4.2.8. Preset operations

All Lightware matrices have 32 user programmable presets. Each preset stores a
configuration regarding all input connections and mute state for all outputs and both of the
layers. All presets are stored in a non-volatile memory; the router keeps presets even in
case of power down. Memory numbers are assigned to source buttons 1 to 4. The higher
numbered presets are accessible only through software control.
Saving a Preset in TAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Create the desired connections which have to be saved.
Step 3. Press and release the SAVE PRESET button.
Step 4. Press and release a source button according to the desired memory address
Step 5. Press and release TAKE button. Now the current configuration is stored in the
Info Preset save action always stores the current configuration for all outputs including mute
state, but ignoring lock state.
Loading a Preset in TAKE mode
Step 1. Press and release LOAD PRESET button.
Step 2. Press and release a source button according to the desired memory address
Step 3. Press and release TAKE button. Now the selected preset is loaded.
Info Loading a preset modifies all output states that are not currently locked.
Saving a Preset in AUTOTAKE mode
Step 1. Select the desired layer. (Video or audio or both of them)
Step 2. Create the desired connections which have to be saved.
Step 3. Press and release SAVE PRESET button.
Step 4. Press and release a source button according to the desired memory address
Info Preset save action always stores the current configuration for all outputs including mute
state, but ignoring lock state.
Loading a Preset in AUTOTAKE mode
Step 1. Press and release LOAD PRESET button.
Step 2. Press and release a source button according to the desired memory address
Info Loading a preset modifies all output states that are not currently locked.
Section 4. Operation
(source 1 to 4).
selected memory.
(source 1 to 4).
(source 1 to 4). Now the current configuration is stored in the selected memory.
(source 1 to 4). Now the selected preset is loaded.
UMX4x4-Pro
User's Manual
Page 27 / 129
