Example Design
This chapter contains step-by-step instructions for generating an HDMI Example Design
from the HDMI 1.4/2.0 Transmitter Subsystem by using Vivado® Flow.

Summary

HDMI 1.4/2.0 Transmitter Subsystem allows users to customize the example design based
on their system requirements. It offers the full flexibility with the following system
parameters:
Topology:
• TX-Only
• Pass-through
VPHY Configuration:
• NI-DRU Enable/Disable
• TXPLL Selection
• RXPLL Selection
Board:
• KC705
• KCU105
• ZC706
• ZCU102
Processor:
• MicroBlaze
• A9
• A53
• R5
HDMI 1.4/2.0 TX Subsystem
