QFX5200 Management Port LEDs

Table 9: Management Port LEDs on a QFX5200 Switch

LED Color
Link/Activity Unlit
Green
Status Unlit
Green
Amber
Related
Documentation
Copyright © 2017, Juniper Networks, Inc.
The management ports (labeled
Base-T and SFP 1000 Base-X connections) on a QFX5200 switch have two LEDs that
indicate link status and link activity (see
status; the right LED indicates link/activity.

Figure 5: Management Port LEDs on a QFX5200 Switch

1— Status LEDs
2— em0–RJ-45 (10/100/1000 Base-T)
management Ethernet port (C0)
3—RJ-45 console port (C0N) )
Table 9 on page 13 describes the management port LEDs.
State
Off
On steadily
Blinking or flickering
Off
On steadily
On steadily
QFX5200 Management Panel on page 11
Connecting a QFX5200 to a Network for Out-of-Band Management
Chapter 2: Chassis Components and Descriptions
for 10/100/1000 Base-T and
C0
Figure 5 on page 13). The left LED indicates
4— USB port
5— em1–SFP management Ethernet port (C1)
Cage (socket for either 10/100/1000 Base-T
RJ45 SFP or 1GbE fiber SFP)
Description
No link is established, there is a fault, or the link is down.
A link is established, but there is no link activity.
A link is established, and there is link activity.
Either the port speed is 10 M or the link is down.
The port speed is 1000 M.
The port speed is 100 M.
for 10/100/1000
C1
13
