78 en | Appendices
8.2.7

Alarm output via siren and communicator

Alarms, trouble events and other events must be output via siren and/or communicator.
4
External alarm via siren
4
–
–
4
Additional behavior items can be optionally added.
Remote alarm via communicator
4
–
–
–
–
–
Additional reportable events can be optionally added.
8.2.8

Connection to a management system

Refer to IP Interface, page 57.
8.2.9

Printer connection

Connecting the DR2020T printer is permitted only for service purposes.
8.2.10

Access levels

The standard distinguishes between four access levels (AE):
–
–
–
–
Selecting the access level
AE 1 Access for everyone, no authorization/code required
AE 2 Access for users, user passcode required
AE 3 Access for installers via control center
1.
2.
3.
AE 3 Access for installers via RPS for MAP
1.
2.
2016.06 | 17 | F.01U.168.332
For possible variants, refer to Sirens and communicator in accordance with EN50131 grade
3, page 63.
Activate the sirens at least for the following events (behavior items):
External intrusion alarm
External tamper alarm
Set the option Panel Wide Device.
Activate the communicator at least for the following events (Event Manager > Panel
Event Groups > Properties > Reportable Events):
External intrusion alarm
External tamper alarm
Hold-up alarm
Duress alarm
Summary trouble
AE 1 Access for everyone, no authorization/code required
AE 2 Access for users, user passcode required
AE 3 Access for installers via control center or via RPS for MAP
AE 4 Access for manufacturers via RPS for MAP
Open control panel enclosure.
The internal warning device is activated for 3 sec.
Switch to installer mode (refer to Installer button, page 67).
Enter installer passcode.
Open control panel enclosure.
Internal warning device is activated for 3 sec.
or
authorize from RPS with an AE 2 user with corresponding permissions (control center:
main menu page 2 > RPS).
Establish a connection between the panel and RPS.
