QFX5200 Switch Hardware Guide
Related
Documentation
50
NOTE:
For information about the actual amount of signal loss caused by
equipment and other factors, see your vendor documentation for that
equipment.
Calculate the (P
) by subtracting (LL) from (P
2.
M
P
– LL = P
B
M
13 dBm – 0.5 dBm [HOL] – 5 (0.5 dBm) – 2 (0.5 dBm) – 2 km (1.0 dBm/km) – 1 dB
[CRM] = P
M
13 dBm – 0.5 dBm – 2.5 dBm – 1 dBm – 2 dBm – 1 dBm = P
P
= 6 dBm
M
The calculated power margin is greater than zero, indicating that the link has sufficient
power for transmission. Also, the power margin value does not exceed the maximum
receiver input power. Refer to the specifications for your receiver to find the maximum
receiver input power.
Understanding QFX Series Fiber-Optic Cable Signal Loss, Attenuation, and Dispersion
on page 46
):
B
M
Copyright © 2017, Juniper Networks, Inc.
