20
en | Installation
MAP 5000
Installing the power supply
ICP-MAP0111
IPP-MAP0005
2
1
3
Refer to IPP-MAP0005 power supply ratings label, page 21 for the location of the power supply
ratings label. Refer to Technical Specifications, page 69 for power specifications.
2016.06 | 17 | F.01U.168.332
Installation manual
Bosch Sicherheitssysteme GmbH
