the display to form the image that you see. Like traditional 2D Sonar, the sonar history scrolls left across the screen.
Page 214: Customize The Down Imaging View
USTOMIZE THE MAGING The settings in this section are optional. You can use the default settings for the view, or you can customize it with your preferences. See Views for more information. PEN THE MAGING REFERENCES The Preferences menu allows you to set the palette, zoom mode, and bottom line. For more information about view preferences, see Views.
Page 215 Add a check mark to Bottom Line to display the depth reading from the Depth Source as a line, either from the selected transducer or another digital depth source. See Set up your Humminbird Network for details about selecting sources.
Page 216: Change The Down Imaging View Overlays
HANGE THE MAGING VERLAYS Use the Overlays menu to display or hide information on the view. In the Down Imaging View, you can display the following: depth range, beam frequency label, and data overlays. Digital readout data can be displayed as an overlay, and it can be displayed in the data bar.
Page 217: Adjust Down Imaging Display Settings
DJUST MAGING ISPLAY ETTINGS The X-Press Menu provides menu options to adjust the sensitivity and range as you ﬁsh. You can also mark a particular depth, and you can control how fast the sonar history scrolls across the screen. The menu options allow you to see more or less of the sonar returns from the transducer beams as you adjust each setting.
Page 218 Adjust Display Settings 1. With a Down Imaging View displayed on-screen, tap Sonar (DI) in the status bar, or press the MENU key once. 2. Select Sensitivity, Contrast, Chart Speed, or Sharpness. 3. Press and hold the slider, or turn the Rotary dial, to adjust the setting. Sensitivity controls how much detail is shown on the display and will adjust the sensitivity of all sonar frequencies.
Page 219 If there are multiple beams available in a transducer, you can display individual frequencies on the view. See Installation Information: Set up your Humminbird Network, Select Sonar Sources and Set up or Change Transducer Settings for details. 1. With a Down Imaging View displayed on-screen, tap the frequency menu in the status bar.
Page 220: Use Cursor And Zoom In Sonar Views (2D, Si, Di)
URSOR AND OOM IN ONAR IEWS (2D, SI, DI) You can use the cursor in the 2D Sonar, Side Imaging, and Down Imaging Views. With the cursor activated, you can magnify sonar returns on the view to get a closer look. NOTE: To display the 2D Sonar View in Split Zoom mode, see Customize the 2D Sonar View: Change the Sonar Mode.
Page 221 Using Cursor Zoom Mode (2D Sonar View) show cursor exit cursor selection magnified location of cursor in sonar frequency history label (2D and DI only) Tap to Activate Pinch out to Magnify Move the Joystick Press the + ZOOM key to the Cursor the Selection to Activate the Cursor...
Page 222: Navigation In Sonar Views (2D, Si, Di)
AVIGATION IN ONAR IEWS (2D, SI, DI) To mark waypoints and start navigation, the control head must have a GPS ﬁx from a connected or internal GPS receiver. The navigation menus can be accessed from the X-Press Menu, touch screen, and the keypad. Mark a Waypoint You can mark a waypoint on the Sonar Views using the keypad or touch screen.
Page 223 Navigate to a Position Use the instructions in this section to start navigation to a position in the Sonar Views. See Introduction to Navigation for more information about these features. Start Navigation Touch Screen Keypad 1. Press and hold a position on the Sonar View. 1.
Page 224: Sonar Recording
ONAR ECORDING Use the Sonar Recording menu to record active sonar information. Sonar recordings are saved to an installed SD card, and you can play your saved sonar recordings from the Recordings tool. When the recording is played back, the views that were active during the recording are available.
Page 225: Images Tool
MAGES The Images tool displays the screen snapshots saved to the control head or to the installed SD cards. You can edit, rename, copy, and delete a screen snapshot. You can also view your saved screen snapshots (JPG ﬁles) as a slide show. Take a Screen Snapshot Use the screen snapshot feature to take a picture of the on-screen view.
Page 226 Sort Screen Snapshots 1. From the Images tool, select Settings. 2. Select Sort Options. 3. Select a sort option to sort by Name, Date, or File Type. To view the images from newest to oldest, select Reverse Order. Tap the on/oﬀ button, or press the ENTER key, to turn it on. Screen Snapshot Settings Screen snapshots are automatically saved to the control head as JPG ﬁles.
Page 227 Create a Waypoint with Screen Snapshot If you turn on Create Waypoint in the Images tool, each time a screen snapshot is taken, the waypoint position will be saved. 1. Press the HOME key. 2. Select the Images tool. 3. Select Settings. 4.
Page 228 Display Screen Snapshots and Slideshow When you select a saved screen snapshot (JPG ﬁle) from the Images tool, you can display it in full-screen using the touch screen or keypad. Using the Touch Screen with a Saved Screen Snapshot start close slideshow Previous...
Page 229 Set up the Slideshow Screen snapshots and pictures from your camera’s SD card can be displayed in a slideshow. You can use the control head default settings to play the slide show, or you can set the slideshow to loop or shuﬄe. 1.
Page 230 Edit Screen Snapshots The Images Options menu allows you to edit the name and review the ﬁle information for the selected screen snapshot. You can also copy screen snapshots to another save location or delete them. Change a Screen Snapshot Name 1.
Page 231: Installation Information
NMEA 2000 network, and add transducers to your system through black box sonar. For conﬁguration options and the latest Humminbird accessories, visit our Web site at humminbird.com. Installation guides are included with each hardware component to install equipment purchased separately (transducer, heading sensor, radar, AIS, autopilot, and accessories).
Page 232: Set Up Or Change Transducer Settings (Advanced Settings)
Transducer Setup Guide from our Web site at humminbird.com. NOTE: Humminbird has provided the best settings for your unit. You can use the settings included with your control head, or you can adjust these advanced options.
Page 233 If the selected transducer (sonar source) includes more than one beam, you can select which beam will be displayed in the sonar view. The beams selected in this menu aﬀect all units that are sharing the sonar source. See Set up your Humminbird Network: Select Sonar Sources for details.
Page 234 1. Press the HOME key. 2. Select Settings. 3. Select CHIRP Sonar. 4. Under 2D CHIRP, select 2D CHIRP Frequency Select. 5. Select a frequency. See the Frequency Select Options tables on the following pages. To access all beams in the 2D Sonar View, but view individual frequencies on diﬀerent control heads, select Auto, Medium, or Medium/High Frequency.
Page 235 Select and Display Frequencies for the Side Imaging View (optional, CHIRP MEGA SI and CHIRP MEGA SI+ models only) Use the instructions in this section to choose a frequency that will be used for the Side Imaging View. QUICK TIP! You can also select this menu on the status bar and in the X-Press Menu in Side Imaging View. 1.
Page 236 WARNING! If an accessory transducer is installed, confirm it is configured in the control head. See Set up or Change Transducer Settings for details. For information about accessory transducers, visit our Web site at humminbird.com. Adjust the CHIRP Frequency Spectrum (2D CHIRP, SI CHIRP, DI CHIRP)(not recommended) 1.
Page 237 Setting the 2D CHIRP Frequency Spectrum set the frequency spectrum for each beam Turn On/Off CHIRP Sonar (not recommended) To view digital CHIRP sonar, CHIRP must be turned on. To view single frequency sonar, turn CHIRP oﬀ. You can also adjust the single frequency range.
Page 238 Use SI Orientation to switch how the Side Imaging beams are displayed on the Side Imaging View. This menu option can be used if the port and starboard beams are reversed during installation, which might be the case if a transducer is installed incorrectly. For further assistance, contact Humminbird Customer Service. 1. Press the HOME key.
Page 239 Change Imaging+ Presets (MEGA SI+ and DI+ models only) Use one of the Imaging+ Presets to change your frequency for maximum detail or maximum coverage. 1. Press the HOME key. 2. Select Settings. 3. Select CHIRP Sonar. 4. DI+: Under DI CHIRP Frequency Spectrum, select one of the presets: Increased Detail, Increased Depth 1, Increased Depth 2. SI+: Under SI CHIRP Frequency Spectrum, select one of the presets: Increased Detail, Increased Range 1, Increased Range 2.
Page 240: Configure Humminbird Radar (Installation And Repair Only)
The radar should be conﬁgured by a qualiﬁed radar technician after installation or equipment repair. The settings in this section should only be needed periodically. We recommend that you contact Humminbird Customer Service at 1-800-633-1468 before using the menus in this section.
Page 241 For best results, run the tuning while there are targets within range, so it will be easier to review the data and make adjustments. WARNING! The radar should only be tuned under very limited circumstances. Contact Humminbird Customer Service at 1-800-633-1468 before tuning the radar.
Page 242 3. Tap the Back icon, or press the EXIT key. WARNING! Humminbird is not responsible for the loss of data files (waypoints, routes, tracks, groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the unit’s hardware or software. It is important to back up your control head’s data files periodically.
Page 243: Configure The Control Head
ONFIGURE THE ONTROL Use the instructions in this section to review control head and network connections, select baud rates and NMEA 0183 Output sentences, and name the control heads and networks. When the SOLIX control head equipment and accessories are installed, the Setup Guide provides the prompts to guide you through conﬁguring the unit.
Page 244 Sensor Port Connections (GPS and NMEA 0183) When equipment is connected to the control head, the equipment and its data will be detected automatically. You can also manually select data, set the data oﬀset, baud rate, and NMEA output sentences from the Sensor Port submenus. The available menus are determined by the attached equipment.
Page 245 NMEA 0183 Message Description Input Output Waypoint Arrival Alarm • Heading/Track Controller (Autopilot) Sentence “B” • • Bearing-Origin to Destination • Bearing & Distance to Waypoint - Great Circle • Bearing & Distance to Waypoint - Rhumb Line • • Depth Below Transducer Depth •...
Page 246 Wind MWV or VWR NOTE: See the SC 110 manual and the SCP 110 manual for details. To download the manuals, visit our Web site at humminbird.com. 9. Press the EXIT key to return the previous menu. 10.Select Baud Rate. Select 4800.
Page 247: Set Up Anmea 2000 Network
When equipment is connected to the control head, the equipment and its data will be detected automatically. You can also manually select equipment and set the data oﬀset. The available menus are determined by the attached equipment. NOTE: Humminbird recommends that the NMEA 2000 network be installed by a certified NMEA 2000 technician. See NMEA.org for details.
Page 248 NMEA 2000 Network Devices Selected Manually Turn off Auto-Select selected device devices detected but not selected NMEA 2000 Network Devices Selected Automatically Turn on Auto-Select devices detected and selected on the NMEA 2000 network NMEA 2000 Setup...
Page 249 Set NMEA 2000 Data Offsets 1. From the NMEA 2000 Sensor port menu, select Data Oﬀsets. 2. Select a device. 3. Tap the on/oﬀ slider, or press the ENTER key, to turn it oﬀ. 4. Press and hold the slider, or press and hold the ENTER key, to set the oﬀset amount. NMEA 2000 Data Offset Turn off the slider to manually adjust...
Page 250 NMEA 2000 Messages (PGN) The following NMEA 2000 input/output messages are available when NMEA 2000 is turned on and the related NMEA 2000 equipment is detected and selected as a source. Message (PGN) Description Input Output 059392 ISO Acknowledgement • •...
Page 251 NMEA 2000 AIS Messages (PGN) The following NMEA 2000 input/output messages are available when NMEA 2000 is turned on and an AIS is detected and selected as a source on the NMEA 2000 network. Message (PGN) Description Input Output 129038 Class A Position Report •...
Page 252 Engine 1 Source Auto-Configured Engine (1) is selected When Auto- Configure is turned on, the control head assigns numbers to each engine automatically. Instance 0 = Engine 1 Source Change the Engine Source Assignments The instructions in this section are optional and allow you to change which engine is assigned as the Engine 1, Engine 2, or Engine 3 source in the control head.
Page 253 Set up Fuel Tanks The Setup Guide provides prompts to set up the fuel tanks in the system, and it assigns a source number to each fuel tank. If a NMEA 2000 fuel tank sensor and a fuel ﬂow rate sensor are installed, the control head can display fuel levels automatically. If only a fuel ﬂow rate sensor is installed, you need to set up the fuel tanks manually to manage fuel levels.
Page 254 Setting up Fuel Tanks Manually settings select Manual select Fuel Capacity to enter data manually Displaying the Fuel Tool Open the Fuel Tool 1. Press the HOME key. 2. Select the Fuel tool. Refill the Tank(s) The menu options in this section are determined by the Fuel Management Mode (Manual or Automatic). See Set the Fuel Tank Capacity for more information.
Page 255 Change the Fuel Tank or Fuel Flow Source Assignments The instructions in this section are optional and allow you to change which fuel tank is assigned as the Tank 1, Tank 2, or Tank 3 source in the control head. You can also use these instructions to change the fuel ﬂow rate Sensors (Fuel Flow) assignments. The menu options are determined by the type of sensors installed.
Page 256: Set Up Your Humminbird Network
UMMINBIRD ETWORK When the Humminbird network is fully installed, conﬁgure the network so the control heads and equipment are synchronized across the network. Depending on your network conﬁguration, your options may include sources from remote control head(s), NMEA 0183, Ethernet, and NMEA 2000.
Page 257 The SOLIX control head is compatible with black box sonar to expand its sonar capabilities. See humminbird.com for transducer conﬁguration options. NOTE: Humminbird has provided the best settings for your unit. You can use the settings included with your control head, or you can adjust these advanced options.
Page 258 The transducer you select on the Down Imaging tab will provide the data for the Down Imaging Views and related digital readouts. The transducer you select on the Side Imaging tab will provide the data for the Side Imaging Views and related digital readouts. Humminbird Network Setup...
Page 259 When you turn on/oﬀ pinging or change the transducer settings, all control heads sharing the transducer are aﬀected. selected source turn on/off transducer setup turn on/off pinging menu transducer If you change settings here, it will change the settings across the network. Humminbird Network Setup...
Page 260 Share GPS Sources with the Network 1. Under GPS Source, select Global Source. 2. Tap the on/oﬀ button, or press the ENTER key, to turn it on. NOTE: See Set up your Humminbird Network for details about Global On/Off. Humminbird Network Setup...
Page 261 4. Select Data Sources. 5. Select a Data Category, and select the data type under that category. 6. Select Auto-Conﬁgure. Tap the on/oﬀ button, or press the ENTER key, to turn it oﬀ. 7. Select a source from the list. Humminbird Network Setup...
Page 262: Change The Network Name
1. Press the HOME key. 2. Select Settings. 3. Select Network. 4. Select Network Info. 5. Select Rename Network. Use the on-screen keyboard to change the control head name. 6. Select Save. Humminbird Network Setup...
Page 263 The sources you select will provide the data for the related digital readouts and more, depending on your selection. In the illustration above, see Information about the Selected Source. The Temp 1 digital readout data is provided by the Temp (1) source. Humminbird Network Setup...
Page 264: Manage Your Control Head
ANAGE YOUR ONTROL Many of the control head settings can be accessed from the Settings tool (General Menu) or from the Power X-Press Menu in the status bar. Open the Settings Tool 1. Press the HOME key. 2. Select Settings. 3.
Page 265 WARNING! Humminbird is not responsible for the loss of data ﬁles (waypoints, routes, tracks, groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the unit’s hardware or software. It is important to back up your control head’s data ﬁles periodically.
Page 266: Update Software
PDATE OFTWARE As you build your Humminbird network, it is important to keep your control head and accessories software up to date. Accessories such as i-Pilot Link, 360 Imaging, and Ethernet Switches are updated through the SOLIX control heads. You can update software using an SD or microSD card (depending on your SOLIX model) or using the built-in Bluetooth and the Humminbird FishSmart App.
Page 267 4. Repeat step 3 to download the software updates posted to each product. 5 | Update Control Head Software Supplies: In addition to your Humminbird equipment, you will need a PC with Internet access and a blank SD or microSD card (depending on your control head model).
Page 268 Update Software Automatically 1. Press the POWER key. Follow the on-screen prompts to start normal mode on the control head. 2. Install the SD card with the software ﬁle(s) into the control head card slot. 3. A dialog box will display to start the software update. To start the control head software update, select Install.
Page 269 6 | Update Accessories Accessory software is updated from the Files tool, and the process is similar to updating the control head software. It is important to review the following tips: • Update the control head and accessories in the order they appear on the software update list in the Files Tool. Sonar Black Boxes (SM3000) and Ethernet Switches must be updated individually on the software update list.
Page 270: Specifications
Power Output (MAX) ............. . 500 Watts (RMS), 4000 Watts (Peak to Peak) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition, and slope.
Page 271 SOLIX SI G1 Control Head SOLIX 10 Display Size (diagonal) ..............10.1 inches (256.54 mm) SOLIX 12 Display Size (diagonal) .
Page 272 Power Output (MAX) ............. . 500 Watts (RMS), 4000 Watts (Peak to Peak) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition, and slope.
Page 273 SOLIX DI G1 Control Head SOLIX 10 Display Size (diagonal) ..............10.1 inches (256.54 mm) SOLIX 12 Display Size (diagonal) .
Page 274 Power Output (MAX) ............. . 500 Watts (RMS), 4000 Watts (Peak to Peak) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition, and slope.
Page 275 SOLIX MEGA SI+ G2 Control Head SOLIX 10 Display Size (diagonal) ..............10.1 inches (256.54 mm) SOLIX 12 Display Size (diagonal) .
Page 276 Power Output (MAX) ............. . 500 Watts (RMS), 4000 Watts (Peak to Peak) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition, and slope.
Page 277 SOLIX MEGA DI+ G2 Control Head SOLIX 10 Display Size (diagonal) ..............10.1 inches (256.54 mm) SOLIX 12 Display Size (diagonal) .
Page 278 Power Output (MAX) ............. . 500 Watts (RMS), 4000 Watts (Peak to Peak) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition, and slope.
Page 279 SOLIX 10 Control Head Measurements SOLIX 10 In-Dash Mount (separate purchase required) Width 11.8" (300 mm) Height 7.1" (179.3 mm) Depth 1.52" (38.6 mm) SOLIX 10 Gimbal Mount Width 11.8" (299.7 mm) Height 7.1" (180.3 mm) Depth 4.5" (114.3 mm) Specifications...
Page 280 SOLIX 12 Control Head Measurements SOLIX 12 In-Dash Mount (separate purchase required) Width 13.8" (350.5 mm) Height 8.2" (208.5 mm) Depth 1.2" (30.5 mm) SOLIX 12 Gimbal Mount Width 13.8" (350.5 mm) Height 8.7" (221 mm) Depth 4.8" (122 mm) Specifications...
Page 281 SOLIX 15 Control Head Measurements SOLIX 15 In-Dash Mount (separate purchase required) Width 16.5" (419.9 mm) Height 10.1" (256.5 mm) Depth 1.2" (30.5 mm) SOLIX 15 Gimbal Mount Width 16.5" (419 mm) Height 10.5" (266.7 mm) Depth 4.8" (122 mm) Specifications...
Page 282: Statements And Acknowledgements
TATEMENTS AND CKNOWLEDGEMENTS ENVIRONMENTAL COMPLIANCE STATEMENT: It is the intention of Johnson Outdoors Marine Electronics, Inc. to be a responsible corporate citizen, operating in compliance with known and applicable environmental regulations, and a good neighbor in the communities where we make or sell our products.
Page 283 Eufaula, AL 36027 *NOTE: A copy of the libxml++ software is not required to upgrade your fishing system. The Humminbird application software and control head include a separate service warranty. Please see humminbird.com and the separate warranty card included with your unit for details.
Page 284 Eufaula, AL 36027 *NOTE: A copy of the Linux operating system is not required to upgrade your fishing system. The Humminbird application software and control head include a separate service warranty. Please see humminbird.com and the separate warranty card included with your unit for details.
Page 285 Navionics WARNINGS: The electronic chart is an aid to navigation designed to facilitate the use of authorized government charts, not to replace them. Only official government charts and notices to mariners contain all information needed for the safety of navigation, and as always, the captain is responsible for their prudent use.
Page 286 Eufaula, AL 36027 *NOTE: A copy of the Qt software is not required to upgrade your fishing system. The Humminbird application software and control head include a separate service warranty. Please see humminbird.com and the separate warranty card included with your unit for details.
Page 287 State as examined and the product is compliant with Article 10(10) as it has no restrictions on putting into service in all EU member states. EU DECLARATION OF CONFORMITY: Hereby, Humminbird declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
Page 288: Contact Humminbird
ONTACT UMMINBIRD Contact Humminbird Customer Service in any of the following ways: Web site: humminbird.com E-mail: service@humminbird.com Telephone: 1-800-633-1468 Direct Shipping: Humminbird Service Department 678 Humminbird Lane Eufaula, AL 36027 USA Hours of Operation: Monday - Friday 8:00 a.m. to 4:30 p.m. (Central Standard Time) Social Media Resources: Facebook.com/HumminbirdElectronics...

This manual is also suitable for:

Solix si g1 Solix 2d g1

Humminbird SOLIX Series Operation Manual

Warnings

Introduction

The SOLIX Control Head

Power On/Off

Getting Started

The Home Screen

The Menu System

Views

Chart Overview

Introduction to Navigation

Navigation Menu Overview

Waypoints

Routes

Search

Tracks

Manage Your Navigation Data

Autochart LIVE Overview

Mosaic Live Overview

Autopilot Overview

Radar Overview

AIS and MARPA

AIS Overview

MARPA Targets

Sonar Overview

Sonar Overview

Side Imaging Overview

Down Imaging Overview

Use Cursor and Zoom in Sonar Views (2D, SI, DI)

Navigation in Sonar Views (2D, SI, DI)

Sonar Recording

Images Tool

Installation Information

Manage Your Control Head

Update Software

Specifications

Statements and Acknowledgements

Contact Humminbird

Quick Links

Need help?

Questions and answers

Related Manuals for Humminbird SOLIX Series

Summary of Contents for Humminbird SOLIX Series

This manual is also suitable for:

Table of Contents
