P C
ROPELLER ONTROLS
A manual function is where the operator takes full control of the function, such as manually steering the motor or adjusting the
propeller speed.
The propeller can be controlled from the X-Press Remote. You can steer, increase or decrease speed, and start Cruise Control from
the X-Press Remote.
WARNING! If you use the X-Press Remote to steer, you are taking manual control, and the current navigation mode will be
canceled (with the exception of recording an iTrack).
WARNING! Watch for a turning propeller and be prepared for boat movement when working with each i-Pilot Link navigation
mode. The propeller will automatically turn on when i-Pilot Link navigation modes are engaged, even if the engagement is
accidental. A turning propeller can cause injury.
Propeller Icon
i-Pilot Link Propeller On - When the i-Pilot Link propeller is turned on, it is ready to be used for i-Pilot Link navigation.
Icons will display in the i-Pilot Link data bar indicating the current status of the i-Pilot Link prop (on, on and rotating,
off). See Display Digital Readout Boxes.
You will have to manually turn on the i-Pilot Link prop to start i-Pilot Link navigation; except when starting navigation
to a Spot-Lock from the Go To menu, in which case the propeller will automatically turn on to start navigation.
i-Pilot Link Propeller On and Rotating - The i-Pilot Link propeller is currently being used for i-Pilot Link navigation.
i-Pilot Link Propeller Off - If you selected Prop Off for the Arrival Mode, the i-Pilot Link propeller will automatically turn
off after the destination has been reached during i-Pilot Link navigation. See Configure i-Pilot with the Control Head:
Set the Arrival Mode.
You will have to manually turn off the i-Pilot Link prop when canceling AutoPilot navigation.

Start or Stop the Propeller

The propeller must be started to start navigation with the i-Pilot Link. You can start the propeller manually each time you start
i-Pilot navigation, or you can set the propeller to turn on automatically when i-Pilot Link navigation is initiated (see Configure i-Pilot
with the Control Head: Turn on/off Prop Auto-On).
WARNING! Spot-Locks and Cruise Control will turn on the propeller as soon as they are engaged, regardless of the Prop Auto-On
setting.
Start or Stop the Propeller
Use the following instructions to start/stop the propeller manually using the X-Press Remote on the control head.
Touch Screen
1. Open the X-Press Remote: Tap the top, right corner of
the status bar. Tap the remote.
2. Tap the propeller button.
Yellow = On, Gray = Off.

Propeller Controls

Keypad
1. Open the X-Press Remote: Press the POWER key.
Select the remote.
2. Select the propeller button. Press the CHECK/ENTER
key.
Yellow = On, Gray = Off.
46
(X-P R )
RESS EMOTE
