- Page 1 Ethernet Networking Ethernet Networking Installation & Operations Manual Installation & Operations Manual 531906-1EN_B Unit 1 Unit 2 HUMMIN IRD ® ETHERNET...
- Page 2 Always operate the boat at very slow speeds if you suspect shallow water or submerged objects. WARNING! The electronic chart in your Humminbird® unit is an aid to navigation designed to facilitate the use of authorized government charts, not to replace them.
- Page 3 Please read the manual carefully in order to understand the full capabilities of your model. NOTE: The Ethernet accessory is compatible with many Humminbird® models, and every effort has been made to note the differences between the models and functions throughout this manual.
-
Page 4: Table Of Contents
Table of Contents Introduction 1. Installing an Ethernet Connection 2. Powering On 3. Configuring the Ethernet Network Configuration Overview Network Menu Tab ..........10 Customize the Unit Name Open the Network Source Setup Dialog Box Sonar Source Overview... - Page 5 Fishing System Doesn’t Power Up........29 Fishing System Defaults to Simulator with a Transducer Attached..30 Humminbird® Accessories...
-
Page 6: Introduction
Introduction This manual will guide you through the following network setup instructions: 1. Connect two Humminbird® units together 2. Power On 3. Configure your Humminbird® Ethernet Network 4. Share Waypoints Alarms, navigation, sonar data, and the menu system are all affected by the Ethernet network settings. -
Page 7: Installing An Ethernet Connection
1. Installing an Ethernet Connection If your Humminbird® control head has a built-in Ethernet connector, the unit can be connected to the Ethernet network. When you connect the units together, data is shared between the two units. Before you start, please note that the Ethernet network installation has the following requirements: •... - Page 8 2. To install the Ethernet cables, see the connection information for your network configuration as follows: • Two 700 Series™ Units: see Section A. • One 700 Series™ Unit & One 800/900/1100 Series™ Unit: see Section B. • Two 800, 900, or 1100 Series™ Units: see Section C.
- Page 9 Ethernet slot on the 700 Series™ cable collector. Repeat this step for the second AS EC QDE cable. NOTE: The 700 Series™ control head uses a cable collector for the Quick Disconnect Mount and the In-Dash Mount. See your control head installation guide for details.
- Page 10 3. Connect the AS EC QDE cable connector to the AS EC 10E cable connector. 4. Hand-tighten the screw nut(s) on each cable to secure the connection. Hand-Tightening the Screw Nut Screw The connector is keyed to prevent incorrect installation. C.
- Page 11 800/900 Series™ (rear view) Ethernet Port 1100 Series™ (rear view) Installation...
-
Page 12: Powering On
2. Powering On When you have installed an Ethernet network, the power on process is the same as powering on a single control head, however, your transducer connections will determine how the control head starts normal operation. It is important to set up your network to use the correct sources. If there is a transducer connected to only one of the control heads, and you intend to share the transducer on the network, power on the control head with the connected transducer first. -
Page 13: Configuring The Ethernet Network
3. Configuring the Ethernet Network Set up your Humminbird® Ethernet Network using the following instructions, including these topics: 1. Network Setup Overview 2. Customize the Unit Name 3. Select Data Sources (transducer, temperature, GPS receiver) for each control head 4. Understand the Shared and Local Menu Settings 5. - Page 14 Example of a Network Configuration GPS (Shared) Note that the Speed Digital Readout is the same on both control head views 1198c SI 788ci HD Ethernet Speed Digital Readout Speed Digital Readout DualBeam PLUS™ Transducer (Local) It will only report data Side Imaging®...
-
Page 15: Network Menu Tab
Network Menu Tab When units are connected on the network, the Network menu tab is added to the Main Menu system. The Network menu tab includes the following menu options: Unit Name: Displays the name of the control head. The default Unit Name is based on its model number and serial number. -
Page 16: Customize The Unit Name
Customize the Unit Name Each control head is assigned a Unit Name, which is based on its model number and serial number. The unit name is also displayed next to a source name in the Network Source Setup dialog box so you can see where the source is connected. -
Page 17: Open The Network Source Setup Dialog Box
Open the Network Source Setup Dialog Box The Network Source Setup dialog box displays all of the sources connected to the network. The sources may be shared on the network or operating locally with their connected control head. Open the Network Source Setup Dialog Box 1. -
Page 18: Sonar Source Overview
Sonar Source Overview When you select a new transducer source, the alarms, menu settings, view rotation, and digital readouts will automatically update on the control head. • Menu Settings: If the sonar source is shared, the control heads will synchronize menu settings (Shared), while other menu settings will continue to operate individually (Local) on each control head. -
Page 19: Select A Sonar Source
Local Sonar Menu Settings 83 kHz Sensitivity Quad Layout Sonar Colors 455 kHz Sensitivity RTS Window™ Ping Rate Bottom Lock Sensitivity (Down) SI Range Bottom Range SI Colors SwitchFire™ Bottom View SI Enhance Transducer Select Chart Speed SI Sensitivity Upper Range Depth Lines SI Side Water Type... - Page 20 4. Select: Press the RIGHT Cursor key. The check mark indicates that the source is being used by the control head. 5. Save: Press the EXIT key twice to close the dialog box. Network settings are saved even after the unit is powered off. Local Setup (default): To use separate transducers for each control head, repeat steps 1 - 5 on each control head until you’ve set a transducer for each unit.
-
Page 21: Change The Sonar Source
Network Source Setup dialog box. See Select a Sonar Source for details. Finding the Sonar Source (700 Series™) If the control head cannot detect the shared transducer, follow the on-screen instructions to change the sonar source. Press the LEFT Cursor key to select No, or press the RIGHT Cursor key to select Yes. -
Page 22: Temperature Source Overview
Temperature Source Overview When you select a new temperature source, the alarms, menu settings, view rotation, and digital readouts will automatically update on the control head. • Menu Settings: If the temperature source is shared, the control heads will synchronize menu settings (Shared), while other menu settings will continue to operate individually (Local) on each control head. -
Page 23: Select A Temperature Source
Select a Temperature Source Temperature sources can be detected from a transducer’s built-in temperature feature or from optional-purchase temperature/speed accessories connected to the network. • Default: When you first set up the network, the control head will automatically choose the locally connected temperature source to display digital readouts on the screen. - Page 24 2. Select the tab for T1, T2, T3, or T4: Press the RIGHT or LEFT Cursor keys. Each tab represents a digital readout position on the screen. NOTE: The temperature readout positions may vary with the Humminbird® model. See the Views section and Select Readouts section of your Humminbird® Operations Manual for more information.
- Page 25 6. Save: Press the EXIT key twice to close the dialog box. Network settings are saved even after the unit is powered off. Local Setup: To use separate temperature sources for each control head, repeat steps 1 - 6 on each control head until you’ve set a temperature source for each unit and each digital readout.
-
Page 26: Change The Temperature Source
Temperature Graph 1100 Series™ Temperature Graph (Source: Temp. 1) Red marks indicate where the temperature source changed. Change the Temperature Source To change the temperature source after the network has been configured, open the Network Source Setup dialog box to change the temperature sources at any time (see Select a Temperature Source). - Page 27 Temperature Source Lost 1100 Series™ The Temp 2 (T2) Source is not detected on the network. Temperature Sources...
-
Page 28: Gps And Sharing Waypoints Overview
GPS and Sharing Waypoints Overview When you select a new GPS source, the position, menu settings, view rotation, and digital readouts will automatically update on the control head. To view waypoint data on the network, it is important to understand the GPS source and how to share waypoint data. -
Page 29: Select A Gps Source
Select a GPS Source When you power on the network for the first time, the control head will automatically choose the connected or internal GPS receiver to provide data to the control head. Use the instructions below to select a GPS source for your control head. - Page 30 Selecting a GPS Source GPS tab Selected The check mark The control indicates the head detects source is used by all of the GPS the control head. sources in the network. Empty The empty box indicates the GPS data is available but not selected.
-
Page 31: Change The Gps Source
See Select a GPS Source to select another GPS Receiver in the network. Finding the GPS Source 700 Series™ If the control head cannot detect the shared GPS Receiver set in the network, follow the on-screen instructions to change the GPS source. Press the LEFT Cursor key to select No, or press the RIGHT Cursor key to select Yes. -
Page 32: Share Waypoints
Share Waypoints To share waypoints on the network, turn on Share Waypoints on each control head. You can then observe the following: • When a waypoint is marked on one control head, the waypoint will also be displayed on the other control head. If the waypoint is saved, it will be saved to the local control head where it was marked. -
Page 33: Restore Defaults (Setup Menu Tab)
Restore Defaults (Setup Menu Tab) If you choose to restore defaults on a Humminbird® control head, it is important to note that the menu settings, including your saved network settings, will be reset to their factory defaults. See your Humminbird® control head operations manual for more information. -
Page 34: Troubleshooting
Troubleshooting Before contacting the Humminbird® Customer Resource Center, please read the following section. Taking the time to review these troubleshooting guidelines may allow you to solve a performance problem yourself, and therefore avoid sending your unit back for repair. Fishing System Doesn’t Power Up If your Fishing System doesn’t power up, use the installation guide that is... -
Page 35: Fishing System Defaults To Simulator With A Transducer Attached
Fishing System Defaults to Simulator with a Transducer Attached A connected and functioning transducer will cause the newly-started Fishing System to go into Normal operating mode automatically. If, when you power up the Fishing System, it goes into Simulator mode automatically, even though a transducer is already connected, this means that the control head is not detecting the transducer. -
Page 36: Humminbird® Accessories
Universal Sonar 2 features new temperature sensing and the performance of DualBeam PLUS™ technology (available with all Humminbird® DualBeam PLUS™ models). An expanded view and greater bottom detail gives you a totally new perspective of the water below, along with optimal sonar performance to help you find fish. - Page 37 System Modules and you’ll have a network that lets you share digital data around the boat. It’s a simply, clearly, better networking solution! Humminbird’s AS WX 1 weather accessory provides anglers with access to continuously-updating weather conditions. The AS WX 1 uses sophisticated...
