  • Page 1 T24 Telemetry User Manual mantracourt.com Wireless Telemetry...

  • Page 2: Table Of Contents

    Battery and Radio Levels Advanced ..............................34 Radio Settings ......................................35 Radio Settings Advanced ..................................36 Save and Restore ..................................... 37 Transmitter Modules ............................... 38 T24-ACM-SA, T24-ACMi-SA, T24-ACMm-SA, T24-SAe, T24-SAi ..................38 Overview ......................................... 38 Order Codes ......................................38 T24-SAe ......................................38 T24-SAi ........................................ 38 T24-ACM-SA .....................................
  • Page 3 T24-ACMi-SA ....................................52 T24-ACMm-SA ....................................52 Antennas ......................................... 52 T24-SAi ........................................ 52 T24-SAe ......................................52 T24-ACM-SA, T24-ACMi-SA, T24-ACMm-SA ........................52 Specification ......................................53 Radio Range ...................................... 54 T24-ACM-SAf, T24-ACMi-SAf, T24-ACMm-SAf, T24-SAfe, T24-SAfi .................. 55 Overview ......................................... 55 Order Codes ......................................55 T24-SAfe ......................................
  • Page 4 Calibration by Certificate ................................79 Calibration Advanced ..................................80 Advanced Settings..................................81 Enclosure & Mounting ..................................82 T24-VAe, T24-VAi ................................... 82 T24-ACM-VA ....................................82 T24-ACMi-VA ....................................82 T24-ACMm-VA ....................................82 Antennas ......................................... 83 T24-VAi ....................................... 83 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 5 Overview ....................................... 101 Order Codes ......................................101 T24-TAe ......................................101 T24-TAi ......................................101 T24-ACM-TA ....................................101 T24-ACMi-TA ....................................101 T24-ACMm-TA ....................................101 Connections ......................................102 T24-TAe, T24-TAi ..................................102 Power ......................................102 Sensor ......................................102 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 6 Connecting T24-BB1 ................................117 Sensor ......................................117 Shield Connections (All Enclosures) ............................118 Configuration ...................................... 119 Data Rates and Quality ................................119 Input / Output Configuration ..............................121 Calibration by Certificate ................................123 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 7 Advanced Settings..................................143 Enclosure & Mounting ..................................144 T24-PAe, T24-PAi ..................................144 T24-ACM-PA ....................................144 T24-ACMi-PA ....................................144 T24-ACMm-PA ....................................144 Antennas ....................................... 145 T24-PAi ......................................145 T24-PAe ......................................145 T24-ACM-PA, T24-ACMi-PA, T24-ACMm-PA ........................145 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 8 Order Codes ......................................174 T24-HS ......................................174 Connections ......................................174 Power ......................................174 Quick Start......................................175 Connecting Power ..................................175 T24-HS ......................................175 Transmitter Module ................................175 Pairing ....................................... 175 Operation ......................................176 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 9 Power ......................................205 Operation ......................................206 View readings ....................................206 Keys ........................................206 Indicators ......................................206 Errors ........................................207 Special Modes ....................................207 Transmitter Module Configuration ............................208 Configuration ...................................... 209 Display Format ....................................209 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 10 Relay Operation Settings ................................233 Operation and Hysteresis Settings ............................ 234 Relay Settings Advanced ................................235 Alarm Settings ....................................236 Enclosure & Mounting ..................................237 Antennas ....................................... 237 Specification ......................................238 Radio Range ....................................238 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 11 MODBUS Communication................................. 260 Control Registers ..................................260 Commands....................................260 Data Tag Holding Registers ..............................261 Value & Status Registers ............................... 261 ASCII Communication ................................. 262 Commands....................................263 Configuration ...................................... 264 General Settings .................................... 264 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 12 T24-RDC-1, T24-RDC-2, T24-RDC-5, T24-RDC-10, T24-RDC-200 ..................298 Overview ....................................... 298 Order Codes ......................................299 T24-RDC-1, T24-RDC-2, T24-RDC-5, T24-RDC-10, T24-RDC-200 ................299 Connections ......................................300 Power ......................................300 LED Indicators .................................... 301 Digital Input ....................................302 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 13 Mobile Service Provider SMTP Servers ..........................344 Other “Free” SMTP Servers ............................... 344 Your SMTP server ..................................344 Web Based Relaying SMTP server............................344 SMTP Server Providers................................344 Enclosure & Mounting ..................................345 Antennas ....................................... 345 Specification ......................................346 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 14 Overview ....................................... 371 Order Codes ......................................371 T24-BSu ......................................371 T24-BSue ......................................371 T24-BSi ......................................371 T24-BSd ......................................371 Addressing ......................................371 Connections ......................................372 T24-BSu, T24-BSue & T24-BSd ............................... 372 T24-BSi ......................................372 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 15 T24-BC1 ........................................389 Overview ....................................... 389 Physical Connections ..................................389 Specification ......................................389 Example Batteries ....................................390 VARTA LIP653450 ..................................390 VARTA LIC18650 ................................... 390 UBC 581730 ....................................390 PP1 & SP1 ......................................... 391 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 16 Mounting Information ................................407 Antenna Position................................... 407 Environmental Protection ................................407 Mounted Display Type ..................................408 Dimensions ...................................... 408 Opening the Case ..................................409 Mounting Information ................................409 Antenna Position................................... 409 Environmental Protection ................................409 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 17 Voltage Source................................. 423 NPN Open Collector ..............................423 PNP Open Collector 5V Powered Sensor ......................423 T24-ACM-PA ....................................423 Power ....................................... 423 Sensor ...................................... 424 T24-ACMi-PA ..................................... 425 Power ....................................... 425 Sensor ...................................... 425 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 18 CE ..........................................448 IC ..........................................449 FCC .......................................... 450 Appendix I - Worldwide Regional Approvals ..........................451 Important Note ....................................451 Appendix J - Declaration of Conformity ............................452 Appendix K - Warranty ..................................453 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 19: Introduction / Overview

    The flexible transmission rates and low power usage allows for long battery life for remote modules. Free Toolkit software provides simplified configuration of modules and other free software provides logging and visualisation functionality for Windows PCs. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 20: Navigating This Manual

    Line Tensiometer T24-LT1 Base Stations T24-BSi T24-BSu T24-BSue T24-BSd Repeaters T24-AR Receivers T24-HS T24-HA T24-HR T24-AO1 T24-AO1i T24-RM1 T24-SO T24-GW1 T24-LD1 T24-PR1 T24-RDC T24-DWS T24-HLT Power Supplies T24-BC1 Antennas T24-ANTA T24-ANTB T24-ANTC T24-ANTD T24-ANTE Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 21: T24 Telemetry Basic Principles

    A group key is defined by the user and is up to 15 alphanumeric characters. Group keys were introduced in v3.0 radio firmware in March 2015. New radio modules will work with older radio modules but group keys cannot be used. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 22: Configuring Multiple Modules To Use The Same Radio Settings

    The last mode is sleep. Modules can be sent to sleep by other modules or they can go to sleep themselves when their messages are no longer being used. See Sleep Delay Settings later. When sleeping, the modules can be awakened on demand by other modules or software via the base station. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 23: Transmitter Module Sleep Delay Settings

    Transmitter module. In this case no configuration mode is required so the Transmitter module simply continues to operate in normal mode but with altered radio settings. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 24: Soft Pairing

    So if there is a requirement that recorded sets of readings are within a certain time of each other, then that time is the maximum message interval that should be set for the Transmitters regardless of the actual log interval of the software (Which should always be greater than the Transmitter message interval). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 25: Bandwidth

    This is a simple way to break down modules into smaller groups and control what messages get repeated. Changing the repeater subgroup is not normally necessary unless the bandwidth is very full due to either many Transmitter modules being present or very fast transmissions from modules. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 26: T24 Toolkit

    (T24-BSu or T24-BSue) then you just need to plug this into a USB socket on your PC. If you are using an alternative base station then please refer to the appropriate section of this manual. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 27: Common Toolkit Pages

    If no communications can be established the toolkit will remain on this page. You will need to check that the base station is powered and that it is connected to any converters correctly. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 28: Analyser

    The above charts show the traffic from a Wi-Fi network and it can be seen to be operating over channels 12 to 16 and it would be best (though not essential) to avoid using these channels. Although 16 channels are shown the T24 modules operate over radio channels 1 to 15. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 29: Channel Monitor

    Click a tab to change the radio channel the base station is operating on Clear List Clear all detected messages from the list Wake All Wake all modules on the current radio channel Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 30 When this button is clicked all modules on the same radio channel and group key will be woken before they are changed to the target radio channel. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 31: Home

    The base station radio settings will be changed to match those of the remote module. When the toolkit connects to a remote module to enable configuration it will usually inhibit the normal operational transmission of messages Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 32: Connecting To The Attached Base Station Module

    If you cannot get to the power supply of the remote module you can attempt to connect manually using Soft Pairing. Click the ‘Click Here’ link at the bottom of the page and follow the prompts. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 33: Information

    Channel Monitor page modules that are sleeping will also be listed Extended range radios were introduced to the T24 range in 2015. This indicates that the connected module has an extended range radio fitted. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 34: Battery And Radio Levels

    Items you can change: Low Battery Level Click this item to set the battery low level. Clicking the Advanced button will give more detailed information on the RSSI and CV levels of the received radio packets. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 35: Battery And Radio Levels Advanced

    CV is the correlation value and indicates how well the signal can be decoded. This ranges from 55 which is a poor quality signal and 110 which is an excellent signal. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 36: Radio Settings

    When radio settings are changed they do not take effect immediately but require a reset or power cycle. This button forces both the connected module and the base station to adopt the new changes and re-establishes a connection. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 37: Radio Settings Advanced

    Apply power to the remote module  The Toolkit will remain unchanged and still paired to whatever module or base station it was paired to but the remote module will have changed its radio settings. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 38: Save And Restore

    Click this button to open a file dialog window to allow you to select a filename and location of a previously saved file to load into the connected module. All configuration information including user calibration data will be overwritten. The file extension is tcf. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 39: Transmitter Modules

    T24 Transmitters are the modules that connect to a sensor or have an input signal applied and periodically transmit messages containing the value read from the sensor or input. T24-ACM-SA, T24-ACMi-SA, T24-ACMm-SA, T24-SAe, T24-SAi Overview The range of SA modules provide measurement from strain gauges and load cells.

  • Page 40: Connections

    As the measurement is four wire then as the cable length increases the voltage drops in the cable will have more of an effect on the factory mV/V calibration. The strain gauge measurement is bi-directional, i.e. tension & compression. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 41: T24-Acm-Sa

    Appendix D – Battery Selection Sensor The strain gauge input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +5 V Excitation +Signal -Signal -Excitation Shield Digital Output Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 42: T24-Acmi-Sa

    The input connections are accessed by lifting the right hand cover plate, this plate incorporates the T24-ACMi Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield - Excitation -Signal +Signal + 5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 43: T24-Acmm-Sa

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation -Signal +Signal +5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 44: Using Completion Resistors

    The diagram below shows how you should wire for full, half and quarter bridge configurations. Full Bridge Half Bridge Quarter Bridge Strain Element in Tension Strain Element in Compression Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 45: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 46: Configuration

    You can vary this to see the effect on battery life and noise free resolution. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 47 Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 48: Calibration

    For more complex calibrations which include linearization select three to nine points. Point 1 - 9 For each point enter the engineering unit value that you want the transmitter module to report at the applied input. i.e. 1.67 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 49 This will take you to a different screen. Advanced Clicking the advanced button will allow you to edit the gains and offsets for each available calibration point. This will take you to a different screen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 50: Calibration By Certificate

    (mV/V shown in this value screenshot) Engineering Units 1 - 9 Enter the required engineering unit output for the specified input value Calibrate Click this button to calculate and update the module calibration Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 51: Calibration Advanced

    When the best point has been found the Gain and Offset values from that point are applied to the mV/V value as follows. Value = (input * Gain) – Offset. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 52: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 53: Enclosure & Mounting

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-SA, T24-ACMi-SA, T24-ACMm-SA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 54: Specification

    Operating temperature range Storage Temperature ° Humidity Power Supply Typical Units Standby / Low Power Mode µA T24-SAe, T24-SAi, T24-ACMi-SA, T24-ACMm-SA Power Supply voltage Power Supply ripple mV ac pk-pk Normal Mode (1K Bridge) mA (1) T24-ACM-SA Power Supply voltage...

  • Page 55: Radio Range

    Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 56: T24-Acm-Saf, T24-Acmi-Saf, T24-Acmm-Saf, T24-Safe, T24-Safi

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-SAf Strain transmitter module mounted in small enclosure with screw terminals to connect external 3V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 57: Connections

    As the measurement is 4 wire the longer the cable the more inaccurate the measurement from the factory mV/V calibration will be due to voltage drops in the cable. The strain gauge measurement is bi-directional, i.e. tension & compression. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 58: T24-Acm-Saf

    For battery information please refer to Appendix D – Battery Selection Sensor The strain gauge input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +5 V Excitation +Signal -Signal -Excitation Shield Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 59: T24-Acmi-Saf

    The input connections are accessed by lifting the right hand cover plate, this plate incorporates the T24-ACMi Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield - Excitation -Signal +Signal + 5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 60: T24-Acmm-Saf

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation -Signal +Signal +5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 61: Using Completion Resistors

    The diagram below shows how you should wire for full, half and quarter bridge configurations. Full Bridge Half Bridge Quarter Bridge Low Reference High Reference Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 62: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 63: Configuration

    This capacity needs to be calculated from battery manufacturer’s data sheets to take into account that you can only use batteries down to 2.1 volts so in the case of twin AA cells this would be 1.05 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 64 Enter the resistance of the connected strain gauge in Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-SAf will be turned on and communicating. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 65: Zero Settings

    Enter a value which will be subtracted from the current nV/V value. Used to zero the value. Zero Now Zero the value now by placing the current value into the System Zero value. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 66: Data Provider Monitor

    Value is the value logged. The same button is used to stop the logging. View Last Log Once logging has stopped clicking this will open the log file in the program associated with the .csv file extension. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 67: Advanced Settings

    Allows turning on or off the application of a shunt calibration resistor to the bridge input. You must remember to turn this off before exiting the Toolkit software. nV/V Shows the output value so the effect of the Shunt Cal can be seen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 68: Enclosure & Mounting

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-SAf, T24-ACMi-SAf, T24-ACMm-SAf These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 69: Specification

    Pair D cells Constantly on 5.5 days Pair D cells 12 sessions per day of 5 minutes 4.5 months Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 70: T24-Acm-Va, T24-Acmi-Va, T24-Acmm-Va, T24-Vae, T24-Vai

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-VA Voltage transmitter module mounted in small enclosure with screw terminals to connect external 3V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 71: Connections

    This module is not reverse polarity protected! The maximum voltage is 3.6V! For battery information please refer to Appendix D – Battery Selection Sensor Voltage input connected as follows: SHLD -Excitation +5V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 72: T24-Acm-Va

    For battery information please refer to Appendix D – Battery Selection Sensor The voltage input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +5 V Excitation -Excitation Shield Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 73: T24-Acmi-Va

    The input connections are accessed by lifting the right hand cover plate, this plate incorporates the T24-ACMi Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield -Excitation -V in +V in + 5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 74: T24-Acmm-Va

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation -V in +V in +5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 75: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 76: Configuration

    You can vary this to see the effect on battery life and noise free resolution. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 77 Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 78: Calibration

    For more complex calibrations which include linearization select three to nine points. Point 1 - 9 For each point enter the engineering unit value that you want the transmitter module to report at the applied input. i.e. 1.67 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 79 This will take you to a different screen. Advanced Clicking the advanced button will allow you to edit the gains and offsets for each available calibration point. This will take you to a different screen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 80: Calibration By Certificate

    These modules are factory calibrated where 0% = 0 V and 100% = 10 V Engineering Units 1 - 9 Enter the required engineering unit output for the specified input value Calibrate Click this button to calculate and update the module calibration Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 81: Calibration Advanced

    This leads to a resultant gain and offset which is applied to the mV/V values as follows. Value = (input * Resultant Gain) – Resultant Offset. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 82: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 83: Enclosure & Mounting

    This module is fitted inside our medium enclosure. Please see Appendix A – Enclosures & Mounting – ACMi more information. T24-ACMm-VA This module is fitted inside our small enclosure. Please see Appendix A – Enclosures & Mounting – ACMm more information. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 84: Antennas

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-VA, T24-ACMi-VA, T24-ACMm-VA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 85: Specification

    Pair D cells Constantly on 4.5 months Pair D cells 12 sessions per day of 5 minutes > 9 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 86: T24-Acm-Ia, T24-Acmi-Ia, T24-Acmm-Ia, T24-Iae, T24-Iai

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-IA Current transmitter module mounted in small enclosure with screw terminals to connect external 3 V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 87: Connections

    5 Vdc to 18 Vdc source. In both cases you need to fit the JP1 power jumper to supply power to the transmitter module. When powered from the external DC source the LED will illuminate. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 88: Sensor

    For battery information please refer to Appendix D – Battery Selection Sensor The current input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +5 V Excitation -Excitation Shield Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 89: T24-Acmi-Ia

    The input connections are accessed by lifting the right hand cover plate, this plate incorporates the T24-ACMi Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield -Excitation -I in +I in + 5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 90: T24-Acmm-Ia

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation -I in +I in +5 V Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 91: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 92: Configuration

    You can vary this to see the effect on battery life and noise free resolution. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 93 Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 94: Calibration

    For more complex calibrations which include linearization select three to nine points. Point 1 - 9 For each point enter the engineering unit value that you want the transmitter module to report at the applied input. i.e. 1.67 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 95 This will take you to a different screen. Advanced Clicking the advanced button will allow you to edit the gains and offsets for each available calibration point. This will take you to a different screen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 96: Calibration By Certificate

    These modules are factory calibrated where 0% = 0 V and 100% = 10 V Engineering Units 1 - 9 Enter the required engineering unit output for the specified input value Calibrate Click this button to calculate and update the module calibration Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 97: Calibration Advanced

    This leads to a resultant gain and offset which is applied to the mV/V values as follows. Value = (input * Resultant Gain) – Resultant Offset. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 98: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 99: Enclosure & Mounting

    This module is fitted inside our medium enclosure. Please see Appendix A – Enclosures & Mounting – ACMi more information. T24-ACMm-IA This module is fitted inside our small enclosure. Please see Appendix A – Enclosures & Mounting – ACMm more information. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 100: Antennas

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-IA, T24-ACMi-IA, T24-ACMm-IA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 101: Specification

    Pair D cells Constantly on 4.5 months Pair D cells 12 sessions per day of 5 minutes > 9 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 102: T24-Acm-Ta, T24-Acmi-Ta, T24-Acmm-Ta, T24-Tae, T24-Tai

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-TA Temperature transmitter module mounted in small enclosure with screw terminals to connect external 3 V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 103: Connections

    This configuration allows use of bridge so that the resistance is cancelled out, so long 100 meters of cable. as the two lead resistances are accurately the same. This configuration allows up to 600 metres of cable. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 104: Wire

    For battery information please refer to Appendix D – Battery Selection Sensor The temperature sensor input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +Drive +Sense -Sense -Drive Shield Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 105: T24-Acmi-Ta

    Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield -Drive -Sense +Sense +Drive T24-ACMm-TA Power Power is supplied by connecting a 3 V supply to the There is no reverse polarity protection. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 106: Connecting T24-Bb1

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Drive -Sense +Sense +Drive Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 107: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 108: Configuration

    You can vary this to see the effect on battery life and noise free resolution. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 109 Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 110: Calibration

    The value you enter here will be subtracted from the measured temperature to create the transmitted temperature. The offset is entered in the same engineering units as selected above. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 111: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 112: Enclosure & Mounting

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-TA, T24-ACMi-TA, T24-ACMm-TA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 113: Specification

    Pair D cells Constantly on 4.5 months Pair D cells 12 sessions per day of 5 minutes > 9 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 114: T24-Acm-Ra, T24-Acmi-Ra, T24-Acmm-Ra, T24-Rae, T24Rai

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-RA Resistance transmitter module mounted in small enclosure with screw terminals to connect external 3 V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 115: Connections

    5 Vdc to 18 Vdc source. In both cases you need to fit the JP1 power jumper to supply power to the transmitter module. When powered from the external DC source the LED will illuminate. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 116: Sensor

    For battery information please refer to Appendix D – Battery Selection Sensor The resistance input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +2V5 Excitation +Input Not Connected -Excitation Shield Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 117: T24-Acmi-Ra

    The input connections are accessed by lifting the right hand cover plate, this plate incorporates the T24-ACMi Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield -Excitation Not Connected + Input +2V5 Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 118: T24-Acmm-Ra

    Power to transmitter modules in this enclosure can also be supplied by a T24-BB1 battery box which contains two AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation Not Connected +Input +2V5 Excitation Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 119: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 120: Configuration

    Transmit Interval. A shorter sample time means that the module is awake for less time so battery life is increased but at the expense of a reading with less noise free resolution. You can vary this to see the effect on battery. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 121 Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 122: Input / Output Configuration

    For more complex calibrations which include linearization select three to nine points. Point 1 - 9 For each point enter the engineering unit value that you want the transmitter module to report at the applied input. i.e. 1.67 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 123 This will take you to a different screen. Advanced Clicking the advanced button will allow you to edit the gains and offsets for each available calibration point. This will take you to a different screen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 124: Calibration By Certificate

    ( shown in this screenshot) value Engineering Units 1 - 9 Enter the required engineering unit output for the specified input value Calibrate Click this button to calculate and update the module calibration Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 125: Calibration Advanced

    This parameter stops the unit reporting values outside the viable input range. System Zero You can set the system zero value here or set it to zero to remove the system zero effect. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 126 This leads to a resultant gain and offset which is applied to the mV/V values as follows. Value = (input * Resultant Gain) – Resultant Offset. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 127: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 128: Enclosure & Mounting

    This module is fitted inside our medium enclosure. Please see Appendix A – Enclosures & Mounting – ACMi more information. T24-ACMm-RA This module is fitted inside our small enclosure. Please see Appendix A – Enclosures & Mounting – ACMm more information. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 129: Antennas

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-RA, T24-ACMi-RA, T24-ACMm-RA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 130: Specification

    Pair D cells Constantly on 4.5 months Pair D cells 12 sessions per day of 5 minutes > 9 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 131: T24-Acm-Pa, T24-Acmi-Pa, T24-Acmm-Pa, T24-Pae, T24-Pai

    D cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-PA Pulse transmitter module mounted in small enclosure with screw terminals to connect external 3 V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 132: Connections

    A maximum of 50 mA can be drawn from ‘Excitation’ (User selectable for 3 V, 5 V or 12 V) to power a pulse generating sensor. Reset Count is a ‘volt-free’ contact input. This can be used to reset the count input to zero. To activate connect ‘Reset Count’ to GND. Relay & Volt Free Contact Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 133: Voltage Source

    Voltage Source SHIELD Input A Excitation NPN Open Collector SHIELD Input A Excitation Onboard resistor configured for pull up PNP Open Collector Powered Sensor SHIELD Input A Excitation Onboard resistor configured for pull down Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 134: Quadrature Sensor

    Quadrature Sensor SHLD Input B OUT B (2) Input A OUT A (1) Excitation Onboard resistor configured to suit sensor The quadrature inputs A and B determine direction based on the following table. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 135: T24-Acm-Pa

    The pulse input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +Excitation Input A Input B - Excitation (GND) Shield T24-PAe, T24-PAi section above for wiring options. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 136: T24-Acmi-Pa

    Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield - Excitation (GND) Input B Input A +Excitation T24-PAe, T24-PAi section above for wiring options. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 137: T24-Acmm-Pa

    AA 1.5 V batteries. For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation (GND) Input B Input A +5 V Excitation T24-PAe, T24-PAi section above for wiring options. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 138: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 139: Configuration

    A possible reason for not using Low Power Mode would be if using the module in a Master-Slave arrangement with PC so the radio must be active and responsive permanently. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 140 This is the current drawn by any sensor attached to the user selectable excitation on board power supply. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the module will be turned on and transmitting. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 141: Input / Output Configuration

    Mark (Space) – Gives the percentage of Mark over Space for inputs on ‘Input A’. Pulses per Revolution Specify the number of pulses per revolution. This parameter only affects the RPM output value. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 142 By entering the minimum frequency or RPM measurement required, the module can calculate the most effective form of power saving to apply. Not available in Counter, Quadrature and Digital State output modes. Advanced Button Click to show the advanced page described below. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 143: Advanced I/O

    T24-PA to reset to zero whenever a data packet with this data tag is received. Data providers can be produced by other transmitter modules, T24- HA or custom software. For this to operate correctly this module should not be in Low Power Mode. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 144: Advanced Settings

    LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 145: Enclosure & Mounting

    This module is fitted inside our medium enclosure. Please see Appendix A – Enclosures & Mounting – ACMi more information. T24-ACMm-PA This module is fitted inside our small enclosure. Please see Appendix A – Enclosures & Mounting – ACMm more information. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 146: Antennas

    Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE T24-ACM-PA, T24-ACMi-PA, T24-ACMm-PA These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 147: Specification

    Pair D cells Constantly on 6.5 months Pair D cells 12 sessions per day of 5 minutes > 6 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 148: T24-Wss, T24-Wssp

    Appendix E – Legacy products Overview The T24-WSS wireless anemometer is built on the same technology as previous Mantracourt wireless sensor interfaces offering the same sleep and wake functionality and operation with peripheral modules including handhelds, USB base stations and GPRS data loggers.

  • Page 149: Order Codes

    D cell alkaline batteries. Also has ability to be powered cell alkaline batteries. Designed for pivot mounting to from external supply voltage. moving booms. For clamp mounting to 50 mm scaffold pole. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 150: Connections

    Launch the T24 Toolkit software application and pair to this module to enable the connection to the Toolkit to allow configuration to take place. See Common Toolkit Pages - Home Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 151: Data Rates And Quality

    So setting this to zero would always transmit the average wind speed between transmissions. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 152 Temperature and internal resistance of the battery are not taken into account in the guide. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the module will be turned on and transmitting. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 153: Units

    Simply select the required output units from the drop down list. The T24-WSS can provide wind speed in: Description Units Miles Per Hour Metres Per Second Kilometres Per Hour Km/h Feet Per Second Knots Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 154: Advanced Settings

    Average Wind Speed is transmitted using the defined Data tag. Optionally Gust Wind Speed is transmitted using the defined Data Tag + 1. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 155: Enclosure & Mounting

    Enclosure & Mounting T24-WSS The T24-WSS is designed to be attached to the top of a 50 mm scaffold pole or equivalent using the fitted clamp. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 156: T24-Wssp

    Install the mounting pivot bar on the same side of the boom as the cabin mounted display. b. Install the mounting pivot bar perpendicular to the boom. Install the mounting pivot bar at the highest point possible where the sensor will be free to rotate at all boom angles. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 157 Note that angle iron can be used to extend the mounting position to be clear of the top of the boom. Re-fit the wind speed sensor to the bar, add the M8 washer and fit the split pin/cotter pin.  Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 158: Antennas

    Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 159: Specification

    Pair D cells Constantly on 1 year Pair D cells 12 sessions per day of 10 minutes 6 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 160: T24-Lt1

    Typical battery life based on a pair of AA cells gives 13 days continuous operation at transmission rate of 3 readings per second. Order Codes T24-LT1 OEM Running Line Tensiometer transmitter module with external antenna UFL connector. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 161: Connections

    As the measurement is four wire then as the cable length increases the voltage drops in the cable will have more of an effect on the factory mV/V calibration. The strain gauge measurement is bi-directional, i.e. tension & compression. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 162: Quadrature Inputs

    The quadrature input sensors A and B should be mounted so that the activation zones (Whether optical or magnetic etc) cover both A and B inputs simultaneously as rotation occurs. The inputs then determine direction based on the following table. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 163: Shield Connections (All Enclosures)

    The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 164: Configuration

    You can vary this to see the effect on battery life and noise free resolution. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 165 Ohms. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the T24-HS handheld will be turned on and communicating with a transmitter module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 166: Calibration (Load)

    For more complex calibrations which include linearization select three to nine points. Point 1 - 9 For each point enter the engineering unit value that you want the transmitter module to report at the applied input. i.e. 1.67 Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 167 This will take you to a different screen. Advanced Clicking the advanced button will allow you to edit the gains and offsets for each available calibration point. This will take you to a different screen. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 168: Calibration By Certificate (Load)

    (mV/V shown in this value screenshot) Engineering Units 1 - 9 Enter the required engineering unit output for the specified input value Calibrate Click this button to calculate and update the module calibration Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 169: Calibration Advanced (Load)

    When the best point has been found the Gain and Offset values from that point are applied to the mV/V value as follows. Value = (input * Gain) – Offset. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 170: Calibration (Payout & Speed)

    This shows the calibrated final Speed value that will be transmitted. The Data Tag used to transmit this value is shown in the title. Auto Calibration Actuators Enter the number of actuators situated around the wheel. An actuator is defined Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 171 Enter the wheel diameter. Note that this dimension needs to take into account where the cable sits on the wheel and is unlikely to be the external diameter. Calibrate Button Click this button to calculate and update the module calibration. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 172: Advanced Settings

    Tag of one of the modules and perform pairing again with the T24-HS handheld. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 173: Enclosure & Mounting

    Appendix B – Antennas – T24-ANTB T24-ANTC Dipole Antenna Swivel Appendix B – Antennas – T24-ANTC T24-ANTD Puck Antenna SMA Appendix B – Antennas – T24-ANTD T24-ANTE Puck Antenna UFL Appendix B – Antennas – T24-ANTE Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 174: Specification

    Pair AA cells Constantly on 12 Days Pair AA cells 12 sessions per day of 5 290 Days minutes Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 175: Receiver Modules

    The handheld module is powered by two alkaline AA batteries. For battery information please refer to Appendix D – Battery Selection Due to the higher voltage requirements of this module NiMh and NiCad batteries are not recommended. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 176: Quick Start

    Remember that from this point onwards to turn the handheld on you just need to press and hold the power key as the pairing function is no longer required. Pairing was just used as a method of setting the transmitter module to the radio settings already configured in the handheld. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 177: Operation

    The batteries in the handheld are low and need to be replaced. REMOTE ERROR The transmitter module has an error that the handheld does not recognise. REMOTE BATT LOW The battery or supply to the transmitter module is low. Errors Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 178 There may be open or short circuits. Rather than display a misleading reading this error is displayed instead. Only certain transmitter modules support this error such as the T24-SA. Overload The overload limit set by the user has been exceeded. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 179: Configuration

    The T24 Toolkit provides a means of simple configuration of the handheld module along with useful tools to aid integration. Launch the T24 Toolkit software application and pair to this module to enable the connection to the Toolkit to allow configuration to take place. See Common Toolkit Pages - Home Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 180: Zero Settings

    The minimum weight of a box is 5 kg so you could set the Power On Auto Zero to 2 kg. When you turn on the handheld, if the weight on the platform is between -2 and +2kg then the handheld will tare this weight off and so read zero. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 181 (By setting the display resolution you may hide this difference) by setting a small value here such as 0.2kg the display will show a stable zero while actual weight is fluctuating less than ± 0.2kg. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 182: Display Format

    ‘--------‘ is displayed on the LCD. Should be at least 3 times the interval between the data being transmitted by the transmitter module. Advanced This opens the advanced page where you can scale the displayed data. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 183: Display Format Advanced Settings

    Example: If a T24-SA was supplying data in kg and you wanted to show tonnes. You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 184: Advanced Settings

    Indicates the ID of the currently paired transmitter. Enter the ID of the desired transmitter. Note that the transmitter must be set to the same radio channel and group key as the hand held module. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 185 The default of INT32 with a Start Byte of zero is the default which will be correct for a T24-SAF module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 186: Enclosure & Mounting

    Enclosure & Mounting Appendix A – Handheld Style section for more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 187: Specification

    IP67 Operating Temperature Range Storage Temperature Humidity Physical Hand Held Dimensions 90 mm x 152 mm x 34 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 188: T24-Ha

    The handheld module is powered by two alkaline AA batteries. For battery information please refer to Appendix D – Battery Selection Due to the higher voltage requirements of this module NiMh and NiCad batteries are not recommended. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 189: Operation

    Power Key - Press and hold the power key until the display shows BUSY then release the key. Can also be used, by giving a quick press, to reset the Auto-Sleep delay. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 190: Result Mode

    Power Key - Toggles between on and off. Hold for 2 seconds to activate. Keys when viewing an individual item Sleep Key - No effect. Wake Key - Will attempt to wake the currently selected module. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 191 This transmits a Data Provider packet marked with a Data Tag held in F1DataTag and can also contain data as defined by F1Data. This can be used to trigger external actions such as a printout. Power Key - Toggles between on and off. Hold for 2 seconds to activate. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 192: All Modes

    The motion detection has been enabled and the reading is deemed in motion or unstable. Other Functions System Zero If enabled, holding the Tare key for a number of seconds will perform a system zero. Pairing See Field Transmitter Module Replacement later Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 193: Configuration

    Up to 12 individual transmitter modules can be summed and displayed. Optionally the operator can view the individual module values (See Allow Next Key). Item Mode Up to 12 individual modules can be displayed and the user can step through each one in sequence. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 194 For modules with a firmware revision of 1.2 and newer this button will be visible. This displays a page where the message labels shown before switching between channels can be set by the user. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 195: Prompts

    7 segment LCD display is very limited in how it can represent letters. Some letters cannot be displayed. These include K, M, W, X Prompt for result Enter the prompt to display before the total result is displayed. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 196: Zero Settings

    The minimum weight of a box is 5 kg so you could set the Power On Auto Zero to 2 kg. When you turn on the handheld, if the weight on the platform is between -2 and +2kg then the handheld will tare this weight off and so read zero. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 197 This section allows the user to apply or remove a system zero. This will require that the transmitter modules are configured and attached to the handheld and the entire system is ready for zeroing. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 198: Zero Settings Advanced

    Tag. Usually pairing is activated by removing and replacing the power supply on the remote transmitter. You must perform pairing within 5 seconds of clicking the button. Click this to reset the Data Tag and ID to zero (disabling the external system zero function). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 199: Display Format

    You can enter a limit here above which Overload will be shown on the display instead of the actual value. Enter zero to disable this feature. Advanced This opens the advanced page where you can scale the displayed data. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 200 The F1 key will be disabled while the reading is in motion. Motion Time Enter a time in seconds within which the displayed value must not change more than the Motion Band amount set above. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 201: Display Format Advanced Settings

    Example: If a T24-SA was supplying data in kg and you wanted to show tonnes. You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 202: Advanced Settings

    Used when in Result Mode and the Next key has been enabled to allow viewing of discrete inputs. Enter a time in seconds that the individual item value will be displayed for before the display is automatically switched back to showing the result. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 203 The time you enter here in milliseconds is the time that this message will be displayed before the actual value is shown. Newer versions of the handheld allow the user to define these message prompts. See Prompts Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 204: Enclosure & Mounting

    Enclosure & Mounting Appendix A – Handheld Style section for more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 205: Specification

    IP67 Operating Temperature Range Storage Temperature Humidity Physical Hand Held Dimensions 90 mm x 152 mm x 34 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 206: T24-Hr

    The handheld module is powered by two alkaline AA batteries. For battery information please refer to Appendix D – Battery Selection Due to the higher voltage requirements of this module NiMh and NiCad batteries are not recommended. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 207: Operation

    The batteries in the handheld are low and need to be replaced. REMOTE ERROR The transmitter module has an error that the handheld does not recognise. REMOTE BATT LOW The battery or supply to the transmitter module is low. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 208: Errors

    Press and hold these keys for around 8 seconds until ZERO appears on the LCD. Release the keys and the display should then show the zeroed reading. This system zero is performed at the transmitter module and is stored through power cycling. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 209: Transmitter Module Configuration

    1 every 30 seconds. Just remember to set the Timeout of the handheld to at least 3 times this period. (i.e. 91 seconds in the case of 30 second transmission interval). The handheld will wake any sleeping module if it is on the same channel and has the same group key. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 210: Configuration

    You can also define the resolution, which is the block size of changes to the display. Example: If you enter the format as 000.0005 the display will only change in steps of 0.0005 which can be used to mask noisy digits at high resolutions. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 211 LCD. Should be at least 3 times the interval between the messages being sent by the transmitter module. Advanced This opens the advanced page where you can scale the displayed data. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 212: Display Format Advanced Settings

    Example: If a T24-SA was supplying data in kg and you wanted to show tonnes. You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 213: Settings

    Enter a value in engineering units which represents a band (+/-) about zero within which zero will be displayed. As soon as the value is outside this band the real value will be shown. (Only available in version 1.01 onwards) Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 214: Example Installation Scenarios

    The operator moves to the next pallet and presses the Next key again at which point the previous pallet LED goes off and the closest pallet LED activates. As the operator moves out of range, pallets go back to sleep because of their sleep delay settings. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 215: Enclosure & Mounting

    Enclosure & Mounting Appendix A – Handheld Style section for more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 216: Specification

    IP67 Operating Temperature Range Storage Temperature Humidity Physical Hand Held Dimensions 90 mm x 152 mm x 34 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 217: T24-Ao1, T24-Ao1I

    Version 1.1 brings the ability to wake the paired transmitter module when the analogue output module is turned on and to keep it awake while it remains powered up. Order Codes T24-AO1 T24-AO1i Analogue output module in desktop enclosure. Analogue output in weatherproof industrial enclosure. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 218: Connections

    Power is supplied via the screw terminals and can be in the range of 9 Vdc to 36 Vdc. T24-AO1 1 2 3 4 5 6 7 8 9 - 36V PAIR DC Supply T24-AO1i 1 2 3 4 5 6 7 8 PAIR 9 - 36V DC Supply Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 219: Connections And Indicators

    To configure the required output range the DIP switches (SW2) require setting as follows. To access the DIP switches you will need to remove the cover from the case. SW2 Switch Settings Range 0-10 V +/-10 V 0-5 V +/-5 V 0-20 mA Sink Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 220: Led Indicators

    50Hz the LED will appear constantly illuminated. Timeout Lost communications with the remote module. Error Remote module is reporting an error. Batt Low Remote module is reporting a low battery. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 221: Configuration

    The T24 Toolkit provides a means of simple configuration and calibration of the module along with useful tools to aid integration. Launch the T24 Toolkit software application and pair to this module to enable the connection to the Toolkit to allow configuration to take place. See Common Toolkit Pages - Home Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 222: Input / Output

    Output 0-10 V +/-10 V -10 V 0-5 V +/-5 V -5 V 0-20 mA Sink 0 mA 0-20 mA Source 0 mA 4-20 mA Sink 4 mA 4-20 mA Source 4 mA Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 223 Always check the SW2 DIP switch table for the correct settings. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 224: Alarm Settings

    Remote Batt Action When the transmitter module reports a low battery this action will occur. See the Output Actions section for the available actions and the effect of these choices on the different output ranges. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 225 Minimum Output * -0.5 -0.3 -5.5 Maximum Output * 22.4 22.4 Half Full Scale Hold Last Output * The values shown here are approximate. Each module will vary depending on tolerances of electronic components. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 226: Zero Settings

    Click to use the current input value as the new system zero. Remove System Zero Remove the system zero so that the input value is directly used to determine the analogue output. System Zero Enter the required system zero value. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 227: Advanced Settings

    The recommended time for the sleep delay is 10 seconds or 10000ms. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 228: Enclosure & Mounting

    This module is fitted inside our ACM ABS enclosure. Please see Appendix A – Enclosures & Mounting – ACM more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 229: Specification

    190 X 80 X 55 mm Environmental T24-AO1 IP50 T24-AO1i IP67 Humidity 95%RH (max) Radio Range To determine T24-AO1i radio range please refer to Appendix B – Antenna Range The T24-AO1 has a maximum range of 100m Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 230: T24-Rm1

    This module is supplied in an IP67 sealed ABS case but a DIN rail option is available. The state of the power relays during an error can be selected. Order Codes T24-RM1 Relay module housed in weatherproof enclosure. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 231: Connections

    Digital Input 1 Can either reset a latched relay 1 or transmit a Data Provider Packet of a specified Data Tag Digital Input 2 Can either reset a latched relay 2 or transmit a Data Provider Packet of a specified Data Tag Digital Input 3 Resets both latched relays Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 232: Operation

    COM and NC). The relay de-energises if an error is detected, an error is classed as a timeout and optionally can include Integrity error or low Battery. The Alarm Relay will return to normal (energised) once the source of the error is removed. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 233: Configuration

    2. Zero Offset [1-2] This value will be subtracted from the total of the summed data from the data tags for Relay 1 and relay 2. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 234: Relay Operation Settings

    (See diagram on next page) Latching [1-2] Latching locks the state of the relay when it passes the set point. Advanced Button Displays the Relay Settings Advanced page. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 235: Operation And Hysteresis Settings

    Operation and Hysteresis Settings Relay de-energises when reaching the set point. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 236: Relay Settings Advanced

    Transmitter modules will be kept awake while this module has power applied. The transmitter modules should have a Sleep Delay set so that after the relay module has been powered down the transmitter modules then return to sleep. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 237: Alarm Settings

    Digital input 2 can be used to either Reset Relay 2 from its latched state  Transmit a data provider with user defined data tag containing the total  of the inputs of Relay 2 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 238: Enclosure & Mounting

    This module is fitted inside our ACM ABS enclosure. Please see Appendix A – Enclosures & Mounting – ACM more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 239: Specification

    1A 120 Vac Operational Temperature Range °C Storage Temperature Range °C Humidity IP Rating IP67 * At 12 Volt nominal Supply Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 240: T24-So

    The serial output can consist of a single line of data suitable for feeding into an LED display module or a more complex multi-line result that can contain a mixture of fixed and variable data suitable for tickets, receipts etc. for printed output. Order Codes T24-SO Serial output module in weatherproof enclosure. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 241: Connections

    Switch positions 5 to 7 control the baud rate for the serial interface. Baud rate 9600 19200 38400 57600 115200 230400 460800 This switch position selects whether the serial interface is RS232 or RS485. 232/485 RS232 RS485 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 242: Rs232

    When using RS232 or RS485 you should use the fastest baud rate possible. At lower rates data can be lost  because it can arrive from the radio faster than the gateway station can send it serially. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 243: Configuration

    Arrival of a data packet identified with a Data Tag that matches what the T24-SO uses to trigger an  output/print. Arrival of a command to trigger an output/print or to tare or zero etc.  Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 244: T24 Toolkit

    Use the SleepDelay settings in the transmitter modules to let them return to sleep after the display module is switched off. This is only available for firmware versions 1.08 and above. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 245 It is possible to set the resolution (the smallest unit of change) of the output results by including the numeric value in the format. i.e. 00.005 would only represent the value in steps of 00.005 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 246: Output Settings

    By setting this property an output would be triggered when the data failed to arrive thus setting the serial display which would show ------- instead of the value when <V1> is decoded. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 247 Buttons Do Output Trigger the output when clicked. Output Scaling Will display the Output Scaling page. Output Design Will display the Output Design page. This is where you define the output data. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 248: Output Scaling

    You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. This affects all inputs and sums (both gross and net). All tokens will effectively be decoded using the new scale factor. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 249: Output Design

    See the example in the screenshot above. To enter a token you can type it in or double click the token list on the right of the page (a single click will display the description of the token). Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 250 ÆӪ-ü▀ where xx is a two digit hexadecimal value. i.e. <0D> Below are listed some useful hex codes. Hex Value Description Token <0D> Carriage Return <0A> Line Feed <09> <1B> Escape <02> <03> Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 251: Zero Settings

    By performing a system zero (with all inputs operational) this is zeroed away so next time the T24-SO is powered on the same input will yield a zero result. Remove System Zero Clicking this will remove all system zeros and restore all outputs to normal. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 252: Zero Settings Advanced

    Click this to give 5 seconds to perform pairing to automatically provide the Data Tag and ID from a specific module. Usually pairing is activated by removing and replacing the power supply. Click this to reset the Data Tag and ID to zero (disabling the external system zero function). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 253: Configuration Examples

    We will use the out of the box rate of 3 per second. The display only needs the ASCII data followed by a carriage return. Assuming the T24-SAs send data on Data Tag C675 and FF34 Parameter settings: Line1=<NET><0D> FormatSUM=00.000 ValueDataTag1=C675 ValueDataTag2=FF34 PrintTrigger=C675 MinInterval=100 LineDelay=0 PrintOnError=1 SwitchMode=1 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 254: Print Gross Sum Of Two Modules To Printer

    Parameter settings: Line1=ABC Electronics Ltd<0D><0A> Line2=Weigh Station #1<0D><0A> Line3=<0D><0A> Line4=Input 1:<V1> kg<0D><0A> Line5=Input 2:<V2> kg<0D><0A> Line6=---------------------<0D><0A> Line7=Sum: <G>kg<0D><0A> Line8=<0D><0A> Line9=For assistance call<0D><0A> Line10=0871 345672<0D><0A> V1Format=00.0000 V2Format=00.0000 SumFormat=00.0000 ValueDataTag1=C675 ValueDataTag2=FF34 PrintTrigger=0000 LineDelayChar=0A LineDelay=50 MinInterval=10000 SwitchMode=0 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 255: Customer Ticket From Handheld Module

    This module is fitted inside our ACM ABS enclosure. Please see Appendix A – Enclosures & Mounting – ACM more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 256: Specification

    Reverse polarity Protection Maximum Supply level Humidity IP Rating IP67 USB connector fitted to board is for power supply only. Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 257: T24-Gw1

    The T24-GW will NOT act as a base station and cannot be used to configure T24 modules. It will support all transmitter modules that deliver a single value in their Data Provider packets. The T24-GW1 does not support the T24-SAf. Order Codes T24-GW1 Gateway module in weatherproof enclosure. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 258: Connections

    Whether the serial interface is RS485 or RS232 is selected by switch position 8. 232/485 RS232 RS485 Power The T24-GW1 requires an external power supply to be connected to J4 on the –V and +V pins. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 259: Led Indication

    PC / PLC Connection Signal Base Station Connection Refer to RS485 Device User Manual J4 -A Refer to RS485 Device User Manual J4 +B Refer to RS485 Device User Manual J4 SH Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 260: Serial Limitations

    When using RS232 or RS485 you should use the fastest baud rate possible. At lower rates data can be lost  because it can arrive from the radio faster than the gateway station can send it serially. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 261: Communications Overview

    41009 – Read / Write Set to 1 to perform module save to save all the current settings and data tags in the module. It will set back to zero once the save is complete. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 262: Data Tag Holding Registers

    Note the ‘assumed 1’ before the mantissa. The exception to this is the special value 0.0, which is represented as 4 zeroes. The precision of this format is to 7 digits. eg. a floating-point number of -12345.678 is represented as – [hex] C640E6B6 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 263: Ascii Communication

    Value - an ASCII representation of the module reading LQI – Link quality indicator between 0 – 100 B – Set to 1 if low battery error E – Set to 1 if integrity error Example: FE56=123.156,100,0,0 <CR> Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 264: Commands

    STAYAWAKE <CR> - Issue a stay awake packet to all modules seen for 5 seconds following this command being executed. When using RS485 interface issuing commands while the T24-GW1 is outputting is not possible as the RS485 bus is only half duplex Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 265: Configuration

    The duration in seconds to look for modules after a WAKEUP command has been issued. Sleep Duration The duration in seconds to look for modules to send to sleep after a SLEEP command has been issued. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 266 AND the Timeout Action is set to Use Default. Data Format In Modbus mode the data from the value register can be displayed in two formats: MSB – Most Significant Byte First  LSB – Least Significant Byte First  Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 267: Define Inputs

    You can simply paste a list of tags into the list or type them manually. Refresh Button Refreshes the list. When using this page ensure you are in Modbus mode for values to be updated live. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 268: Enclosure & Mounting

    This module is fitted inside our ACM ABS enclosure. Please see Appendix A – Enclosures & Mounting – ACM more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 269: Specification

    Operating Temperature Range °C Storage Temperature Range °C Reverse polarity Protection Humidity IP Rating IP67 * At 12 Volt nominal Supply Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 270: T24-Ld1

    ‘System Zero’ function. Further wired Logic Inputs allow the user to remotely control Tare and Net/Gross toggle functions. Order Codes T24-LD1 Large LED display module Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 271: Connections

    Connections To access the connections the rear panel should be removed. The T24-LD1 should be connected to an 11–30VDC external power supply capable of supplying 3.5 amps as below: Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 272: Logic Input Connections

    The logic input provides a 5 Vdc signal. When connected to this common, a current of 1mA will flow. Because this is a small signal only switches with gold contacts or self-cleaning contacts are recommended. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 273: Logic Input Front Panel Indicators

    For Revision “C” Onwards Steady – Showing Net Value Flashing – Showing Gross Value Off – No Tare Value Set *Note keypad and LED fitted here on revision A & B of product only. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 274: Configuration

    Alternatively enter the Data Tag which, on arrival, will trigger a display update. This could be, for example, the Data Tag configured for a handheld display function button. i.e. Entering a Data Tag will allow on demand display updates. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 275 9.999 –Ur- If the value to display is below the minimum displayable value then will be displayed. –Or- If the value to display is above the maximum displayable value then will be displayed. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 276: Output Scaling

    Example: If a Transmitter module was supplying data in kg and you wanted to display in tonnes. You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 277: Zero Settings

    This does not affect the data transmitted from the transmitter modules. Remove System Zero Clicking this will remove all system zeros and restore all outputs to normal. Advanced Button Show the Zero Settings Advanced page. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 278: Zero Settings Advanced

    Click this to give 5 seconds to perform pairing to automatically provide the Data Tag and ID from a specific module. Usually pairing is activated by removing and replacing the power supply. Click this to reset the Data Tag and ID to zero (disabling the external system zero function). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 279: Enclosure & Mounting

    It is recommended that the T24-LD1 module is mounted at a higher elevation than the transmitter modules as the antenna is located on the lower face of the display (Where the cable access glands are located). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 280: Antennas

    Detail showing bracket hardware fitting sequence: Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 281: Specification

    Range + Reverse Polarity Protection Maximum Operational Current Operating Temperature °C Range Storage Temperature °C Range Humidity IP Rating IP65 Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 282: T24-Pr1

    Power is supplied via a 2.5 mm DC plug which plugs into, and locks with, a 2.5 mm socket on the side of the module. Voltage range is 9 to 36 Vdc and requires approximately a one Ampere (1A) capable supply. The tip of the connector is positive. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 283: Configuration

    The T24 Toolkit provides a means of simple configuration of themodule along with useful tools to aid integration. Launch the T24 Toolkit software application and pair to this module to enable the connection to the Toolkit to allow configuration to take place. See Common Toolkit Pages - Home Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 284: Input Settings

    Min Interval setting on the Output Settings page may stop this from working at the rate at which the data arrives. This is usually set to the Data Tag of one of the inputs. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 285 It is possible to set the resolution (the smallest unit of change) of the output results by including the numeric value in the format. i.e. 00.005 would only represent the value in steps of 00.005 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 286: Output Settings

    (Within the timeout period for that input) and the values would show ------- instead of the numeric value when <V1> is decoded. This would indicate to the user that there is a problem. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 287 You will see the token <0A> in the Output Design page when you press the enter key at the end of a line. Line Delay This is not alterable but shows the delay in milliseconds required at the end of each printed line. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 288: Output Scaling

    You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. This affects all inputs and sums (both gross and net). All tokens will effectively be decoded using the new scale factor. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 289: Output Design

    You can compensate for this either by designing your lines in reverse order or including the following tokens at the top of your lines <1B><63><00> Available Tokens Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 290 <1B><57><02> Start Large Character Printing <1B><57><01> End Large Character Printing <1B><63><01> Print in reverse order (This is the default mode.) <1B><63><00> Print as designed (Should be placed at the top of the design) Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 291 Example To print the value from input 1 in reverse: Current Value: 123.456 Current Value: <1B><69><01><V1><1B><69><00> kg Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 292: Zero Settings

    By performing a system zero (with all inputs operational) this is zeroed away so next time the T24-PR1 is powered on the same input will yield a zero result. Remove System Zero Clicking this will remove all system zeros and restore all outputs normal. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 293: Zero Settings Advanced

    Click this to give 5 seconds to perform pairing to automatically provide the Data Tag and ID from a specific module. Usually pairing is activated by removing and replacing the power supply. Click this to reset the Data Tag and ID to zero (disabling the external system zero function). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 294: Configuration Examples

    Line3=<0A> Line4=Input 1: <V1> kg<0A> Line5=Input 2: <V2> kg<0A> Line6=---------------------<0A> Line1=Sum: <G> kg<0A> Line8=<0A> Line9=For assistance call<0A> Line10=0871 345672<0A> Line11= <0A> Line12= <0A> Line13= <0A> V1Format=00.0000 V2Format=00.0000 SumFormat=00.0000 ValueDataTag1=C675 ValueDataTag2=FF34 PrintTrigger=0000 MinInterval=10000 SwitchMode=0 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 295: Customer Ticket From Handheld Module

    Ticket No: 0007 Weighment: 12.3456 kg ABC Electronics Ltd Ticket No: 0007 Weighment: 12.3456 kg Parameter settings: Line1=<1B><63><00>ABC Electronics Ltd<0A> Line2=Ticket No: <LOG><0A> Line3=Weighment: <TV> kg<0A> Line4=<0A> Line5=<0A> SumFormat=00.0000 LogDigits=4 PrintTrigger=ABCD MinInterval=5000 Duplicate=1(Yes) Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 296: Printer Operation And Maintenance

    LED will go out. Now you can press the LED/Button marked LF to feed the paper one line at a time. Remember to press the SEL button again to put the printer back online to enable it to print again. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 297: Enclosure & Mounting

    Base Lid 16 mm 0.6299” 82 mm 3.2283” Ø 4 mm 0.1574” 166 mm 6.5354” Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 298: Specification

    8 dots per mm (384 dots per line) Print Head Life 6X10 character lines Print Speed 30 mm/sec (25% utilization) Character Size 6x8dots , 8x16dots,or12x24dots Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 299: T24-Rdc-1, T24-Rdc-2, T24-Rdc-5, T24-Rdc-10, T24-Rdc-200

    The RDC is a Remote Data Collection module which communicates using GSM/GPRS and therefore is bound by the restrictions and limitations of a mobile data network. This can include but is not limited to partial or complete loss of coverage, environmental interference or network faults. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 300: Order Codes

    Order Codes T24-RDC-1, T24-RDC-2, T24-RDC-5, T24-RDC-10, T24-RDC-200 All T24-RDC variants are fitted within a weatherproof enclosure. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 301: Connections

    As soon as power is supplied the module will enter its startup routine. The above diagram also shows where to connect the digital input and the alarm output. See later in the manual for more information on digital IO. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 302: Led Indicators

    LEDs will all go out. The unit will reset and try again a few seconds later causing all LEDS to flash on. If this state persists you should remove the battery connector and any external power supply for a few seconds then re- attach. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 303: Digital Input

    This is an open collector drive and can be used to operate alarms, klaxons etc. Refer to the specification to see whether you would need relays to drive your required alarm indicator or whether it could be driven directly from the output. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 304: Configuration

    Enter a time here in seconds that if exceeded with no T24 data arriving at all will result in the T24 Error LED to light. Also if individual channels fail to deliver data for longer than this period their value will default to the T24 Default below. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 305 Do not specify an extension. CSV data will be allocated a .CSV extension and reports will be allocated a .TXT extension. Useful tokens include <s>, <y>, <f> and <@xxx> date time formatted tokens. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 306: Status Tab

    External Communications This indicates the state of the connection to the cellular network. Most of the Status time this should be idle but will indicate when CSV or report data is being transferred. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 307: Gprs Tab

    This indicates the strength of the network signal and is shown only on connection and is not dynamically updated. You will need to wait until the module has completed its startup routine before this value is displayed. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 308: Email Tab

    Enter a subject to appear in the email subject line. This is common for all delivered email both CSV data and reports so would usually indicate the site from which the module operates. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 309: Clock Tab

    Clicking here will open a dialog to allow you to select the minute (0-59) on a slider. Second Clicking here will open a dialog to allow you to select the second (0-59) on a slider. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 310: Silent Mode Tab

    By setting Silent to YES the module can be deployed as required and then by using SMS Configuration (See later in the manual) silent mode can be turned off and the data and reports will then be transmitted. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 311: Macros Tab

    Enter the text to substitute for the token <m4> Macro 5 Enter the text to substitute for the token <m5> Macro 6 Enter the text to substitute for the token <m6> Macros cannot contain tokens. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 312: Post Tab

    Items you can change: POST Tab Custom Header Enter the custom header data here. This will be included in all HTTP headers for destinations defined as POST. See the HTTP Post section later in this manual. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 313: Serial Tab

    The RDC can support locally wired serial T24-BSi base stations connected to J9 configured as RS485. Items you can change: Serial Tab Baud Rate Select the baud rate that matches the attached base stations. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 314: Inputs

    If you clear the channels in Auto Mode then it is advisable to also clear the CSV data from the Data Collection page. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 315 Changes the display to show a simple list of Data Tags. This allows quick bulk entry of tags from an external source. You can simply paste a list of tags into the list or type them manually. Refresh Button Refreshes the list. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 316: Data Collection

    1 – Low Power The module sleeps in a low power mode and wakes at the Log Interval (Set in the Schedules tab) it can then react to SMS Reports and Triggered Reports. This mode Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 317 You can also select whether the RDC sends the modules back to sleep after a reading has been recorded. It is advisable to also set a Sleep Delay on the transmitter modules and not rely solely on the RDC to send the modules to sleep. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 318: Schedules Tab

    8Hr 0Min synchronised to 8Hr 0Min so the logs will take place at 8am, 4pm and 12pm. Log Send Interval This is the interval that the CSV data is transmitted to the specified destinations. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 319 This ensures that the CSV data contains the value that caused the report to trigger. The user of the CSV file must use the date/time stamp to determine when the data was logged and not just assume it was logged at the Log Interval! Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 320: Formatting Tab

    The two-digit day. Single-digit day values are preceded by a zero. "ddd" The three-character weekday abbreviation. "dddd" The full weekday name. "hh" The two-digit hour in 12-hour format. Single-digit values are preceded by a zero. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 321 Specify the decimal separator. Usually in the UK this would be a decimal point but Europe would use a comma. Header Row You can override the automatic header row at the top of the CSV file by entering a custom one here. i.e. Date,IntTemp,Strut1,Strut2,ExtTemp Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 322: Destinations Tab

    See the lower part of the page for the status and result of this test. You will also need to check the actual destination for the delivered message to ensure that you have entered the correct details. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 323 Enter the required destination. NOTE that this is the primary destination and if in Low Power mode and this delivery fails it will be retried at every subsequent Log Interval. Destination 2 Enter the required destination. Destination 3 Enter the required destination. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 324: Sms Reports

    (?) then the contents of the triggering SMS message (after the password line) are used to create the response message. Therefore you can create the desired message, including tokens, remotely to receive any custom information required. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 325 Depending on the low power mode selected you may not see an SMS response until the next log interval or in the case of ultra low power mode until the next transmission of the CSV data. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 326: Sms Configuration

    Set the text for macro 2 m2=upper support Set the text for macro 3 m3=West Mount Site Set the text for macro 4 m4=Channel Set the text for macro 5 m5=kg Set the text for macro 6 m6=-------------------------- Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 327: Triggered Reports

    Check the specified channels and trigger the report if any report an integrity error (A problem with their input) 4-Remote Low Battery Check the specified channels and trigger the report if any report a low battery Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 328 When entering a Data Tag ensure that you use 4 characters i.e. 0F45 Unless Data Tags are manually changed on transmitter modules the random nature would tend to make entering a range of Data Tags useless. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 329 Also bear in mind that in Low Power or Ultra Low Power modes reports could not be delivered more regularly than the Log Interval or the CSV Delivery Interval respectively. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 330: Message Tab

    On transitionally triggered reports this message is used when the trigger criteria is no longer met. For example a report triggered on low internal battery would send this message when the battery voltage is OK. i.e. Internal battery voltage is OK at <v> volts. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 331: Destination Tab

    Items you can change: Destination Tab Destination 1 Enter the required destination. Destination 2 Enter the required destination. Destination 3 Enter the required destination. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 332: Tokens

    Replaced with the value/limit value of a triggered report. <T> Replaced with internal temperature. <nnnn> Replaced with last value from specified data tag. i.e. <FC34> <nn> Replaced with last value from specified channel. i.e. <12> <S> Replaced with SiteName . Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 333 Within a loop section this will be replaced with the value from the channel (Contains a zero rather than a specific channel number). <SS> Replaced with the status value from the channel. <FF> Replaced with the flags value from the channel. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 334 Channel 2 [FC12] = 456.78 kg Channel 3 [FCE8] = 12.34 kg Channel 4 [FD5D] = 45.67 kg <@dddd> tokens starting with @ character will be decoded to date time as described in the Time Date Formatting section. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 335: Time Date Formatting

    The full time and date encoded numerically in the MS Excel format. "EE" Epoch format in milliseconds elapsed since 01/01/1970. Any other characters will form part of the formatted output. i.e. ‘<@mmmm dd yyyy at HH:MM:SS>’ would decode to ‘January 15 2009 at 12:23:05’ Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 336: Destinations

    Where you can use either the DNS name or the IP address. Example 12.135.36.265:8080 info.mantra.com:1024 HTTP Post The message is sent as the data content of an HTTP POST. This is useful for getting data into a web service or site. The format is Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 337 HTTP header if the site you are posting data to requires it. POST http://host.com/Service/batch HTTP/1.0 Host: host.com Content-Type: application/x-www-form-urlencoded CUSTOM HEADER ITEMS APPEAR HERE Content-Length: 40 V1=123.456&V2=456.789&DATESTAMP=31122010 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 338: Battery Life

    The interval for transmitting the CSV file to a single email destination is every 24 hours. The average current drawn: Low Power Mode None Ultra Milliamps Scenario 1 Log:1hr Send:24hr Low Power Modes 300.0 None Ultra 250.0 200.0 150.0 100.0 50.0 Battery Capacity (Am p Hours) Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 339: Scenario 2

    The interval for transmitting the CSV file to a single email destination is every hour. The average current drawn: Low Power Mode None Ultra Milliamps Scenario 1 Log:15mins Send:1hr Low Power Modes 80.0 None Ultra 70.0 60.0 50.0 40.0 30.0 20.0 10.0 Battery Capacity (Am p Hours) Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 340: Sim Card Considerations

    M2M Dedicated SIM Very robust  Designed for use with machine to machine communications  Voice data not required  This is the recommended SIM type for use in the T24-RDC modules. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 341: Service Provider Settings For T24-Rdc

    Effectively the service provider website portal to give access to the internet User Name & Password These are provided to give you access to the internet, the same provider may have different usernames and passwords for PAYG vs Contract customers to distinguish users. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 342: Service Providers

    UK which is evident by the number of other companies that use their network Virgin and 3 included. Orange Property Value APN (Contract) orangeinternet APN (PAYG) payginternet Username user Password pass Notes Untested Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 343 3 SIMS are not compatible with the T24-RDC. Property Value mobile.o2.co.uk Username mobileweb Password password Notes Untested. Other Service Providers will use one of these main providers with a different tariff structure on top, i.e. Tesco Mobile, Fresh, Talk Talk. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 344: Simple Mail Transfer Protocol (Smtp) Servers

    SMTP server settings on the mail client for each ISP; using a relaying SMTP server allows the SMTP client settings to be used unchanged worldwide. The SMTP service must support AUTH LOGIN authentication or allow unauthenticated access. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 345: Smtp Server Options

    Web Based Relaying SMTP server Mantracourt has gone down the path of outsourcing our SMTP server forwarding to a web based SMTP server. This allows us to send emails from any device from a PC to T24-RDC using any validated sender email address.

  • Page 346: Enclosure & Mounting

    Enclosure & Mounting Antennas These modules have the antenna already fitted to the enclosure so there are no specific mounting requirements. However, the left antenna can be angled to give better T24 reception. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 347: Specification

    Maximum Supply level Protection Enclosure Grey ABS Environmental Protection IP67 Dimensions 120 mm x 122 mm x 55 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 348: T24-Dws

    T24-DWS Surface mounted display module for winds peed sensor housed in a robust weatherproof enclosure. Connections The module incorporates 3 metres of cable. The cable is used to supply power and relay connections. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 349: Quick Start

    T24 Toolkit to connect to the display module. After that either use the above method of automatic pairing or the transmitter radio settings could be changed manually by connecting it to the T24 Toolkit. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 350: Operation

    Communications may start to deteriorate when this indicator is visible. Until ------ is displayed the communications are still OK and the display can be relied on for accuracy. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 351 Error 2 The transmitter is indicating that the wind speed measured indicates that there is a system fault. Error 3 The wind speed transmitter is not configured for metres per second (m/s) units. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 352: Configuration

    For correct operation of the display, the wind speed transmitter modules must be configured for transmitting metres per second (m/s) as the output units. If it is not configured correctly the display will show Error 3. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 353: Advanced Settings

    Indicates the ID of the currently paired transmitter. Enter the ID of the desired transmitter. Note that the transmitter must be set to the same radio channel and group key as the hand held module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 354: Enclosure & Mounting

    Enclosure & Mounting Appendix A – Mounted Display Type section for more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 355: Specification

    IP rating IP67 Operating Temperature Range Storage Temperature Humidity Physical Display Dimensions 90 mm x 152 mm x 89 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 356: T24-Hlt

    The handheld module is powered by two alkaline AA batteries. For battery information please refer to Appendix D – Battery Selection Due to the higher voltage requirements of this module NiMh and NiCad batteries are not recommended. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 357: Operation

    Next Key - Step to the next reading (Load, Payout and speed). A brief prompt will be displayed before the value is shown. i.e. ‘Load’, ‘Payout’ etc. Also see Prompts Power Key - Press and hold the power key until the display shows BUSY then release the key. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 358: Indicators

    The motion detection has been enabled and the reading is deemed in motion or unstable. Other Functions System Zero If enabled, holding the Tare key for a number of seconds will perform a system zero. Pairing See Field Transmitter Module Replacement later Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 359: Configuration

    Up to 12 individual transmitter modules can be summed and displayed. Optionally the operator can view the individual module values (See Allow Next Key). Item Mode Up to 12 individual modules can be displayed and the user can step through each one in sequence. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 360 For modules with a firmware revision of 1.2 and newer this button will be visible. This displays a page where the message labels shown before switching between channels can be set by the user. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 361: Prompts

    7 segment LCD display is very limited in how it can represent letters. Some letters cannot be displayed. These include K, M, W, X Prompt for result Enter the prompt to display before the total result is displayed. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 362: Zero Settings

    The minimum weight of a box is 5 kg so you could set the Power On Auto Zero to 2 kg. When you turn on the handheld, if the weight on the platform is between -2 and +2kg then the handheld will tare this weight off and so read zero. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 363 This section allows the user to apply or remove a system zero. This will require that the transmitter modules are configured and attached to the handheld and the entire system is ready for zeroing. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 364: Zero Settings Advanced

    Tag. Usually pairing is activated by removing and replacing the power supply on the remote transmitter. You must perform pairing within 5 seconds of clicking the button. Click this to reset the Data Tag and ID to zero (disabling the external system zero function). Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 365: Display Format

    You can enter a limit here above which Overload will be shown on the display instead of the actual value. Enter zero to disable this feature. Advanced This opens the advanced page where you can scale the displayed data. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 366 The F1 key will be disabled while the reading is in motion. Motion Time Enter a time in seconds within which the displayed value must not change more than the Motion Band amount set above. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 367: Display Format Advanced Settings

    Example: If a T24-SA was supplying data in kg and you wanted to show tonnes. You would keep both the low points at zero. Enter At High Input Value of 1000 and Display Should Read Value of 1. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 368: Advanced Settings

    Used when in Result Mode and the Next key has been enabled to allow viewing of discrete inputs. Enter a time in seconds that the individual item value will be displayed for before the display is automatically switched back to showing the result. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 369 The time you enter here in milliseconds is the time that this message will be displayed before the actual value is shown. Newer versions of the handheld allow the user to define these message prompts. See Prompts Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 370: Enclosure & Mounting

    Enclosure & Mounting Appendix A – Handheld Style section for more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 371: Specification

    IP67 Operating Temperature Range Storage Temperature Humidity Physical Hand Held Dimensions 90 mm x 152 mm x 34 mm Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 372: Base Stations & Repeater Modules

    Some complex topologies may only be realized by using multiple base stations which may require changes to the Address switches. (Contact Mantracourt Electronics for advice regarding multiple base stations residing on a single serial bus) The industrial base station (T24-BSi) has interfaces for USB, RS232 and RS485 and is addressable.

  • Page 373: Connections

    The interface can be selected from the DIP switches SW1 as can baud rates for serial interfaces and the Address of the base station. SW1 Settings Address Switch positions 1 to 4 select the base station Address. This should normally be 1. Address Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 374: Serial/Usb

    The RS232 interface uses TX, RX and GND to connect to a PC, PLC etc. and uses standard RS232 voltage levels. The baud rate can be selected by setting the DIP switches stated above. The base station will require power cycling to utilise a baud rate change. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 375: Rs485

    To communicate with the base station the connected module must use the USB HID Device Class and support USB 2.0 full speed interface (12Mbits). The USB connection will also power the base station. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 376: Communications

    The Toolkit software can then be configured to use the desired interface to the base station. If you intend to write your own software to connect to a T24 module please refer to the T24 Technical Manual for descriptions of communications protocols. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 377: Configuration

    You now have successful communications with the base station so you can now let the Toolkit know you want to configure the base station and not a remote module. To connect to and configure the connected base station, hold the shift key and click the Pair button. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 378: Radio Settings

    To use modules that support Group Keys with older modules that do not then the Group Keys must be blank. Advanced Advanced Settings below. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 379: Advanced Settings

    Waker Duration When you send a wake command to a T24 module via the base station the duration of this wake attempt is controlled by this setting. Enter the desired duration in seconds. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 380: Enclosure & Mounting

    T24-BSi, T24-BSu, T24-BSue, T24-BSd These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 381: Specification

    Operating Temperature Range °C Storage Temperature Range °C Environmental Protection IP67 Does not apply to USB connector at cable end. Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 382: T24-Ar

    Adding more repeaters will not increase range but can increase coverage. Order Codes T24-AR Active Repeater module mounted in large weatherproof enclosure with battery holder for two D cell alkaline batteries. Also has ability to be powered from external supply voltage. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 383: Connections

    Stay awake messages are transmitted by handhelds, analogue output modules and PC software etc. so that when those items are turned off or disabled all other T24 modules will sleep when their Sleep Delay time elapses. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 384: Getting Started

    Increase Range With No Repeater With Repeater Span Obstacles With No Repeater Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 385: Combined Solutions

    With Repeater Combined Solutions Many Consumers Many Providers Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 386: Considerations

    But some modules only wake specific single target modules such as the T24-HS handheld module and the T24-AO1 analogue output module. For these modules to wake the repeater they must be fitted with at least version 2.1 radio modules. This only affects repeaters with a SleepDelay set. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 387: Configuration

    Once the repeater stops hearing Stay Awake messages from the data consumer (PC or handheld etc.) it will go to sleep after this amount of time. The repeater will wake when any other module is woken. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 388: Enclosure & Mounting

    This module is fitted inside our ACM ABS enclosure. Please see Appendix A – Enclosures & Mounting – ACM more information. Antennas These modules have the antenna already fitted inside the enclosure so there are no specific mounting requirements. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 389: Specification

    For example: If the T24-AR was used for 1 hour per day then the battery life would be 6840 hours or 288 days or nearly 10 months. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 390: Power Supply Modules

    150 * Quiescent Current μA * 07/02 gauge wire attached to maximum load i.e. T24-SAf with four 350 ohm strain gauges Note LED will only be lit when an input voltage is applied Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 391: Example Batteries

    Charge Time : 2 Hours @ 133 mA  Battery life = 18 hours *  Battery life is calculated with a T24-SAf running for 2 hours out of every 8 hours, to a 1000 ohm bridge. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 392: Pp1 & Sp1

    The PP1 can also be used as a mains powered 12 Vdc supply with 33 Ah battery backup. Order Codes Solar panel with cable suitable for connection to PP1 Power pack 1 housed in robust weatherproof case. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 393: Getting Started

    To insert remove the dust cap and align the connector and insert; there is a locating ridge to ensure correct orientation. Once inserted, twist the collar clockwise to lock in place. The connectors for the solar panel and 12 volt output are opposite gender preventing incorrect connections. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 394: Solar Panel Orientation

    The bracket is designed to be mounted on a pole or directly onto a wall. For detailed panel angle information based on country and location see Solar Electricity Handbook calculator here: http://www.solarelectricityhandbook.com/solar-angle-calculator.aspx Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 395: Operation

    6.3A 20x5 mm ceramic glass tube type. The 100-240 Vac input charger is fuse protected in the 13 amp plug, if this plug is replaced with any other connector please consider how your PP1 is protected. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 396: Dimensions & Weight

    Dimensions & Weight PP1 Dimensions 339 x 295 x 152 mm PP1 Case materials Polypropylene PP1 Weight 13 kg SP1 Dimensions 360 x 510 x 28 mm SP1 Frame Material Aluminium SP1 Weight 3 kg Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 397: Specifications

    * Supplied with 13 A Plug Environmental Typical Units IP rating IP67 Operating Temperature Range ** °C Storage Temperature °C Humidity ** When being charged from Mains min operating temperature 0 C max operating temperature 40 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 398: Appendices

    Note that the mounting hole is connected directly to the Battery ground of the transmitter module. The mounting hole near the chip antenna cannot accept metal mounting hardware. The connection holes are on a 1.9 mm pitch and are a diameter of 1.0 mm. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 399: Antenna Position

    Appendix B - Antennas Modules with an internal chip antenna have the antenna at one end of the board with the metal can on. Environmental Protection These modules are not protected against the environment. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 400: Acm Type

    The module is fitted with a T24-ANTA antenna which is mounted on the inside of the long side of the base on the opposite side of the enclosure to the metallised polyester label visible on the outside. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 401: Environmental Protection

    The sealing gasket resides in the lid. Be careful when replacing the lid that there are no dirt particles on the lower case lip or in the lid gasket channel as this may reduce the sealing capability. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 402: Acmi Type

    In addition mountings can be made through the back of the case however a seal or gasket must be used to maintain environmental protection. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 403: Antenna Position

    The cable diameter can range from 3.0 mm to 6.5 mm. Cables of a smaller diameter may be used if sleeved to increase their diameter. When mounting the enclosure outside the cables should be dressed to provide a drip loop. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 404: Acmm Type

    3.3 mm and the head diameter up to 8.0 mm. The distance between the mounting holes is 67.8 mm. Antenna Position If the enclosure contains an antenna this will be of the chip type and could be at either position inside the enclosure as indicated by the black rectangles shown below. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 405: Environmental Protection

    Environmental Protection This enclosure is not weatherproof. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 406: Handheld Type

    Note that the top two screws will have rubber ‘O’ rings on them. These rings are an integral part of the sealing mechanism. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 407: Mounting Information

    The enclosure is fitted with a T24-ANTA antenna which is mounted in the top end of the enclosure. Environmental Protection The enclosure is sealed to IP67. Ensure gaskets and mating parts are free from dirt and debris when re- assembling. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 408: Dongle Type

    Antenna Position The enclosure is fitted with an integrated chip antenna which is mounted in the top end of the enclosure opposite to the USB connector. Environmental Protection This enclosure is not weatherproof. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 409: Mounted Display Type

    Mounted Display Type Dimensions This ABS handheld case is 152 mm X 90 mm and 89 mm deep including ball joint mount. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 410: Opening The Case

    M4 clamp bolts once the display has been positioned as required. Antenna Position The enclosure is fitted with a T24-ANTA antenna which is mounted in the top end of the enclosure. Environmental Protection The enclosure is sealed to IP67. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 411: Appendix B - Antennas

    Range underwater is only 100 mm or so depending on packet rate. Best performance underwater is obtained by using low packet rates and immersing water-proofed antennae rather than water-tight enclosures containing the antennae. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 412: Internal Chip Antenna (Oem Modules)

    There must be no metal objects within 7 mm of the antennas long edge and 20 mm from the short edges. See diagram below. Integrated Antenna 7 mm Internal Antenna Specification Gain: 1.3 dBi Type: Ceramic chip antenna (Helix) Connection: None Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 413: T24-Anta

    The antenna feeder cable, or any other cables or wires, must not be routed over or near the cross hatched area shown below as this will affect range. Specification Gain: 3.0 dBi Type: Inverted F Printed circuit antenna Connection: 100 mm cable with UFL connector Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 414: T24-Antb

    The user must ensure that the bulkhead mounted connector is sealed to the required level. Specification Gain: 1.1 dBi Type: ½ wave dipole Connection: Reverse polarity SMA connector on antenna to connect to reverse polarity SMA bulkhead on 100 mm tail to UFL connector. Environmental Protection: IP67 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 415: T24-Antc

    The user must ensure that the bulkhead mounted connector is sealed to the required level. Specification Gain: 2.2 dBi Type: ½ wave dipole Connection: Reverse polarity SMA connector on antenna to connect to reverse polarity SMA bulkhead on 100 mm tail to UFL connector. Environmental Protection: IP67 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 416: T24-Antd

    Dimensions: 53 mm diameter, 19 mm puck height, 6 mm stud length Specification Gain: 3.0 dBi Type: Inverted F Printed circuit antenna Connection: 1.0 m cable terminated in reverse polarity SMA plug (RPSMA Plug) Environmental Protection: IP69K Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 417: T24-Ante

    Dimensions: 53 mm diameter, 19 mm puck height, 6 mm stud length Specification Gain: 3.0 dBi Type: Inverted F Printed circuit antenna Connection: 60 mm cable terminated UFL plug Environmental Protection: IP69K Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 418: Antenna Range

    Tests conducted in an open field site with the transmitter at the top of a 3m pole. The receiver was mounted 1.5m off the ground. Note that the range of the T24-BSd may be reduced because of its close proximity to computer and user. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 419: Appendix C - Radio Specification

    License License Exempt Modulation method MS (QPSK) Radio type Transceiver (2 way) Data rate K bits/sec Radio Frequency 2.4000 2.4835 Power Channels (DSSS) For radio range information See Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 420: Appendix D - Battery Selection

    This may have the unexpected effect of resetting or restarting a module. In the case of a transmitter module that is in a deep sleep mode this may wake the module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 421: Environmental

    Optimising battery life Battery life can be optimised by considering the following: Use of low power mode.  Transmission interval.  Required Measurement resolution (Sample time).  Sleep / Wake configuration  Auto-Sleep duration.  Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 422: Appendix E - Legacy Products And Versions

    D batteries. cell alkaline batteries. Also has ability to be powered from external supply voltage. T24-ACMm-PA Pulse transmitter module mounted in small enclosure with screw terminals to connect external 3 V power supply. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 423: Connections

    ‘sleep’ period can be accounted for by delaying the sampling until this period has elapsed. Reset Count is a ‘volt-free’ contact input. This can be used to reset the count input to zero. To activate connect ‘Reset Count’ to GND. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 424: Relay & Volt Free Contact

    SHLD Pulse in + 5V Voltage Source SHLD Pulse in + 5V NPN Open Collector SHLD Pulse in + 5V PNP Open Collector 5V Powered Sensor SHLD Pulse in + 5V T24-ACM-PA Power Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 425: Sensor

    The pulse input is connected to the module via a 2 part screw terminal block. Screw Terminal Function +5 V Excitation Pulse In Not Connected -Excitation (GND) Shield T24-PAe, T24-PAi section above for wiring options. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 426: T24-Acmi-Pa

    Antenna; take extra care when re-assembling that the grey UHF cable is attached to the antenna socket. Screw Terminal Function Shield -Excitation (GND) Not Connected Pulse In + 5 V Excitation T24-PAe, T24-PAi section above for wiring options. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 427: T24-Acmm-Pa

    For battery information please refer to Appendix D – Battery Selection Sensor Screw Terminal Function -Excitation (GND) +Not Connected -Pulse In +5 V Excitation T24-PAe, T24-PAi section above for wiring options. Shield Connections (All Enclosures) Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 428 The quality of the measured reading should also be looked at. In cases where the shield/chassis connection makes no difference to the radio signal or the reading quality then the connection should be made. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 429: Configuration

    Enter the transmission rate in milliseconds. The default is 300 giving approximately 3 per second which is ideally suited to reading on a handheld. You may want to slow this down to achieve longer battery life. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 430 This is the current drawn by any sensor attached to the 5 V on board power supply. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the module will be turned on and transmitting. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 431: Input / Output Configuration

    This is useful in situation where a sensor may be powered by the transmitter module and may produce an erroneous pulse on start up. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 432: Advanced I/O

    T24-PA to reset to zero whenever a data packet with this data tag is detected. Data providers can be produced by other transmitter modules, T24- HA or custom software Advanced Settings Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 433 LED to be externally mounted. This is very useful when using a T24-HR roaming handheld as the transmitter module LED will activate while the handheld is in communications with the module. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 434: Enclosure & Mounting

    Input Range in RPM (presuming 1 pulse / rev) 180,000 Accuracy % input error @ 1 Hz 0.15 Accuracy % input error @ 1 kHz 0.175 Accuracy % input error @ 2 kHz Accuracy % input error @ 3 kHz 0.25 Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 435: Radio Range

    Pair D cells Constantly on 4.5 months Pair D cells 12 sessions per day of 5 minutes > 9 years Radio Range To determine radio range please refer to Appendix B – Antenna Range Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 436: T24-Wss

    Overview The T24-WSS wireless anemometer is built on the same technology as previous Mantracourt wireless sensor interfaces offering the same sleep and wake functionality and operation with peripheral modules including handhelds, USB base stations and GPRS data loggers.

  • Page 437: Connections

    In both cases you need to fit the JP1 power jumper to supply power to the transmitter module. When powered from the external DC source the LED will illuminate. Pow er Jumper JP1 2 X D Cell Batteries +Supply For battery information please refer to Appendix D – Battery Selection Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 438: Configuration

    You may want increase this value to slow transmissions down to achieve longer battery life. In order to capture wind speed of 3.5 mph the Sample time must be 1000ms so the minimum TX interval is al 1000. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 439 This is the current drawn by the sensor; this should be set to 2 mA for the T24- WSS to provide a conservative battery life guide. Usage Per 24 Hour Period Enter the number of hours per 24 hour period that the module will be turned on and transmitting. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 440: Units

    Output Value is the live value of the current wind speed in the units selected above. Items you can change: Output Units Simply select the required output units from the drop down list. The T24-WSS can provide wind speed in m/s , mph, km/h and fps Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 441: Advanced Settings

    Tag of one of the modules and perform pairing again with the T24-HS handheld. Transmit power Set the transmit power level from 0 – 100%. Default is 100% Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 442: Enclosure & Mounting

    Measurement Range Accuracy 5 – 10 mph Accuracy 10 – 125 mph ±4% Environmental Typical Units Operating Temperature Range ° Storage Temperature ° Humidity Environmental protection with suitable cables IP67 exiting through cable glands. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 443: Radio Range

    If charging these cells in circuit precautions must be taken to ensure that the maximum voltage on the transmitter module is not exceeded. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 444 Li ion, LiPo module and the battery. Care must be taken here that the regulator does not draw too much current when idle so that the low power modes are not compromised. Recommend T24-BC1 module. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 445: Appendix F - Conditions Of Use

    Appendix F – Conditions of Use Mantracourt T24 products are not authorised for use in safety-critical applications where a failure of the Mantracourt T24 product would reasonably be expected to cause severe personal injury or death. Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 446: Appendix G - Approval Statements

    This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU . Manufactured in the UK by: Mantracourt Electronics Ltd, The Drive, Farringdon, Exeter, Devon, EX5 2JB, UK Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 447 (antenna) and all persons at all times and must not be co-located or operating in conjunction with any other antenna or transmitter. Manufactured in the UK by: Mantracourt Electronics Ltd, The Drive, Farringdon, Exeter, Devon, EX5 2JB, UK Mantracourt Electronics Limited...

  • Page 448: Fcc

    1699481 AUREL ANT.RP SMA 2.4GHz 2.0dBi Farnell Electronic Components 537-785 EAD, FBKR35068-RS-KR WiFi Antenna 2.0dBi RS Components Manufactured in the UK by: Mantracourt Electronics Ltd, The Drive, Farringdon, Exeter, Devon, EX5 2JB, UK Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 449: Appendix H - Oem / Reseller Marking And Documentation Requirements

    The CE marking must have a height of at least 5 mm  except where this is not possible on account of the nature of the apparatus. The CE marking must be affixed visibly, legibly, and  indelibly. Mantracourt Electronics Limited T24 Telemetry User Manual...
  • Page 450 5 cm is maintained between the radiator (antenna) and all persons at all times and must not be co-located or operating in conjunction with any other antenna or transmitter.” Mantracourt Electronics Limited T24 Telemetry User Manual...

  • Page 451: Fcc

    RS Components Transmitter modules have been certified by the FCC for use with other products without any further certification (as per FCC section 2.1091). Changes or modifications not expressly approved by Mantracourt could void the user’s authority to operate the equipment.

  • Page 452: Appendix I - Worldwide Regional Approvals

    Europe Canada Important Note Mantracourt does not list the entire set of standards that must be met for each country. Mantracourt customers assume full responsibility for learning and meeting the required guidelines for each country in their distribution market. For more information relating to European compliance of an OEM product incorporating the T24 range of modules, contact Mantracourt, or refer to the following web site: www.ero.dk...

  • Page 453: Appendix J - Declaration Of Conformity

    Appendix J - Declaration of Conformity EU DECLARATION OF CONFORMITY We, the undersigned: Name of Manufacturer: Mantracourt Electronics Ltd Address: The Drive, Farrington, Exeter, Devon, EX5 2JB Country: United Kingdom Declare under our sole responsibility that the T24 Telemetry Product Range is in conformity...

  • Page 454: Appendix K - Warranty

    (1) year from the date of dispatch. If the 'Mantracourt' product you purchase appears to have a defect in material or workmanship or fails during normal use within the period, please contact your Distributor, who will assist you in resolving the problem.
  • Page 455 T24 Product Range Part Number: 517-937 Issue Number: 01.06 Dated: January 2018 In the interests of continued product development, Mantracourt Electronics Limited reserves the right to alter product specifications without prior notice. www.mantracourt.com Mantracourt Electronics Limited T24 Telemetry User Manual...

This manual is also suitable for:

T24-saeT24T24-acm-saT24-acmm-saT24-saiT24-acm-saf ... Show all

Table of Contents
