QFX5200 Switch Hardware Guide
Related
Documentation
12

Figure 4: Management Panel Components on QFX5200

1— Status LEDs
2— em0–RJ-45 (1000 Base-T) management
C0
Ethernet port ( )
Some SKUs have an additional SFP
management Ethernet port (second
3— RJ-45 console port ( CON
The management panel consists of the following components:
Chassis status LEDs, see
Switch product number
Management Ports C0 and C1
C0–Use the RJ-45 connectors for 10/100/1000 BaseT or to cable a virtual
management Ethernet (VME) interface for spine members in a VCF. See .
NOTE: For product SKUs with C0 available in both copper and fiber, the
copper C0 has priority over fiber C0.
C1–Use the SFP connector for 1000 BaseX.
USB port for image updates.
Console port (RJ-45) to support RS-232 serial ports. The LEDs above the port indicate
status and link.
QFX5200 Field-Replaceable Units on page 9
QFX5200 Chassis Status LEDs on page 14
USB Port Specifications for the QFX Series on page 51
QFX5200 Cooling System and Airflow on page 17
QFX5200 AC Power Supply on page 23
Installing and Removing QFX5200 Hardware Components on page 99
4— USB port
5—
em1–SFP management Ethernet port (
Cage (socket for either 1 GbE copper SFP or
fiber SFP)
C0
)
) )
"QFX5200 Chassis Status LEDs" on page 14
Copyright © 2017, Juniper Networks, Inc.
C1
)
