Video Resolutions - Xilinx HDMI 1.4 Product Manual

• Samsung UHDTV (UE40HU6900S)
• Murideo video analyser / SIX-A
• DELL P2415Q
• Philips 288P6LJEB
• LG 27mu67

Video Resolutions

Figure A-1 shows the hardware setup for AXI4-Stream Video Interface. An HDMI source
connects to Video PHY Controller, which converts the HDMI Video into LINK DATA and
sends to the HDMI RX Subsystem. Then, the HDMI RX Subsystem translates the LINK DATA
into AXI4-Stream Video and sends to the Test Pattern Generator. By setting the Test Pattern
Generator to pass-through mode, the AXI4-Stream Video from the HDMI RX Subsystem is
passed to HDMI TX Subsystem where it gets translated to LINK DATA again and sends back
to the Video PHY Controller. The Video PHY Controller then converts it back to HDMI Video
and sends to HDMI Sink.
The Test Pattern Generator can also be configured to generate certain video pattern in the
AXI4-Stream video format, which can be used to test the HDMI TX Subsystem alone instead
of relying on the video received from the HDMI RX Subsystem.
