QFX5200 Switch Hardware Guide
Related
Documentation

Console Port Connector Pinouts for the QFX Series

Related
Documentation
52
NOTE: USB flash drives used with the QFX Series device must support
USB 2.0 or later.
Creating an Emergency Boot Device on page 115
Performing a Recovery Installation Using an Emergency Boot Device on page 117
The console port (labeled
RJ-45 connector to connect to a console management device. The default baud rate for
the console port is 9600 baud.
Table 28 on page 52 provides the pinout information for the RJ-45 console connector.
An RJ-45 cable and RJ-45 to DB-9 adapter are supplied with the QFX Series device.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to a QFX Series device, use a
combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the
device and a USB to DB-9 male adapter. You must provide the USB to DB-9
male adapter.

Table 28: Console Port Connector Pinouts for the QFX Series

Pin
1
2
3
4
5
6
7
8
Connecting a QFX Series Device to a Management Console
, or ) is an RS-232 serial interface that uses an
CON CONSOLE
Signal
RTS Output
DTR Output
TxD Output
Signal Ground
Signal Ground
RxD Input
DCD Input
CTS Input
Description
Request to send
Data terminal ready
Transmit data
Signal ground
Signal ground
Receive data
Data carrier detect
Clear to send
