Table 3: QFX5200 Hardware-only Product Numbers (continued)
Product Numbers
QFX5200-32C-DC-AFI
Related
Documentation
Understanding Hardware Redundancy of QFX5200 Components and Functionality
Related
Documentation
Copyright © 2017, Juniper Networks, Inc.
Ports
32 QSFP28
CAUTION: Mixing different types (AC and DC) of power supplies in the same
chassis is not supported. Mixing different airflow modules in the same chassis
is not supported.
QFX5200 Management Panel on page 11
QFX5200-32C Port Panel on page 7
QFX5200 Hardware Overview on page 3
The following hardware components provide redundancy on a QFX5200 switch:
Power supplies—The QFX5200 switch has one or two power supplies. Each power
supply provides power to all components in the switch. If two power supplies are
installed, the two power supplies provide full power redundancy to the device. If one
power supply fails or is removed, the second power supply balances the electrical load
without interruption.
To provide power redundancy to the system both power supplies must be installed.
Connect power source feed A to one power supply and power source feed B to the
second power supply.
CAUTION: Do not connect feed A and feed B to the same power supply
input terminal.
Cooling system—The QFX5200 has five fan modules. If a fan module fails and is unable
to keep the QFX5200 switch within the desired temperature thresholds, chassis alarms
occur and the QFX5200 switch can shut down.
QFX5200 AC Power Supply on page 23
QFX5200 DC Power Supply on page 25
QFX5200 DC Power Supply on page 25
Chapter 1: System Overview
Power
Supply Airflow
DC Air In (FRUs-to-ports)
5
