Read preset names
The control software downloads the names automatically upon establishing connection to
the matrix. Preset names can be re-read manually by clicking on the READ PRESET
NAMES button in the preset area.

5.3.7. Input parameter settings

By clicking on an input label a dialog window appears showing the parameters for the
corresponding input.
Scope of changes
There are two options to apply changes. To set the scope of the changed settings, select
the desired option in the top left box.
Apply changes to current input: this option means the modified parameters are applied
only to the currently selected port.
Apply changes to all inputs: this option means that the modified parameters are applied
to all input ports.
When opening this window again, the scope selection will be set to "Current Input"
Info:
regardless of the active selection at the time of closing. It is to avoid making changes to all
inputs by mistake.
Section 5. Software control – Using Lightware Matrix Controller
Figure 5-5. Input parameters for digital signal
