X-Ref Target - Figure 5-10
10. Export Hardware to prepare for SDK Example Design Flow (File->Export->Export
Hardware).
11. Click OK. (Use the default Export Location <Local to Project> for the example design.)
12. Launch SDK (File->Launch SDK).
13. Choose SDK workspace location. By default, it is "Local to Project."
Vivado SDK is launched.
14. Create Board Support Package in Vivado SDK.
15. Enter BSP project name and click Finish.
16. Click OK.
17. From system.mss, find the HDMI 1.4/2.0 Transmitter Subsystem and click on Import
Examples.
18. Select xhdmi_example.
HDMI 1.4/2.0 TX Subsystem
