Xilinx HDMI 1.4 Product Manual page 81

Table A‐2: Tested Video Resolutions for YCbCr 4:2:2 at 12 Bits/component
Resolution
1080p25
1080p30
1080p50
1080p60
2160p24
2160p25
2160p30
vgap60
svgap60
wxgap60
wxga+p60
uxgap60
wuxgap60
wsxgap60
Table A‐3: Tested Video Resolutions for YCbCr 4:2:0 at 8, 10, 12, 16 Bits/Component
Resolution
2160p60
HDMI 1.4/2.0 TX Subsystem
PG235 October 4, 2017
Appendix A: Verification, Compliance, and Interoperability
Horizontal
Total Active
2640 1920
2200 1920
2640 1920
2200 1920
5500 3840
5280 3840
4400 3840
800 640
1056 800
1440 1280
1792 1366
2160 1600
2592 1920
2240 1680
Horizontal
Total Active
4400 3840
www.xilinx.com
Vertical
Total Active
1125 1080
1125 1080
1125 1080
1125 1080
2250 2160
2250 2160
2250 2160
525 480
628 600
790 768
798 768
1250 1200
1245 1200
1089 1050
Vertical
Total Active
2250 2160
Send Feedback
Frame
Rate (Hz)
25
30
50
60
24
25
30
60
60
60
60
60
60
60
Frame
Rate (Hz)
60
