GE iBox Installation And Maintenance Manual page 152

iBox/iBox Kit
Installation and Maintenance Guide
IBOX Kit with DC Analogs and Ethernet (IBOX-DCL)
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
DNP DPA Communication Port: COM1
Baud Rate: 9600
Communication Type: RS-232
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
Communication Port: Ethernet
DNP DPA
Master IP Address: 192.168.1.200
Slave IP Address: 192.168.1.20
Subnet Mask: 255.255.255.0
User Name: westronic
WESMAINT
Password: rd
Control Password: control
DC Analog Input Ranges
For all bipolar inputs, regardless of whether the input is bipolar current or voltage,
the following is always true:
Maximum negative input
Zero input
Maximum positive input
However, for the 4-20 mA input, the following values are returned by the iBox to the
master:
Any input in the range of 0 to 4 mA
Half of Full Scale (12 mA)
Maximum input (20 mA)
152
Configuration Details
Note: COM2 is used to connect to the Ethernet Module via PPP/TCP/IP.
Note: COM3 is used to connect the DC analog input module to the iBox.
Input Value
Input Value
994-0047-5.10-4
Comments
Refer to point map tables for more detail.
Refer to point map tables for more detail.
Value Returned to Master
-32768
0
32767
Value Returned to Master
-32768
0
32767
