Install a Processor

Install a Processor
Caution -
fragile. A light touch can bend the processor socket pins beyond repair.
1. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
2. Ensure that the replacement processor is identical to the failed processor that
you removed.
For a description of the processors that are supported by the server, see
Description" on page
3. Prepare the new processor for installation.
a. Use the syringe (supplied with the new or replacement processor) to apply
approximately 0.3 cc of thermal grease to the center of the underside of the
heatsink [1].
b. Distribute the thermal grease over the square heatsink-to-processor contact
area using a flat-edged tool [2].
Note -
Install the new processor.
4.
144 Oracle Server X7-2 Service Manual • October 2017
Be careful not to touch the processor socket pins. The processor socket pins are very
15.
Ensure that you spread thermal grease evenly on the contact areas.
61.
"Product
