7.10.12. Query analog input audio properties

Description: This command reads the setup of the ADC on the audio board.
Command {:ADC#<in>@<S/A>I=?}
Response (ADC#<in>@<S/A>I=
Legend:

7.10.13. Set the color of no sync picture

Description: If there is no incoming video signal router gives a monochrome 640x480p60
picture to the output. This command sets the color of the no sync picture with an RGB
value.
Command {:SETBG#<in>@<S/A>I=
Response (SETBG#1@SI=
Legend:
Explanation: The example shows how to set yellow colored monochrome no sync

7.10.14. Query the color of no sync picture

Description: This command reads the RGB color code of the no sync picture.
Command {:SETBG#<in>@<S/A>I=?}
Response (SETBG#1@SI=
Legend:
Explanation: The no sync picture color is the (255, 255, 0) RGB coded yellow.

7.10.15. Query timings of the incoming signal

Description: This command reads out the properties of the incoming signal on the selected
input ports.
Command {GETTIMINGS#<in>@<S/A>=?}
Response (GETTIMINGS#<in>@<S/A>=
Section 7. Programmers reference
Format
<GAIN>;<POL>;<DC>)CrLf
Please read section 7.10.1.
Format
<RED>;<GREEN>;<BLUE>;}
<RED>;<GREEN>;<BLUE>;)CrLf
<S/A>: Affected ports:
S = single selected input
A = all outputs
<RED> Red component of RGB value.
<GREEN> Green component of RGB value.
<BLUE> Blue component of RGB value.
picture.
Format
<RED>;<GREEN>;<BLUE>;)CrLf
Please read section 7.10.1.
Format
<TLW>;
<LW>;
<HFP>;
<HW>;
<HBP>;
<TH>;
<H>;
<VFP>;
<VW>;
<VBP>;
<TMDS>;
<BPP>;)CrLf
Example
→ {:adc#1@si=?}
← (ADC#1@SI=9;1;0;)CrLf
(Set input port properties)
→ {:setbg#1@si=255;255;0;}
← (SETBG#1@SI=255;255;0;)CrLf
→ {:SETBG#1@SI=?}
← (SETBG#1@SI=255;255;0;)CrLf
(Set input port properties)
→ {:GETTIMINGS#1@SI=?}
← (GETTIMINGS#1@SI=
2160;
1600;
105;
0;
455;
1242;
1200;
2;
3;
37;
162134;
24;)CrLf
UMX4x4-Pro
User's Manual
Example
Example
Example
Page 105 / 129
