Xilinx HDMI 1.4 Product Manual page 58

Table 4‐2: Device and Speed Grade Selections (Cont'd)
PPC
Device BPC
Family
Speed
Grade
–1
Virtex-7
–2
–1
Virtex
UltraScale
–2
Notes:
1. All HDMI 1.4 resolutions can be supported.
2. Full HDMI 2.0 resolutions support up to 4096 x 2160 @ 60fps.
Clock Frequencies
The AXI4-Lite CPU clock must run at 100 Mhz. See
information.
Clock Management
This section is not applicable for this IP subsystem.
Clock Placement
This section is not applicable for this IP subsystem.
Banking
This section is not applicable for this IP subsystem.
Transceiver Placement
This section is not applicable for this IP subsystem.
I/O Standard and Placement
This section is not applicable for this IP subsystem.
HDMI 1.4/2.0 TX Subsystem
PG235 October 4, 2017
2
8 10
(2)
HDMI 1.4
(1)
HDMI 2.0
(2)
HDMI 2.0
www.xilinx.com
Chapter 4:
12 16 8
HDMI
(2)
2.0
Clocking in Chapter 3
Design Flow Steps
4
10 12 16
(1)
HDMI 1.4
(2)
HDMI 2.0
(2)
HDMI 2.0
for more
