7.4.4. View CPU firmware compile time
Description: Shows the CPU firmware compile time.
Command {CT}
Response (Compiled:<DATE>●<TIME>●
Legend:
Explanation: The firmware was made in 10.04.2012, 16:36:35 and the identification
number of the firmware is 3564.
7.4.5. View installed controllers' firmware
Description: Shows the firmware revisions of the installed controllers.
Command {FC}
Response (CF●<TYPE>●<VER>●
Legend:
Explanation: The installed matrix controller firmware is 2.0.6 and has the '0X10'
configuration ID.
7.4.6. View current control protocol
Description: Shows the RS-232, TCP/IP control protocol.
Command {P_?}
Response (CURRENT●PROTOCOL●
Legend:
Explanation: Protocol 1 is active here.
7.4.7. Set current control protocol
Description: Sets the RS-232 and TCP/IP control protocol (Default is '1').
Command {P_x}
Response (PROTOCOL●#<x>●
Legend:
Explanation: Protocol 1 is activated.
Section 7. Programmers reference
Format
Build:<tag>)CrLf
<DATE>
Month, Day and Year
<TIME>
Hours, minutes and seconds
<tag>
Identification number of the firmware
Format
@●<INFO>)CrLf
(CF●END)CrLf
Installed controller's type
<TYPE>
The controller's firmware version
<VER>
<INFO>
Optional information about controller configuration
Format
=●#<x>)CrLf
<x>
stands for the active protocol.
Format
SELECTED!)CrLf
Please read section 7.4.6.
Example
→ {ct}
← (Compiled:May 10 2012 16:36:35
Build:3564)CrLf
Example
→ {fc}
←
(CF MX-CP FW:2.0.6 @ 0X10)CrLf
←
(CF END)CrLf
Example
→ {p_?}
← (CURRENT PROTOCOL = #1)CrLf
Example
→ {p_1}
← (PROTOCOL #1 SELECTED!)CrLf
UMX4x4-Pro
User's Manual
Page 83 / 129
