MEGA LIVE IMAGING TARGETLOCK
INSTALLATION GUIDE
532889-3EN_A
1

Advertisement

Table of Contents
loading

Related Manuals for Humminbird MEGA Live

Summary of Contents for Humminbird MEGA Live

  • Page 1 MEGA LIVE IMAGING TARGETLOCK INSTALLATION GUIDE 532889-3EN_A...
  • Page 2 Always operate the boat at very slow speeds if you suspect shallow water or submerged objects. WARNING! The electronic chart in your Humminbird unit is an aid to navigation designed to facilitate the use of authorized government charts, not to replace them.
  • Page 3 APEX™, HELIX®, Humminbird®, MEGA 360 Imaging™, MEGA Live Imaging™, Minn Kota®, SOLIX®, TargetLock™, Ultrex™ are trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc.

  • Page 4: Table Of Contents

    5. Install the Landscape Mode Mount ..........13 6. Test the MEGA Live Views ............17 7.
  • Page 5 1. Confirm Connections ..............43 2. Set Up MEGA Live Imaging on the Control Head ........46 3.

  • Page 7: Introduction

    • Powering Off Before proceeding with this installation, the Humminbird control head and Minn Kota® Ultrex trolling motor should be installed. The MEGA Live Imaging transducer can be connected directly to the control head or to a Humminbird Ethernet Switch (optional, separate purchase required) for networking.

  • Page 8: Supplies

    APEX or SOLIX fish finder. In addition to the cables permanently attached to the transducer, this includes two extension cables (a 10' MEGA Live power cable and a 20' Ethernet cable) to allow for quick-disconnect. To connect the Ethernet to a HELIX control head, you will need to purchase an ethernet adapter cable.

  • Page 9: Update Software

    Update Software Your control head model may need a software update to work with the MEGA Live Imaging transducer. We recommend that you read the following section completely before starting any software updates. NOTE: It is important to install the latest software update on your control head to enable all MEGA Live Imaging TargetLock features.

  • Page 10: Update Control Head Software With An Sd Card

    Update Control Head Software with an SD Card You will need an SD or microSD card (depending on your control head model). WARNING! Humminbird is not responsible for the loss of data files (waypoints, routes, tracks, groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the unit’s hardware or software.

  • Page 11: Update Accessory Software With An Sd Card

    5. Power on your Humminbird control head. Start Normal mode. 6. APEX/SOLIX: Select the Files tool. From the Software Update tab, scroll to MEGA Live on the Accessories list. Confirm that the most current software version is selected from the list, and select Install Now.

  • Page 12: Update Software With Fishsmart

    Update Software with FishSmart You can use the FishSmart App to download and push software updates directly to your Humminbird control head or accessory. NOTE: It is important to install the latest software update on your control head to enable all FishSmart features. For the latest software update, visit our Web site at humminbird.com.

  • Page 13: Install The Mega Live Imaging Targetlock

    Install the MEGA Live Imaging TargetLock Use the following instructions to install the MEGA Live Imaging TargetLock transducer on your Minn Kota Ultrex trolling motor. It is important to read the instructions completely and understand the mounting guidelines before you start the installation.

  • Page 14: View The Installation Video

    1. View the Installation Video Humminbird recommends viewing our installation video before you begin installation of your MEGA Live TargetLock. Use the following QR code to access the video, as well as our FAQ (Frequently Asked Questions). Installation Video QR Code 2.

  • Page 15: Install The Mounting Plate

    4. Determine if you must uninstall and reinstall your trolling motor stabilizer. You will need to uninstall and reinstall the stabilizer if: • You are installing your MEGA Live on the starboard side of your trolling motor. • You are installing the dual mount accessory (for MEGA Live and MEGA 360 installation, separate purchase required).

  • Page 16: Mega Live Mounting Plate

    A. MEGA Live Mounting Plate (for MEGA Live installation only) The plate can be mounted on the left or right side of the trolling motor. If you have a motor stabilizer already installed on one side of the motor, install the mounting plate on the opposite side.

  • Page 17: Mega Live Dual Mounting Plate (For Use With Mega 360)

    1. If you have a trolling motor stabilizer installed, you will first need to uninstall it. You will reinstall it after you have completed installation of your MEGA Live. See the installation guide that was included with your trolling motor or visit www.minnkotamotors.com for instructions.

  • Page 18: Install The Control Box

    (see illustration Installing the Control Box). 2. Install the six (6) included 8-32 screws through the plate and into the control box using the provided 9/64" Allen wrench. Hand tighten only! Installing the Control Box MEGA Live Installation...

  • Page 19: Install The Landscape Mode Mount

    Compressing the Lock Washer), and then tighten an additional 1/4 turn. Hand tighten only! WARNING! The screw and lock washer MUST be fully tightened. Failure to do so may result in the transducer detaching from the shaft mount in the water. MEGA Live Installation...
  • Page 20 4. Connect the transducer to the Landscape Mode mount (see the illustration Connecting the Landscape Mode Mount to the Transducer). The ratchets are keyed. The ribs on the Landscape Mode mount ratchet should align with the marks on your transducer. Connecting the Landscape Mode Mount to the Transducer MEGA Live Installation...
  • Page 21 (see the illustration Connecting the Cable Cover). 8. Secure the cable cover with the four (4) included 8-32 screws, using the provided 9/64" Allen wrench. Hand tighten only! MEGA Live Installation...
  • Page 22 Connecting the Cable Cover The molded anchor point is keyed. MEGA Live Installation...

  • Page 23: Test The Mega Live Views

    6. Test the MEGA Live Views 1. Rotate the transducer by hand to test the Down, Forward and Landscape Mode views as illustrated in MEGA Live Views. Your trolling motor mount includes guides to help you position the transducer correctly (see the illustration MEGA Live Mode Guides).
  • Page 24 MEGA Live Views Down View Forward View Landscape Mode MEGA Live Installation...

  • Page 25: Connect The Shaft Assembly To The Mounting Plate

    Do not fully tighten. 2. Slide the bolts into the plate slots as shown in the illustration Connecting the Steering Housing Assembly. Connecting the Steering Housing Assembly 3. Hand-tighten the bolts using a 3/8" wrench. Hand tighten only! MEGA Live Installation...

  • Page 26: Install The Mega Live Targetlock Heading Sensor

    NOTE: Align the heading collar so that the raised section faces away from the MEGA Live transducer’s pinging element (instead of towards it) to ensure the arrow on the TargetLock heading sensor will point in the same direction as the MEGA Live.
  • Page 27 Connecting the Heading Collar and Mount Align the cables so that the TargetLock heading sensor cable is on top of the MEGA Live power and ethernet cables. Secure the heading collar and mount before securing the TargetLock heading sensor to the mount.

  • Page 28: Adjust The Transducer Height

    If the transducer is installed too close to the propeller, it will be damaged. Ensure there is at least 1" of clearance between the transducer and the propeller. MEGA Live damage caused by the transducer being installed too close to the trolling motor’s propeller is NOT covered by the product warranty.

  • Page 29: Reinstall The Motor Stabilizer

    10. Reinstall the Motor Stabilizer 1. If you removed your motor stabilizer prior to installing your Mega Live, reinstall it now through the MEGA Live plate (see the illustration Reinstalling the Motor Stabilizer) using the provided 5/16" screws with locking washers. It may be necessary to shorten your motor stabilizer.

  • Page 30: Install The Mega Live Imaging Targetlock Foot Pedal

    Install the MEGA Live Imaging TargetLock Foot Pedal Before mounting your MEGA Live Imaging TargetLock foot pedal, please give consideration to the following: • Examine your boat to ensure that you will not drill into any obstructions and that the hardware will be accessible for assembly.
  • Page 31 4. Once the base is installed, reattach the foot pedal to the base. Make sure the tabs on the pedal click into place and that the pedal is fully seated on the deck of the boat. MEGA Live Foot Pedal Installation...

  • Page 32: Install A Mega 360 (Separate Purchase)

    NOTE: The dual mounting plate (separate purchase) is required for this installation. See Install the MEGA Live Imaging TargetLock, Section 2B: MEGA Live Dual Mounting Plate for mounting plate installation instructions. 1. Prepare for Installation 1.

  • Page 33: Assemble The Mega 360 Mount

    • The pod should be submerged 6" (152.4 mm) below the waterline. The height may be adjusted, however, the pod must be mounted 1" (25.4 mm) off the tip of the propeller. 2. Assemble the MEGA 360 Mount 1. If your MEGA 360 will be mounted on the left side of the trolling motor, position the mount so the straight edge faces to the left as shown in the illustration.
  • Page 34 Installing the Screws onto the Mount 1" screw (1/4 - 20 x 1") bracket (straight edge on the left) 3. Align the left screw (left side installation) or right screw (right side installation) under the center hole of the dual mounting plate (see the illustration Securing the Mount and Plate).

  • Page 35: Install The Pod

    3. Install the Pod 1. Route the cables and up through the trolling motor mount and bracket. 2. Use an Allen wrench (not included) to install the (2) 10-32 x 9/16" socket bolts on the bracket where the pod shaft is installed. 3.

  • Page 36: Adjust The Pod Height

    4. Adjust the Pod Height 1. Deploy the Trolling Motor. 2. Loosen the socket bolts on the mount where the pod shaft is installed. Adjust the pod shaft up or down, so it meets the following height requirements: • The pod must be mounted approximately 6" (152.4 mm) below the waterline. •...
  • Page 37 3. Turn the pod shaft until the rounded end of the transducer points in the direction of travel. The centerline of the transducer should be parallel with the centerline of the boat. See the illustration Aligning the Transducer. Aligning the Transducer rounded part of transducer 4.

  • Page 38: Install The Collar Clamp

    5. Install the Collar Clamp After you have established the pod height is no closer than 1 inch from the tip of the propeller, install the collar clamp to prevent the trolling motor from hitting the transducer pod. 1. Apply anti-seize to the end of each 1" socket bolt (1/4-20 x 1"). 2.
  • Page 39 5. Use an Allen wrench (not included) to tighten the hardware just enough to keep the collar assembled. 6. Slide the collar up to the base of the BowGuard. 7. Use an Allen wrench (not included) to fully tighten the socket bolts until they are secure.

  • Page 40: Route The Cables And Connect Power

    WARNING! The power source must be turned off before you proceed with this installation. WARNING! Do NOT route your MEGA Live TargetLock cables where they can be cut, ripped, or pulled by the trolling motor articulating, rotating, or during stow and deploy.
  • Page 41 4. Secure the cables to the zip tie mount on your mounting plate using one of the included zip ties (see the illustration Securing the Cables to the Zip Tie Mount). Installing the Zip Tie Mount screw mount Securing the Cables to the Zip Tie Mount zip tie mount Cable Installation...

  • Page 42: Route The Mega Live Control Box Cables

    2. Route the MEGA Live Control Box Cables 1. If your MEGA Live is installed on the inboard (typically starboard) side of your trolling motor: Route the rest of the cables with your Ultrex trolling motor cables. Secure them with zip ties at the base of the pedal control sleeve (see illustration Routing the Control Box Cables) and along the trolling motor cables as needed.
  • Page 43 Routing the Control Box Cables first zip tie Avoid trolling motor pinch point. Allow for full movement of the trolling motor. zip tie mount Inboard (Typically Starboard) Installation Cable Installation...
  • Page 44 first zip tie Allow for full movement p-clip of the trolling motor. Avoid trolling motor zip tie mount pinch point. Outboard (Typically Port) Installation Cable Installation...
  • Page 45 2. Ethernet: Insert the Ethernet Cable into the Ethernet port on the control head. Hand-tighten the screw nut. NOTE: If you have a HELIX Series unit with Ethernet, connect the Ethernet Cable to an Ethernet Adapter Cable (AS EC QDE, separate purchase required). Insert the connector into the Ethernet port on the control head or cable tray.

  • Page 46: Route The Mega 360 Cables (Separate Purchase)

    (y-cable). See Compatibility for the list of cables, and visit our Web site at www.humminbird.com/support/ installation-diagrams to view the wiring diagrams. 2. Route the cables to the side of the trolling motor, over the bow, to the chosen connection locations in Section 1: Prepare for Installation.

  • Page 47: Connect Power

    The MEGA Live Imaging TargetLock must have adequate protection through the proper selection and installation of a 5A slow-blow fuse. NOTE: A 10' (3 m) power cable is included to supply power to the MEGA LIVE Imaging transducer. You may shorten or lengthen the cable using 12 gauge multi-stranded copper wire.
  • Page 48 2b. Battery Switch: Install the battery switch (not included) using the instructions provided with it. MEGA Live Imaging TargetLock: Install an inline fuse holder and a 5A slow- blow fuse (not included) for protection of the unit. MEGA 360: Install an inline fuse holder and a 1 Amp fuse (not included) for protection of the unit.

  • Page 49: Set Up The Control Head

    Manual). CAUTION! It is important to finish all installation connections before powering on the control head. It may take up to a minute for the MEGA Live Imaging transducer and other attached equipment to be detected by the control head.
  • Page 50 GPS receiver is detected, but it doesn’t have a GPS fix. NOTE: For additional system status, select Home > Settings > Network > Network Info. MEGA Live Imaging Transducer Connected (APEX/SOLIX) MEGA Live icon on the status bar MEGA Live...
  • Page 51 5. Press and hold the VIEW key. Select System > Accessory Test. Confirm that MEGA Live, MEGA Live TL and GPS + Heading Sensor are listed as Connected. It will take up to two minutes for the equipment to be detected.

  • Page 52: Set Up Mega Live Imaging On The Control Head

    Your HELIX control head will automatically detect and subscribe to MEGA Live Imaging. Use the following instructions to confirm that MEGA Live is selected in the Network Source Setup dialog box. It might take up to a minute for the equipment to be detected.

  • Page 53: Test Mega Live Imaging On The Control Head

    Imaging view will display on the Favorite Views widget. 2. Tap MEGA Live Imaging. 3. The sonar returns from the MEGA Live will begin to display on the MEGA Live View. Review the display for the following information and see the illustrations Reviewing the MEGA Live View.
  • Page 54 1. Press and hold the VIEW key. 2. Select Sonar > MEGA Live View. 3. The sonar returns from the MEGA Live will begin to display on the MEGA Live View. Review the display for the following information and see the illustrations Reviewing the MEGA Live View.
  • Page 55 (Forward) (Landscape) Control Head Setup...
  • Page 56 Tap the on/off button, or press the ENTER key, to turn Auto off. 3. Tap, or use the Joystick and Enter key, to select a MEGA Live Mode. When you manually change the MEGA Live mode, a message box will display reminding you to also change the transducer’s installation orientation.
  • Page 57 HELIX Series 1. X-Press Menu: With a MEGA Live Imaging View displayed on-screen, press the Menu key once. 2. Select MEGA Live Mode. 3. Press the RIGHT or LEFT Cursor keys to select a mode. When you manually change the MEGA Live mode, a message box will display reminding you to also change the transducer’s installation orientation.

  • Page 58: Pair The Targetlock Heading Sensor To The Control Head

    Repeat the procedure. NOTE: You can check the MEGA Live Device List to confirm that the TargetLock Heading Sensor is paired. Select Home > Settings > CHIRP Sonar > Device List.

  • Page 59: Pair The Foot Pedal To The Control Head

    APEX/SOLIX Series 1. Press the HOME key. 2. Select Settings > CHIRP Sonar > MEGA Live > Pair TargetLock Foot Pedal. 3. On your foot pedal, press and hold the Left button and the Right button at the same time until the LEDs at the top of the pedal begin to scroll. Then release the buttons.
  • Page 60 NOTE: You can check the MEGA Live Device List to confirm that the foot pedal is paired. Select Home > Settings > CHIRP Sonar > Device List. HELIX Series 1. Main Menu: On your control head, press the MENU key twice.

  • Page 61: Calibrate Your Mega Live Imaging Targetlock

    APEX/SOLIX Series 1. Press the HOME key. 2. Select Settings > CHIRP Sonar > MEGA Live > Calibrate TargetLock Heading Sensor. 3. Your MEGA Live Imaging TargetLock will begin calibration. A message will display on your control head when calibration is complete.

  • Page 62: Confirm The Humminbird Gps Heading Sensor Operation (Optional)

    7. Confirm the Humminbird GPS Heading Sensor Operation (Optional) It is important to confirm that the optional Humminbird GPS Heading Sensor is installed correctly by reviewing the heading digital readout (for Minn Kota Heading Sensor instructions, see your i-Pilot Link Owner’s Manual).
  • Page 63 Confirming the Heading Digital Readout (APEX/SOLIX) course heading (heading sensor required) HELIX Series 1. Main Menu: Press the MENU key twice. 2. Select the Chart tab > North Reference > Magnetic. 3. Press the EXIT key. 4. Select the Setup tab > Select Readouts (G3N models) or Edit Data Boxes (G4N models).
  • Page 64 Adjust (G3N): To adjust the zero point of the GPS Heading Sensor, select Main Menu > Navigation tab > Heading Offset. Press the RIGHT or LEFT Cursor keys to adjust the setting. Adjust (G4N): To adjust the zero point of the GPS Heading Sensor, select Main Menu >...

  • Page 65: Confirm The Baud Rate (For Devices Connected To Sensor Pigtail Only)

    9. Set up the Network After you have confirmed all connections, the MEGA Live Imaging transducer is ready to use on the water. Proceed to your MEGA Live Operations Manual to set up the GPS source, temperature source and additional sonar sources.

  • Page 66: Power Off

    Travel with the MEGA Live Transducer Installed The MEGA Live transducer must not hit the deck, base, or any objects. This is critical during transport. Check the tension of the trolling motor bracket after initial use and periodically thereafter to ensure that the installation remains stable.

  • Page 67: Maintenance

    Maintenance Your Humminbird fish finder is designed to provide years of trouble free operation with very little maintenance. Use the following procedures to ensure your Humminbird continues to deliver top performance. Control Head Maintenance It is important to consider the following precautions when using your Humminbird control head: •...

  • Page 68: Transducer Maintenance

    • Check the stability of the trolling motor mount after initial use and periodically thereafter to ensure that the installation remains stable. • If your boat will be in long-term storage, remove the MEGA Live Imaging transducer and store it in –40°F to 158°F (–40°C to 70°C), dry conditions.

  • Page 69: Troubleshooting

    Ensure that the trolling motor batteries are properly isolated from the rest of the boat’s wiring. 3. If your MEGA Live is now working, there is likely a wiring issue. Check the wiring on the starting and house batteries, if present. If using a house battery system, ensure that it is grounded to the boat’s chassis ground terminal (see...

  • Page 70: Fishing System Doesn't Power Up

    Fishing System Defaults to Simulator with a Transducer Attached In addition to the MEGA Live Imaging accessory transducer, you will have a standard Humminbird transducer connected to the control head. A connected and functioning transducer with built-in temperature will cause the newly started Fishing System to go into Normal operating mode automatically.

  • Page 71: Finding The Cause Of Noise

    Finding the Cause of Noise Electrical noise usually affects the display with streaks or repetitive patterns on the view. One or more of the following sources can cause noise or interference: Possible Source of Noise Isolation Other electronic devices Turn off any nearby electronic devices to see if the problem goes away, then turn them on one at a time to see if the noise re-appears.

  • Page 72: Specifications

    Operating Temperature ......... 32°F to 158°F (0°C to 70°C) Storage Temperature ........-40°F to 158°F (-40°C to 70°C) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 73 ROHS STATEMENT: Product designed and intended as a fixed installation or part of a system in a vessel may be considered beyond the scope of Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 74 Notes...

  • Page 75: Contact Humminbird

    Contact Humminbird Contact Humminbird Technical Support through our Help Center at https:// humminbird-help.johnsonoutdoors.com/hc/en-us or in writing to the address below: Humminbird Service Department 678 Humminbird Lane Eufaula AL 36027 USA Social Media Resources: Facebook.com/HumminbirdElectronics Twitter.com (@humminbirdfish) Instagram.com/humminbirdfishing YouTube.com/humminbirdtv Contact Humminbird...
