MAP 5000
1

Introduction

1.1

Short information

This manual describes the installation, wiring, initial set-up and maintenance of the MAP 5000
system.
It is applicable for the following main panels including all accessory MAP 5000 products:
–
–
1.2

Listings and approvals

The system is designed to comply with the certifications and approvals listed here.
Region
Germany
Europe
Europe
Switzerland
France
1.3

Battery handling

The battery terminals must be covered after installation in order to avoid short circuits.
Suitable terminal covers are included in the scope of delivery of the power supply.
Danger!
Electrictity
Do not short-circuit the battery in the host alarm system. A short-circuited battery can deliver
large currents that might result in serious burns or create a fire hazard.
Further information is available at http://www.boschsecurity.com/standards.
1.4

Installation considerations

–
–
–
–
–
–
Bosch Sicherheitssysteme GmbH
MAP Main Panel (ICP-MAP5000-2)
MAP Main Panel with IP Communicator (ICP-MAP5000-COM) including the MAP GSM
module (ITS-MAP0008).
Agency
VdS
CE
EN
SES
AFNOR / CNPP
Cert.
When installing this system, ensure that all local and national wiring codes are met.
Only authorized service personnel is allowed to install this system.
Use only the installation material recommended by BOSCH Security Systems to ensure
error-free operation.
Follow anti-static procedures when handling system components. Ensure that you are
properly grounded to discharge any static charge before you work with system
components.
Install all components in dry, maintained interior rooms.
Install the system in a centrally located room that is near the AC Power MAINS.
Certification
Class C, VdS G 111040
Conformité Européene
EN 50131-1:2006 + A1:2009
EN 50131-3:2009
EN 50131-6:2008
EN 50136-2/SP4/DP3
EN 50131-10
Association of Swiss Installers of Security Systems
Edition V3 / 01.01.2011-d
NF&A2P Grade 3
Certificate Number 1133400003A0
According to NF324-H58
Installation manual
Introduction | en 5
2016.06 | 17 | F.01U.168.332
