Setting up the machine

2.2 Approaching a reference point

2.2 Approaching a reference point
2.2.1

Referencing axes

Your machine tool can be equipped with an absolute or incremental path measuring system.
An axis with incremental path measuring system must be referenced after the control has
been switched-on – however, an absolute path measuring system does not have to be
referenced.
For the incremental path measuring system, all the machine axes must therefore first
approach a reference point, the coordinates of which are known to be relative to the machine
zero-point.
Sequence
Prior to the approach, the axes must be in a position from where they can approach the
reference point without a collision.
The axes can also all approach the reference point simultaneously, depending on the
manufacturer's settings.
NOTICE
If the axes are not in a collision-free position, you must first traverse them to safe positions
in "JOG" or "MDA" mode.
You must follow the axis motions directly on the machine!
Ignore the actual value display until the axes have been referenced!
The software limit switches are not active!
Procedure
52
Machine manufacturer
Please refer to the machine manufacturer's specifications.
1. Press the <JOG> key.
2. Press the <REF. POINT> key.
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Milling
