4.2.6. Switching

Creating connections in TAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Press and release the desired source button. The pressed source button and all
Step 3. Press and release the desired destination button or buttons which has to be
Step 4. Press and release TAKE button to execute switching. Now the selected input is
Info: A source button can be pressed twice to preselect all outputs. Outputs which are connected
to the pressed input light up and all other outputs start to blink. Some outputs can be
unselected if needed, then pressing TAKE executes the switching.
Info: If the pressed destination is locked then it could not be selected. This is indicated by a short
flash of the OUTPUT LOCK when a locked destination is pressed.
Disconnecting or muting in TAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Press and release the selected source button. The pressed source button and all
Step 3. Press and release the selected, green lighting destination button which has to be
Step 4. Press and release TAKE button to execute disconnection.
Info Deselected destinations are disconnected from any source, thus output devices will display
black image or "no signal" message, or automatically will turn off.
Info: If the pressed destination is locked then it could not be deselected. This is indicated by a
short flash of the OUTPUT LOCK when a locked destination is pressed.
Info: Multiple switching and deselecting actions can be done simultaneously, during only one
TAKE action.
Creating a connection in AUTOTAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Press and release the desired destination button. The pressed destination button
Step 3. Press and release the desired input button. The switch action will be executed
Info: If the pressed destination is locked then sources could not be selected. This is indicated by
a continuously light of the OUTPUT LOCK when a locked destination is pressed.
Section 4. Operation
destination buttons which are currently connected to this source will light up. The
dark remaining destination buttons are not connected to this source. This is an
informative display about current status of the selected input (view only).
connected to the selected source. The preselected destination button(s) start(s)
blinking.
switched to the selected output or to the multiple outputs.
destination buttons which are currently connected to this source will light up. The
dark remaining destination buttons are not connected to this source. This is an
informative display about current status of the selected input (view only).
disconnected from the selected source. The pressed destination or multiple
destinations will turn dark.
and the actually connected source button light up green. If no source is connected
(the output is muted) no source button will light up.
immediately. Switching between sources to the selected destination can be done
directly.
