7.8.6. Mute specified output

Description: This command mutes an output on a single or multiple layers.
Command {#<out>●<A/V/AV>}
Response (1MT<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to mute audio output no. 2.
Info: If the command is used without the <A/V/AV> parameter, both layers are muted.

7.8.7. Unmute specified output

Description: This command unmutes an output on a single or multiple layers.
Command {+<out>●<A/V/AV>}
Response (0MT<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to unmute audio output no. 2. Now output 2 is

7.8.8. View mutes on all outputs

Description: Viewing all outputs' mute state.
Command {VM}
Response (ALL●<M1>●<M2>●<M3>●<M4>)CrLf ←
Legend: All <Mx> indexes are one digit numbers, showing the mute state for the
corresponding output. If <Mx> equals 0 the output x is unmuted. If <Mx> equals 1, the
output x is muted.
Explanation: Output 1 is muted and the other outputs are not muted.

7.8.9. Lock specified output

Description: This command locks an output on a single or multiple layers.
Command {#><out>●<A/V/AV>}
Response (1LO<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to lock audio & video on output no. 4.

7.8.10. Unlock specified output

Description: This command unlocks an output on a single or multiple layers.
Command {+<<out>●<A/V/AV>}
Response (0LO<out²>●<A/V/AV>)CrLf
Legend:
Explanation: The example shows how to unlock audio & video on output no. 4.
Page 94 / 129
Format
Please read section 7.8.1.
Format
Please read section 7.8.1.
switched to the input it was connected to prior to the mute command.
Format
Format
Please read section 7.8.1.
Format
Please read section 7.8.1.
→ {#2●a}
← (1MT02●A)CrLf
(Switch one input to one
→ {+2●a}
← (0MT02●A)CrLf
(Switch one input to one
→ {vm}
ALL 1 0 0 0)CrLf
(
→ {#>4●av}
← (1LO04●AV)CrLf
(Switch one input to one
→ {+<4●av}
← (0LO04●AV)CrLf
(Switch one input to one
Section 7. Programmers reference
Example
output)
Example
output)
Example
Example
output)
Example
output)
