7.6. Communication setup commands

7.6.1. Query IP settings

Description: IP settings can be retrieved from the router with this command.
Command {IP_CONFIG=?}
Response (IP_CONFIG=<id>
Legend:
Explanation: The router has a fix IP address 192.168.2.106 on the 255.255.0.0 subnet
with a gateway on 192.168.2.1 and communicates over TCP port 10001.

7.6.2. Reload factory default IP settings

Description: This command sets the router to the factory default IP setup.
Command {IP_CONFIG=!}
Response (Changing●IP● configuration...)CrLf
Parameters after successful command execution:
Info: This command can be used on all control interfaces (LAN, RS-232 and USB) but the
'(DONE!)' response cannot be seen on LAN because the connection is dropped just after
the '(Changing IP configuration...)' response.
Info: Factory default setting can be reloaded by the front panel buttons or on the front panel LCD
menu as well.

7.6.3. Enable DHCP IP setting

Description: After sending this command the router will inquire IP address with DHCP.
Command {IP_CONFIG=D}
Response (Changing●IP● configuration...)CrLf
Section 7. Programmers reference
Format
●<ip_address>●<port>
●<mask>●<gateway>)CrLf
Identifier
<id> 0: fix IP
<ip_address> IP address
<port> TCP/IP port
<mask> subnet mask
<gateway> gateway address
Format
(DONE!)CrLf or
Parameter
IP address
port number
Subnet mask
Gateway
Format
(DONE!)CrLf or
→ {ip_config=?}
← (IP_CONFIG=0 192.168.2.106 10001
255.255.000.000 192.168.002.001) CrLf
Description
2: DHCP
→ {ip_config=!}
← (Changing IP configuration...)CrLf
← (DONE!)CrLf
(FAILED!)CrLf
192.168.254.254
10001
255.255.0.0
0.0.0.0
→ {ip_config=d}
← (Changing IP configuration...)CrLf
← (DONE!)CrLf
(FAILED!)CrLf
UMX4x4-Pro
User's Manual
Example
Default value
0
192.168.254.254
10001
255.255.0.0
0.0.0.0
Example
Value
Example
Page 87 / 129
