Port Descriptions

Figure 2-11 to
AXI4-Stream is selected as video interface. The VIDEO_IN port is expanded in the figure to
show the detail AXI4-Stream Video bus signals.
The following subsystem has three default interfaces:
• AXI4-Lite control interface (S_AXI_CPU_IN)
• Video Interface (VIDEO_OUT)
• Audio Interface (AUDIO_OUT)
X-Ref Target - Figure 2-11
Figure 2‐11: HDMI TX Subsystem Pinout – AXI4-Stream Video Interface (No HDCP)
HDMI 1.4/2.0 TX Subsystem
