RJ-45 Management Port Connector Pinout Information
Table 29: RJ-45 Management Port Connector Pinout Information
Pin
Signal
1
TRP1+
2
TRP1-
3
TRP2+
4
TRP3+
5
TRP3-
6
TRP2-
7
TRP4+
8
TRP4-
Related
Documentation
Copyright © 2017, Juniper Networks, Inc.
Table 29 on page 53
provides the pinout information for the RJ-45 connector for the
management port on Juniper Networks devices.
Description
Transmit/receive data pair 1
Transmit/receive data pair 1
Transmit/receive data pair 2
Transmit/receive data pair 3
Transmit/receive data pair 3
Transmit/receive data pair 2
Transmit/receive data pair 4
Transmit/receive data pair 4
Connecting a Device to a Network for Out-of-Band Management on page 73
Chapter 8: Pinout Specifications
53
