Identify and Remove the Failed DIMM

1. Prepare the server for service.
a. Power off the server, and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server to the maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
d. Remove the server top cover.
See "Remove the Server Top Cover" on page
Identify and note the location of the failed DDR4 DIMM by pressing the Fault
2.
Remind button on the motherboard.
Identify and Remove the Failed DIMM
53.
59.
61.
62.
Servicing the DIMMs (CRU) 105
