Installing the AC terminal block
Warning!
When installing the power supply, ensure that the ground wire from the AC terminal block is
connected to the ground connection point as shown in Installing the AC terminal block, page
!
22.
The ground wire from the AC terminal block to the power supply does not provide an earth
ground for the enclosure. It only provides an earth ground for the power supply.
2.6

Installing the TAE box

4
2016.06 | 17 | F.01U.168.332
If the TAE Box is not mounted on the wall behind the enclosure, mount the TAE Box to
the enclosure back wall either horizontally or vertically as desired.
2
Installation manual
1
3
