- Page 1 QFX5200-48Y Quick Start Guide Published RELEASE 2023-10-20...
- Page 2 Table of Contents Mounting the QFX5200-48Y Connecting Power to the Device Performing the Initial Software Configuration for QFX5200 Switches Safety Warnings Summary...
- Page 3 Mounting the QFX5200-48Y The QFX5200-48Y is available in AC and DC power models. Only mount QFX5200-48Y models in a four-post rack. This procedure describes the installation into a four-post rack and connecting AC power. For DC connection procedures, see the complete QFX5200-48Y hardware documentation at https:/ / www.juniper.net/documentation/.
- Page 4 The QFX5200-48Y weighs between 20.78 lb (9.43 kg) and 21.16 lb (9.6 kg) with power supplies and fans installed. Installing these devices in a rack or cabinet requires two people to lift the switch and secure it to the rack.
- Page 5 Figure 2: Align Holes for Mounting Rail and Attach with Screws Repeat Steps on the opposite side of the switch. 10. Have one person grasp both sides of the unit, lift it, and position it in the rack so that the front mounting bracket is aligned with the rack holes.
- Page 6 Figure 4: Slide Blades into Mounting Rails and Attach to the Rack 13. Ensure that the chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack. 14.
- Page 7 Connecting Power to the Device The device is supplied with two factory-installed power supplies. To connect power to an AC-powered switch: 1. If the AC power source outlet has a power switch, set it to the OFF (O) position. 2. Insert the coupler end of the power cord into the AC power cord inlet on the AC power supply faceplate.
- Page 8 Connect the console port to a laptop or PC using an RJ-45 cable and RJ-45 to DB-9 adapter. The console (CON) port is located on the management panel of the switch. Log in as root. There is no password. If the software booted before you connected to the console port, you might need to press the Enter key for the prompt to appear.
- Page 9 CAUTION: Although the CLI permits you to configure two management Ethernet interfaces within the same subnet, only one interface is usable and supported. NOTE: On the QFX5200-48Y, the management port em0 is the top right-hand RJ-45 port on the port panel.
- Page 10 No Link Title Safety Warnings Summary IN THIS SECTION Power Cable Warning (Japanese) | 9 Contacting Juniper Networks | 9 This is a summary of safety warnings. For a complete list of warnings, including translations, see the hardware documentation at https:/ /www.juniper.net/documentation/.
- Page 11 Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
