CHAPTER 9

Unpacking and Mounting the Switch

Installing and Connecting a QFX5200

Related
Documentation
Copyright © 2017, Juniper Networks, Inc.
Installing and Connecting a QFX5200 on page 57
Unpacking a QFX5200 on page 58
Mounting a QFX5200 in a Rack or Cabinet on page 59
You can mount a QFX5200:
Flush with the front of a 19-in. four-post rack. Use the standard mounting brackets
provided with the switch for this configuration.
Recessed 2 in. (5 cm) from the front of a 19-in. four-post rack. Use the extension bracket
provided in the standard mounting kit for this configuration. Recessed mounting is
primarily used in enclosed cabinets.
To install and connect a QFX5200:
Follow the instructions in
1.
Determine how the switch is to be mounted.
2.
Flush or recessed mounted in a rack or cabinet, see
or Cabinet" on page 59.
Follow the instructions in:
3.
Connecting Earth Ground to a QFX5200 on page 64
a.
"Connecting AC Power to a QFX5200" on page 65
b.
QFX5200 on page 68
Registering Products—Mandatory for Validating SLAs
c.
Follow the instructions in
4.
QFX5200 Rack Requirements on page 35
QFX5200 Cabinet Requirements on page 36
QFX5200 Clearance Requirements for Airflow and Hardware Maintenance on page 36
"Unpacking a QFX5200" on page
"Mounting a QFX5200 in a Rack
"Configuring a QFX5200" on page
58.
or Connecting DC Power to a
77.
57
