Limitations
Only limited fields are supported in current implementation. The supported fields are
highlighted in yellow with respective to the packet type.
General Control Packet:
Pixel Packing Phase and Color depth information are retrieved from video stream and sent
through general control packet by the driver. However, AVMUTE and Default_Phase fields
are not updated and remain as zero always.
X-Ref Target - Figure 2-7
