Table 2‐11: Miscellaneous Signals with Native Video Interface
Name
hpd
irq
SB_STATUS_IN_tdata
SB_STATUS_IN_tvalid
video_rst
1. The Hot Plug Detect (HPD) signal is driven by an HDMI sink and asserted when the HDMI cable is connected to
notify the HDMI source of the presence of an HDMI sink. In most cases, the HDMI sink is simply connected to 5V
power signal. Therefore, in the PCB, if you choose to use a voltage divider or level shifter, the HPD polarity remains
as Active High. However, if you add an inverter to the HPD signal, then the HPD polarity must be set to Active Low
in HDMI Transmitter Subsystem GUI.
HDMI 1.4/2.0 TX Subsystem
PG235 October 4, 2017
Direction Width
If XGUI option: Hot Plug Detect Active High (Default)
0 - Hot Plug Detect is released
1 - Hot Plug Detect is asserted
Input 1
If XGUI option: Hot Plug Detect Active Low
0 - Hot Plug Detect is asserted
1 - Hot Plug Detect is released
Output 1 Interrupt request for CPU. Active-High.
Side Band Status input signals
Input 2
Bit 0: link_rdy
Bit 1: video_rdy
Input 1 Side Band Status input valid
Output 1 Video reset signal in video_clk domain. Active-High.
