MAP 5000
May view device status
May view duress alarm
May view alarm count
May view event memory
May view control panel history
May print control panel history
May view control panel version
Maintenance category permissions
May adjust control center volume/brightness
May change output state
May set date time
May test bell
May test motion detectors
May walk test automatic points
May walk test points
Tab. 8.7: SES Permissions
See also
–
–
8.3.5

Tamper surveillance of the main panel

Tamper switch with wall tamper
4
Location supervision of the panel
External alarm signaling by means of siren and/or remote alarm signaling with communicator
must be planned in accordance with Sirens and communicator in accordance with EN50131
grade 3, page 63.
1.
2.
Design types of the communicators according to SES
The transmission paths for remote alarm signaling are divided into the following:
Bosch Sicherheitssysteme GmbH
Installer button, page 67
Manufacturer authorization, page 60
When mounting the enclosure and installing the tamper switch, take the wall tamper of
the panel into account (refer to Mounting the enclosure, page 17 and Installing and
connecting the tamper switch, page 50).
In case of variants A, B and C with communicator(s) of classes 3 and 4, provide location
supervision for the panel as soon as one or more areas are armed.
It is possible to omit location supervision for variant D with class 5 communicator.
Realize the location supervision as a technical solution by the intrusion alarm system
itself. Therefore, ensure the EN-compliance of the requirements for disarming.
Or:
Realize the location supervision by security-relevant persons who guarantee that actions
that pose a risk to security are detected at all times at the time of the required location
supervision.
Installation manual
Appendices | en
X X X
X X X
X X X
X X X
X X
X X
X X X
1 2A 2B 3
X X
X X
X
X X
X X X
X
X
2016.06 | 17 | F.01U.168.332
