View locked outputs in AUTOTAKE mode
In AUTOTAKE mode a destination is selected all the time. Therefore the currently selected
output and input buttons are illuminated. The Output Lock button illuminates regarding to
the lock state of the current output.
Viewing all locked outputs is not possible in AUTOTAKE mode, as pressing the Output
Lock button instantly locks or unlocks the current output.
Lock an output in AUTOTAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Press and release the required destination button. Now the selected destination
Step 3. Press and release the Output Lock button. Now the Output Lock button lights up in
Unlock an output in AUTOTAKE mode
Step 1. Press and release the required destination button which was previously locked.
Step 2. Press and release the Output Lock button (deselect). Now the Output Lock button
Section 4. Operation
button and the currently configured source button light up (view mode).
red, and lock function is activated at once. No source can be changed at the locked
destination.
Now the selected destination button and the currently configured source button and
the Output Lock button light up.
turns off, and the locking function has been cancelled.
