Change (view) protocol on the front panel
Step 1. Switch the router to TAKE mode if used previously in AUTOTAKE mode by pressing
Step 2. Press Control Lock button for 3 seconds (it lights in up red continuously)
Step 3. Press and keep pressed the Output Lock button. Now the active protocol is
Step 4.
Step 5. If the control protocol for any interface has changed then a beep will sound to notify
Section 4. Operation
TAKE button for 4 seconds. (light will go off)
displayed: (view protocol) One source button lights up according to the current
protocol:
 Source#1 lights:
 Source#2 lights:
a) If you do not want to change the protocol, release the Output Lock button
(view only).
b) If you want to change the protocol keep the Output Lock button pressed,
and press the desired Source button.
the change.
Lightware protocol active on Serial
Protocol#2 is active on Serial
