Master Answer Record for the HDMI 1.4/2.0 Transmitter Subsystem
AR: 65911
Technical Support
Xilinx provides technical support at the
product when used as described in the product documentation. Xilinx cannot guarantee
timing, functionality, or support if you do any of the following:
• Implement the solution in devices that are not defined in the documentation.
• Customize the solution beyond that allowed in the product documentation.
• Change any section of the design labeled DO NOT MODIFY.
To contact Xilinx Technical Support, navigate to the

Debug Tools

Tools are available to address HDMI 1.4/2.0 Transmitter Subsystem design issues. It is
important to know which tools are useful for debugging various situations.
Vivado Design Suite Debug Feature
The Vivado® Design Suite debug feature inserts logic analyzer and virtual I/O cores directly
into your design. The debug feature also allows you to set trigger conditions to capture
application and integrated block port signals in hardware. Captured signals can then be
analyzed. This feature in the Vivado IDE is used for logic debugging and validation of a
design running in Xilinx devices.
The Vivado logic analyzer is used with the logic debug IP cores, including:
• ILA 2.0 (and later versions)
• VIO 2.0 (and later versions)
See the Vivado Design Suite User Guide: Programming and Debugging (UG908)
HDMI 1.4/2.0 TX Subsystem
PG235 October 4, 2017
Xilinx Support web page
Xilinx Support web
www.xilinx.com
Appendix B: Debugging
for this LogiCORE™ IP
page.
[Ref 21].
