Humminbird i-Pilot Link Operation Manual page 104

2. Set the Contour Offset
You can set Contour Offset to maintain a set distance from a contour line. Contour Offset is a distance setting only, and does not
measure water depth. Input the Contour Offset based on your knowledge of the water depth in your current area.
If you have an AutoChart ZeroLine Map Card, and want to navigate along a bank or shoreline, use Contour Offset to maintain a safe
distance from the shoreline.
Contour Offset can be adjusted while Follow the Contour navigation is in progress by selecting Contour Offset from the Go To menu.
Touch Screen
1. From the Cursor menu, select Go To.
2. Select Follow the Contour.
3. Select Contour Offset. Drag the slider, or press and
hold the slider, to adjust the setting.
To remove the offset, set the offset to 0 (off).
WARNING! Contour Offset does NOT account for changes in water depth. It is important to be aware of depth variations in your
current location and selected navigation route, and adjust the Contour Offset as needed.
navigation option 1
(orange)
navigation option 2
(purple)
Adjust the slider to set
the Contour Offset.
navigation option 1
(orange)
Press and Hold OR Drag
Follow the Contour
Setting the Contour Offset (ONIX)
to Adjust Slider
Keypad
1. Press the GO TO key.
2. Select Follow the Contour.
3. Select Contour Offset. Turn the Rotary dial, or press
and hold the ENTER key, to adjust the setting.
To remove the offset, set the offset to 0 (off).
OR
Select
104
shallow water highlight
(red)
land
cursor at selected
contour line
navigation option 2
(purple)
contour line
depth markers
Turn to Adjust the Setting
